Model mi1 mi2 mi3 mi40
Test procedure
Automated measurement
with single load
Automated
measurement
with single load and
manual weight
selection
Automated measu-
rement and software
controlled weight
selection, Multi load
measurement
Test chamber
Two heater circuits, electrically heated, temperature sensor PT100 1/3 DIN
Temperature diff erence over time: < ± 0.1 °C
Temperature diff erence over distance (0 - 70 mm before the die)
< ± 0.2 °C of set temperature (temperature range 60 °C to 400 °C)
< ± 0.3 °C of set temperature (option: temperature range 400 °C to 500 °C)
Load steps 0,325 - 21.6 kg
Weight guidance Piston guidance according to ISO/ASTM
Piston guidance according to ISO/ASTM and
internally installed test weights
Weight handling system - Yes Yes Yes
Pre-load and
material purge function
Manually with weights (option)
Automated with manual
weight selection
Fully automated
with weights or
force controlled
Multi-Load function -
8 weight steps,
selectable in
any sequence
Actual temperature display
0 - 500°C on PC via VNC
Viewer
0 - 500 °C on touch screen monitor
Temperature acquisition Via 16-bit converter, resolution 0 - 320 °C: 0,01 °C; resolution 320 - 500 °C: 0,1 °C
Test barrel 9.555 (-0.01) mm diameter
Touchscreen display - 14.48 cm (5.7“) Color VGA touch screen monitor
Test value acquisition
Electronically,
resolution:
0,003 mm/Impuls
Electronically,
resolution:
0.003 mm/impulse
Electronically, resolution: 0.006 mm/impulse
Test data display Numerical
Die
2.095 (± 0.003) mm diameter, 8 (± 0.025) mm length
1.048 (± 0.005) mm diameter, 4 (± 0.025) mm length (option)
Advanced evaluation 1 IV calculation to characterize polyester and polyamide based plastics
Advanced evaluation 2:
Add-On die swell measurement
-
Flow Rate Ratio (FRR) calculation
for multi load tests
Melt cutting unit Option
Die locking mechanism Option
Nitrogen purge Option
Corrosion resistant version Option
Abrasion resistant version Option
Pre-load function Manual pre-loading (option) Semi-automatic Fully-automated
Data input PC Touch screen monitor
Interfaces Ethernet Ethernet, serial, 1 or 2 x USB (printer, memory)
Power supply 115 V or 230 V
Ambient temperature +10 - +40 °C
Ambient humidity max. 90 % not condensing
Dimensions
Width / Depth / Height
(*with cleaning module)
W: 290 mm
D: 380 mm
H: 530 mm
W: 530 mm
D: 380 mm
H: 836 mm
W: 888 mm*
D: 585 mm*
H: 1317 mm*
W: 888 mm*
D: 585 mm*
H: 1317 mm*
Weight approx. 37 kg approx. 75 kg approx. 170 kg approx. 200 kg
mi2
Specifi cations
Overview of main parameters
