The MI -ROBO from GÖT TFER T offers the possibility to perform fully automated melt index measurements for granules and powder materials. This includes fully automated filling of the test barrel, automatic execution of the…
HIGHLIGHTS
• Fully automated melt index measurements
according to Method A and B
Automated sample preparation
Automated measurements
Automated cleaning of test piston,
test barrel and die
• Integrated sample magazine for 30 single
tests, fillable with granules, powder and
similar material profiles
• Temperature control algorithm,
Resolution 0 to 320 °C: 0.01 °C,
320 to 500 °C: 0.1 °C
• Precise displacement transducer for exact
volume determination
• High precision timer with a resolution
better than 0.001 s (for determination of
melt density)
Acc. to Standards:
ISO 1133
ISO 1133
ASTM D1238
ASTM D3364
BS 2782
NF51-016
MI-ROBO
Fully automated Melt Flow Indexer
14
The MI-ROBO from GÖTTFERT offers the possibility to
perform fully automated melt index measurements for
granules and powder materials.
This includes fully automated filling of the test barrel,
automatic execution of the measurement, automatic cleaning
of the test barrel and die, as well as die change. With
automated filling, an unlimited number of consecutive
tests can be carried out without operator intervention.
The MI-ROBO can be individually configured for the
respective polymer through various optional features.
Determination of melt density (Method A)
The MI-ROBO optionally enables the automatic determination
of melt density according to Method A in accordance with
ISO 1133. The melt volume is recorded in relation to the
melt index, and the density of the material is calculated
automatically.
This procedure increases reproducibility and minimizes
operator errors – ideal for precise material analysis and
quality assurance.
OPTIONS
• Sample magazine in standard or inlet
design for sticky materials
• Additional integrated weights with
automatic weight selection for pre-load
and measurement
• Magazine heating
• Nitrogen purge
• Automatic material feeding
• Test barrel and piston in corrosion-
resistant or abrasion-resistant design
• MFR measurements according to Method
A (determination of melt density)
Learn more goettfert.com/mi-robo
NEW!
Determination of
melt density
according to
Method A
• Aligned cleaning tools for optimized results
• Individual filling and cleaning procedures,
specific to each material
• Automatic melt cutting unit
• Electrically heated test barrel with easily
exchangeable design
• 5 temperature calibration data sets with
separate control parameters for optimal
adaptation
SPECIFICATIONS
MI-ROBO
15
SOFTWARE miCONNECT
• Uniform and user-friendly operating concept
• Browser-based testing software
• Easy setup, management and analysis of test plans
• Support for Microsoft
®
Access and Microsoft
®
SQL databases
• Flexible search filter (test plans / test results)
• OPC/UA interface
• Easy installation
Our Melt Flow Indexers can be specifically adapted
to special material properties and testing
requirements through various optional features.
From automatic cutting units to corrosion-resistant
designs – for greater efficiency, precision and
durability in daily operation.
• Automatic melt cutting unit (also for highly
adhesive materials) (Fig. 1)
• Time-saving: pre-compression and extrusion for
viscous test materials (mi3)
• Nitrogen purge for hygroscopic polymers
• Barrel and piston in corrosion-resistant or
wear-resistant design
• Die plug (Fig. 2)
Software and Options
mi2, mi3 und mi40
Fig. 1
Fig. 2
Optional versions for individual requirements
