YSP_mpl_je.pdf - 第64页
KHT -1 101 Rev . :It had a change without the compatibility . Please be careful at the time of the parts ordering. Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。 No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. …
KHT-1101
32
3
36
1
4
5
14
51
42
44
29
53
10
7
34
11
13
33
9
20
52
25
30
29
53
24
19
18
8
38
39
16
27
37
35
46
31
46
31
43
48
47
49
37
47
41
40
47
37
28
15
12
42
50
23
17
6
21
26
25
22
30
45
2
2
8
1
POT-Head Assy
PSC
KHT-1101
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
KHT-M7307-00 UNDER COVER,SOL.
1 /
39
91312-03012 BOLT,HEX.SOCKET HEAD 1 M3X12
2
KHT-M7308-00
WASHER
2 /
40
91312-03016
BOLT,HEX.SOCKET HEAD 2
M3X16
3
KHT-M7313-00 BELT, FP MOTOR
1 /
Í
41
91312-04006 BOLT HEX.SOCKET HEAD 1 M4X6
4
KHT-M7315-00 PULLEY,MOTOR
1 /
Í
42
91312-04010 BOLT HEX.SOCKET HEAD 3 M4X10
5
KHT-M7316-00 KNOB,FP MOTOR
1 /
Í
43
92902-04600 WASHER PLAIN 2
6
KHT-M7320-A0 PASTE CUTTER ASSY
1 A
44
92A08-03303 SET SCREW M3X3 2 M3X3
7
KHT-M7321-00 PASTE CUTTER
1
A
45
92A08-03305 SCREW,SET 2 M3X5
8
KHT-M7380-00 PASTE CUP
1
A
46
98702-04010 SCREW FLAT HEAD 2
9
KHT-M7394-00 KNOBE,M3
2
/
47
98902-03005 SCREW BINDING HEAD 6 M3X5
10
98902-03004 SCREW BINDING HEAD
1
M3X4
48
98902-03008 SCREW BINDING HEAD 2 M3X8
11
KHT-M7322-02 CUTTER PLATE
1 /
Í
49
98902-04010 SCREW BINDING HEAD 2 M4X10
12
KHT-M7323-01 COVER,HNS.
1 /
50
$SC4-M3MA SPEED CONTROLLER 2
13
KHT-M7324-00 SPACER BLOCK
1 /
51
90990-12J001 SCREW BIN.HEAD W/W 3
14
KHT-M7326-01 COVER,FP
1
W=160mm
/
52
KHT-M7336-00 BALL PLUNGER 1
/
15
KHT-M7328-01 DAMPER 2,FP COVER
1 /
53
92902-06600 WASHER PLAIN 2
16
KHT-M7329-00 DAMPER 3,FP COVER
1 /
54
17
KHT-M7330-A1 PASTE NOZZLE ASSY
1 /
55
18
KHT-M7331-00 NOZZLE 6,POT DISP.
1
/
56
19
KHT-M7332-00 HOLDER,NOZZLE
1
/
57
20
KHT-M7333-01 BLOCK,PASTE NOZZLE
1
/
58
21
KHT-M7334-00
DAMPER,PASTE NOZZLE
1 /
59
22
KGJ-M7116-01 BALL PLUNGER
1 /
60
23
90990-41J042 COLLAR
2 /
61
24
91312-03008 BOLT HEX.SOCKET HEAD
2
M3X8
62
25
95302-05700 NUT HEXAGON
1 63
26
98902-03008 SCREW BINDING HEAD
2
M3X8
64
27
KHT-M7371-01 CYLINDER
1 A
Í
65
28
KHT-M7388-00 DAMPER 1,FP COVER
1 /
66
29
KGJ-M710B-C0 SPACER PIPE
2 /
67
30
KHT-M7327-00 MINI CLAMP LEVER
2 /
68
31
KGY-M94A7-00 MAGNET
2 /
69
32
90KA0-001G60 AC SERVO MOTOR ASSY
1 B
Í
70
33
KHT-M6535-A0 SENS. CUT OPEN ASSY
1 B
Í
71
34
KHT-M6535-B0 SENS. CUT CLOSE ASSY
1 B
Í
72
35
KHT-M6538-A0 SENS.SOL.DEFECT ASSY
1 B
Í
73
36
KHT-M6538-B0 PNP CHANGER ASSY
1 B
Í
74
37
90990-41J042 COLLAR
6 75
38
91312-03008 BOLT HEX.SOCKET HEAD
1
M3X8
76
8
1
POT-Head Assy
PSC
KHT-1101
4
5
10
8
7
7
8
6
1
3
2
12
9 11
8
6
7
8
2
POT-Adpter, Ext.
PSC
