KHT -1004 Rev . :It had a change without the compatibility . Please be careful at the time of the parts ordering. Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。 No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. P…
KHT-1004
3
5
PU-Motor / Sensor / Matrix-Plate
Moving-axis
3
15
14
4
9
6
6
5
7
11
17
18
17
18
10
8
12
13
2
1
16
KHT-1004
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
KHT-M3231-00 STAY,SENSOR PU
1 /
Í
39
2
KHT-M6521-L1 SENSOR PU ORG ASSY
1 B
Í
40
3
90K63-331512 AC SERVO MOTOR
1 B
Í
41
4
KHT-M3351-11 MATRIX PLATE,AL14
2
Plover Type (AL)
/
42
5
KHT-M3356-00 ADJUSTER,MATRIX P
8 /
43
6
99480-05016 PIN PARALLEL
8 44
7
98702-03008 SCREW FLAT HEAD
8
45
8
KHT-M3351-21 MATRIX PLATE,AL7
2
Lettice Type (AL)
/
46
9
KHT-M3351-31 MATRIX PLATE,FE14
2
Plover Type (FE)
/
47
10
KHT-M3351-41 MATRIX PLATE,FE7
2
Lettice Type (FE)
/
48
11
KGY-M3352-00 SUPPORT SHAFT
72 /
49
12
KGJ-M3352-A0 MATRIX PIN ASSY
200 /
50
13
KGY-M3354-A0 MAGNET MATRIX PIN ASSY
5 /
51
14
91312-04010 BOLT HEX.SOCKET HEAD
2
M4X10
52
15
91312-04014 BOLT HEX.SOCKET HEAD
8
M4X14
53
16
98502-03008 SCREW PAN HEAD (+)
2 54
17
91312-04012 BOLT,HEX.SOCKET HEAD
8
M4X12
55
18
91312-05014 BOLT HEX.SOCKET HEAD
16
M5X14
56
19
57
20
58
21
59
22 60
23 61
24 62
25 63
26 64
27 65
28 66
29 67
30 68
31 69
32 70
33 71
34 72
35 73
36 74
37 75
38 76
3
5
PU-Motor / Sensor / Matrix-Plate
Moving-axis
KHT-1004
22
24
7
24
30
21
14
29
1
34
5
4
3
23
16
33
27
26
33
25
9
12
25
9
12
16
16
33
9
6
19
2
15
28
20
31
11
10
18
17
32
9
26
13
8
4
1
3S-Motor / Sensor
Head
