Commissioning, r epairs or maintenance of your GÖT TFER T testing instruments – we provide the right solution and support you regardless of location via remote access . Our customer platform serviceCONNECT enables direct…
YOUR BENEFITS
WELL ADVISED
1 year
Standard warranty
Device purchase
Semiannual/
Annual
Maintenance visit
Annual
Maintenance visit
Annual
Maintenance visit
Maintenance contract
+warranty
extension
for Melt Flow Indexers and Capillary Rheometer
Enhanced safety
STANDARD
EXTENDED
• Extension of warranty to 24 months
• Free updates
• 3% discount on spare parts
• 50% discount on in-house training
• Prioritized support on our service platform
serviceCONNECT
• Periodic maintenance of your testing instrument
• Maintenance scheduling through service planning
Learn more
goettfert.com/service-contract
Only regular maintenance ensures long-term reliability.
We offer you a service contract tailored to your needs.
All GÖTTFERT testing instruments are delivered with a 1-year
warranty. Enhanced safety extends the warranty for our
manually operated Melt Flow Indexers and Capillary
Rheometer by another 12 months, provided that a
maintenance contract (duration 36 months from purchase
and up to 12 months thereafter) is concluded. With
semi-annual or annual maintenance visits, the reliability of
the machine is ensured.
We are happy to prepare a customized offer for you,
including further benefits such as SERVICE BASIC+ or
SERVICE ISO 17025, discounted spare parts, or
prioritized processing of inquiries. This makes budget
and operating costs predictable.
21
Commissioning, repairs or maintenance of your GÖTTFERT
testing instruments – we provide the right solution and
support you regardless of location via remote access.
Our customer platform serviceCONNECT enables direct
contact with our product managers.
Remote Support
Fast, straightforward and targeted handling of service requests
LOCATION-INDEPENDENT
DIRECT CONTACT
SHORT RESPONSE TIMES
STRAIGHTFORWARD
Learn more
goettfert.com/serviceconnect
Fast Response via remote access
22
Model mi1 mi2 mi3 mi40
Test procedure
Automated measurement
with single load
Automated
measurement
with single load and
manual weight
selection
Automated measu-
rement and software
controlled weight
selection, Multi load
measurement
Test chamber
Two heater circuits, electrically heated, temperature sensor PT100 1/3 DIN
Temperature diff erence over time: < ± 0.1 °C
Temperature diff erence over distance (0 - 70 mm before the die)
< ± 0.2 °C of set temperature (temperature range 60 °C to 400 °C)
< ± 0.3 °C of set temperature (option: temperature range 400 °C to 500 °C)
Load steps 0,325 - 21.6 kg
Weight guidance Piston guidance according to ISO/ASTM
Piston guidance according to ISO/ASTM and
internally installed test weights
Weight handling system - Yes Yes Yes
Pre-load and
material purge function
Manually with weights (option)
Automated with manual
weight selection
Fully automated
with weights or
force controlled
Multi-Load function -
8 weight steps,
selectable in
any sequence
Actual temperature display
0 - 500°C on PC via VNC
Viewer
0 - 500 °C on touch screen monitor
Temperature acquisition Via 16-bit converter, resolution 0 - 320 °C: 0,01 °C; resolution 320 - 500 °C: 0,1 °C
Test barrel 9.555 (-0.01) mm diameter
Touchscreen display - 14.48 cm (5.7“) Color VGA touch screen monitor
Test value acquisition
Electronically,
resolution:
0,003 mm/Impuls
Electronically,
resolution:
0.003 mm/impulse
Electronically, resolution: 0.006 mm/impulse
Test data display Numerical
Die
2.095 (± 0.003) mm diameter, 8 (± 0.025) mm length
1.048 (± 0.005) mm diameter, 4 (± 0.025) mm length (option)
Advanced evaluation 1 IV calculation to characterize polyester and polyamide based plastics
Advanced evaluation 2:
Add-On die swell measurement
-
Flow Rate Ratio (FRR) calculation
for multi load tests
Melt cutting unit Option
Die locking mechanism Option
Nitrogen purge Option
Corrosion resistant version Option
Abrasion resistant version Option
Pre-load function Manual pre-loading (option) Semi-automatic Fully-automated
Data input PC Touch screen monitor
Interfaces Ethernet Ethernet, serial, 1 or 2 x USB (printer, memory)
Power supply 115 V or 230 V
Ambient temperature +10 - +40 °C
Ambient humidity max. 90 % not condensing
Dimensions
Width / Depth / Height
(*with cleaning module)
W: 290 mm
D: 380 mm
H: 530 mm
W: 530 mm
D: 380 mm
H: 836 mm
W: 888 mm*
D: 585 mm*
H: 1317 mm*
W: 888 mm*
D: 585 mm*
H: 1317 mm*
Weight approx. 37 kg approx. 75 kg approx. 170 kg approx. 200 kg
mi2
Specifi cations
Overview of main parameters
23
