MODEL FP-G 300R 0801-002 電装部 ELECTRICAL SECTION Fig. FJ-2 制御部 Control Section 156 156 155 151 152 192 192 149 170 167 146 170 141 166 . 168 . 169 193 . 197 . 198 185 184 183 185 186 157 164 163 179 173 . 176 . 177 . 178 …
MODEL FP-G300R
1004-004
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
FJ-1
FJ-1 list-1
51 6301417356 BASE 1 806FJ-110-051 210A2468
52 6301417363 BRACKET 1 806FJ-110-052 211FA297
53 6301416403 BRACKET 1 806FJ-110-053 211FA286
54 6301416410 BRACKET 1 806FJ-110-054 211FA287
55 6301416427 PLATE 1 806FJ-110-055 211DB188
56 6301416434 PLATE 1 806FJ-110-056 211DB189
58 6301417288 COVER 1 806FJ-110-058 211AA290
59 6301417295 COVER 1 806FJ-110-059 211AA291
60 6301417349 COVER 1 806FJ-110-060 211AA292
61 6301417974 COVER 1 806FJ-110-061 211AA294
68 6300775617 ACCESSORY,P.C.B 8 806FJ-110-168 23L10057
71 6300007619 BOLT,HEX-SCT 20 M4X8 221A0016
72 4110511708 SCR TRS 4X6 29 M4X6 TRS 221E0532
76 4111412905 WASHER SPR 4 20 SW4 221H0284
77 4111414008 WASHER V 4X9X0.8 20 FW4 221H0315
MODEL FP-G300R
0801-002
電装部
ELECTRICAL
SECTION
Fig. FJ-2
制御部
Control Section
156
156
155
151
152
192
192
149
170
167
146
170
141
166
.
168
.
169
193
.
197
.
198
185
184
183
185
186
157
164
163
179
173
.
176
.
177
.
178
175
179
171
180
193
.
197
.
198
196
See Fig. FK-1
Key No.1
See Fig. FK-1
Key No.4
See Fig. FK-1
Key No.3
144
.
145
143
.
145
.
147
193
.
197
.
198
142
181
182
158
165
172
.
154
132
192
162
161
162
194
.
197
.
198
195
.
197
.
198
197
.
198
.
199
197
.
198
.
199
189
.
190
.
191
193
.
197
.
198
See Fig. FA-1
Key No.1
FJ-1 illust-1
MODEL FP-G300R
1004-004
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
FJ-2
FJ-2 list-1
132 6301391199 BRACKET 1 806FJ-110-062 211F9979
141 6301415437 BREAKER 1 Q101 806FJ-110-251 4S230099
142 6301420646 RESISTOR,SPECIAL 1 R01 806FJ-110-252 4R500011
143 4230228203 FUSE 250V 3.15A 1 F102 806FJ-110-253 4V320011
144 4230228005 FUSE 250V 1A 2 F101,F103 806FJ-110-254 4V320007
145 6301262864 FUSE HOLDER 3 806FJ-110-255 4J200033
146 6301262871 ACCESSORY,WIRING 1 806FJ-110-256 23N30605
147 6300969917 ACCESSORY,WIRING 1 806FJ-110-257 23N30524
149 6301099934 ACCESSORY,WIRING 1 806FJ-110-267 23N30542
151 6301237138 UNIT,DRIVER 3 A01,A02,A03
806FJ-110-151 4U240429
152 6301280639 UNIT,DRIVER 2 A04,A05 806FJ-110-152 4U240445
154 6301281308 RESISTOR,SPECIAL 1 806FJ-110-154 4R500009
155 6301235707 P.C.B,MOUNT 1 U06 806FJ-110-155 4B111448
156 6301376103 P.C.B,MOUNT 2 U07,U08 806FJ-110-156 4B111516
157 6301288949 P.C.B,MOUNT 2 U09,U10 806FJ-110-157 4B111494
158 6301404844 NAME PLATE,INDEX 2 806FJ-110-158 6P460165
161 6301405490 MOTOR,DC 1 M101 806FJ-110-161 4M130025
162 6301399799 ACCESSORY,MOT-M 2 806FJ-110-162 23M00061
163 6300728095 SWITCH,BUTTON 3 S0710(H0734),S0711(H0735),
S0713(H0737)
806FJ-110-163 4S1B0118
164 6300703009 LAMP 1 H00001 806FJ-110-164 4T300027
165 6301438382 NAME PLATE 1 806FJ-110-165 6P410329
166 6301270302 TERMINAL 16 806FJ-110-261 4J320187
167 6301270296 ACCESSORY,WIRING 2 806FJ-110-262 23N30612
168 6300969399 ACCESSORY,WIRING 10 806FJ-110-263 23N30519
169 6300969917 ACCESSORY,WIRING 1 806FJ-110-264 23N30524
170 6300911749 BRACKET,WIRING 2 806FJ-110-265 23N10027
171 6300941418 EM-CONTACTOR 4 K101,K201,K301,K401
806FJ-110-171 4S210086
172 6301415369 ACCESSORY,WIRING 4 806FJ-110-172 23N30673
173 6301270302 TERMINAL 4 806FJ-110-173 4J320187
175 6301270296 ACCESSORY,WIRING 2 806FJ-110-175 23N30612
176 6300969382 ACCESSORY,WIRING 1 806FJ-110-176 23N30518
177 6300969399 ACCESSORY,WIRING 3 806FJ-110-177 23N30519
178 6300969917 ACCESSORY,WIRING 1 806FJ-110-178 23N30524
179 6300911749 BRACKET,WIRING 2 806FJ-110-179 23N10027
180 6301240824 RAIL,WIRING 1 806FJ-110-180 23N00098
181 6301415376 RELAY 2 K616,K617 806FJ-110-181 4S200160
182 6300952643 SOCKET 2 806FJ-110-182 4J120108
183 6300854152 RELAY 3 K600-603,K604-607,K608-612
806FJ-110-183 4S200112
184 6301158440 RELAY 1 K001 806FJ-110-184 4S200142
185 6300911749 BRACKET,WIRING 2 806FJ-110-185 23N10027
186 6301099934 ACCESSORY,WIRING 1 806FJ-110-186 23N30542
189 6300007619 BOLT,HEX-SCT 2 M4X8 221A0016
190 4111412905 WASHER SPR 4 2 SW4 221H0284
191 4111414008 WASHER V 4X9X0.8 2 FW4 221H0315
192 4111130700 SCR PAN 3X16 13 M3X16 PAN 221E0491
