Version Description

SIPLACE OIB 4.3 05/2016 Edition

7 Functions in SIPLACE OIB Monitoring Service Adapter

The functions of the SIPLACE OIB Monitoring Adapter are

• Online Station Events

• Board summary with

o Used material

o Identification and Vacuum errors

o Related SIPLACE Pro and Setup data

o Component names

A combined data model including the separated SIPLACE OIS/SIS data in a common structure.

8 Functions in SIPLACE OIB Client API

8.1 Installing Assemblies into the GAC together with a policy file

The OIB Client API installer copies the client side proxy dlls into the global assembly cache (GAC). It also

adds publisher policies to the GAC.

This makes it possible to update the SIPLACE OIB Smart Proxy assemblies at the customer site without

requiring client applications to be recompiled. It enables bringing bug fixes that were done in the proxy dlls

to the customer without touching the applications.

The policy files will redirect the existing application to use the new versions of the Smart Proxy assemblies

in the GAC. The SIPLACE OIB Client API installation will take care that the upgrade of these components

will be performed automatically..

Please see also the chapter “2.7 Upgrading with SIPLACE OIB” in the 00197701-04_IM_SIPLACE-OIB-

4.3_EN.pdf document for a compatibility matrix.

Version Description

SIPLACE OIB 4.3 05/2016 Edition

9 Restrictions

9.1 General Restrictions

Due to the dependency of the API to the underlying SIPLACE products, the content and the functionality of

the exposed API depends on the configuration of the overall system. Please see the adapter version

description of the target adapter for details.

9.2 Restrictions for the Line Control Adapter

The SIPLACE OIB Line Control Adapter must be installed on the same computer as the Line Control

Server has been installed.

9.3 Restrictions for all SIPLACE Pro Adapter Versions

All SIPLACE OIB SIPLACE Pro Adapters require an SPI installation of the target version of SIPLACE Pro

on the same machine.

The installation can be implicitly by installing a SIPLACE Pro product like SIPLACE Pro Desk

on this computer or you can explicitly install the interface by starting the SIPLACE Pro Installer and select “SIPLACE

Pro Interface” as the installation type.

9.4 SIPLACE OIB Setup Center Adapter

When operating the SIPLACE OIB Setup Center Adapter together with the XML Import Service it might

happen that the system is not operating properly, when the event log configuration from Windows is not

setup appropriately.

Workaround: Ensure that the Application event log is setup for “Overwrite events when required”

9.5 Setup Center in General

This chapter describes restrictions concerning the whole Setup Center application.

• For all used components, “verification” has to be activated in SIPLACE Pro.

• The setting “Setup Verification System” of a used setup has to be set to “External … System” in

SIPLACE Pro.

• There has to be a line configured in Setup Center.

• Setup Center only works in unique ID mode, ICL mode is not supported by SIPLACE OIB.

Therefore the barcode definitions have to define a barcode with barcode fragment “UniqueId”.

• Table management is supported with restrictions. Table announcement is only possible at the

station on site. Therefore a table has to be announced first manually, before machine control

operations may be executed via Setup Center Interface. Events have no restrictions.

• Quantity printout for ICL mode has to be disabled.

• XML import has to be disabled.

Version Description

SIPLACE OIB 4.3 05/2016 Edition

9.6 Setup Center Interface

This chapter describes restrictions concerning the whole functionality of the interface.

• The usage of SIPLACE OIB requires online verification.

• Splice chains have to be completed to be passed into the interface. If only one packaging unit of

an existing splice chain is used, the splice association will be deleted.

• Barcode rules won’t be executed.

• The following matrix shows invalid combinations for packaging unit quantity and original quantity:

Condition

Result

Quantity==Int32.MinValue && OriginalQuantity==Int32.MinValue

Denied

Quantity != Int32.MinValue && Quantity < 0

Denied

OriginalQuantity != Int32.MinValue && OriginalQuantity < 0

Denied

Quantity > 0 && OriginalQuantity==0

Denied

Quantity > OriginalQuantity

Denied

10 Errors that have been fixed

Please see the ReadMe.txt file in the installation media for the latest list of errors that have been fixed. The

ReadMe.txt file will be updated with every build.

11 Support of Previous Versions

Beginning with the release of OIB 4.2 the support of OIB Proxies V2.4 and lower will be discontiued. To

continue receiving support it will be required to upgrade the OIB proxies to a newer version.

12 Important terms and abbreviations

OIS

Operator Information System

SIS

Setup Information System

ICL

Identical Component Lot: When the packaging units does not have

unique id, but share the same batch id.

SPI

SIPLACE Pro Programming Interface
