KHT -1004 2 8 10 3 1 5 4 14 6 9 1 1 7 13 12 5 12 7 7 PCB Vacuum (Op.) Conveyor Unit
KHT-1004
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
KHT-M93B0-C0 EXP CONV.EXT-RF,LR
1 /
Í
39
KHT-M6528-A0 SENS. CV1R CV3L ASSY
2
B
Í
2
KHT-M93B0-D0 EXP CONV.EXT-LF,RR
1
/
Í
40
KHT-M6528-B0 SENS. FIX CV. M ASSY
1
B
Í
3
KHT-M9309-A0 PLATE TENSION,PULLY
2 /
41
KHT-M6529-A0 SENS. CV1L CV3R ASSY
1
B
Í
4
KHT-M9309-B0 BASE TENSION,PULLY
2 /
42
$TS4-M5 JOINT
2
5
KHT-M9309-01 PLATE,PULLY CONV.
2 /
43
$US4 JOINT
2
6
KHT-M9310-02 BRKT.,COLLAR
1 /
Í
44
91312-03006 BOLT HEX.SOCKET HEAD
11
M3X6
7
KHT-M9311-00 PULLEY 1,MOTOR
1
/
45
91312-04006 BOLT HEX.SOCKET HEAD
6
M4X6
8
KHT-M9312-00 SPLINE
1
/
Í
46
91312-05010 BOLT HEX.SOCKET HEAD
2
M5X10
9
KHT-M9314-11 TRANSFER BELT W3L
2
E
47
91312-05012 BOLT HEX.SOCKET HEAD
2
M5X12
10
KHT-M9113-00
COUPLING
1 /
48
92902-03200 WASHER PLAIN
11
11
KV1-M9140-A0 PULLEY CONV.ASSY.
4 A
49
92902-04200 WASHER PLAIN
6
12
KG2-M9108-11 COLLAR,CONVEYOR
1 /
50
KGK-M9170-00 MOTER
1 /
13
KHT-M9309-C0 NUT PLATE
2 /
51
14
KGA-M9113-00 GUIDE 1,END
1 /
Í
52
15
KGA-M9114-00 GUIDE 2,END
1 /
Í
53
16
KGJ-M9118-00 GUIDE 1,END
1 /
Í
54
17
KGJ-M9119-00 GUIDE 2,END
1 /
Í
55
18
KGT-M910A-00 BELT(231-3GT-9)
1
/
Í
56
19
KGT-M9135-00 PULLEY 1,SPLINE
1
/
Í
57
20
KGT-M9193-00 NUT PLATE
4
/
58
21
KGY-M9140-A0 PULLEY,CONV. ASSY
4 A
59
22
KH2-M9105-11 PULLEY,MOTOR:P30-3GT
2 /
60
23
91312-03010 BOLT HEX.SOCKET HEAD
4
M3X10
61
24
KHT-M9326-10 BRKT.,SENSOR
3
LF,RR
/
62
25
91312-04008 BOLT HEX.SOCKET HEAD
10
M4X8
63
26
98702-04010 SCREW FLAT HEAD
4
M4X10
64
27
92902-04200 WASHER PLAIN
4 65
28
92A08-04306 SET SCREW M4X6
4 66
29
92902-04600 WASHER PLAIN
12 67
30
KGK-M9172-00 GEAR HEAD
1 /
68
31
91312-04050 BOLT HEX.SOCKET HEAD
4 69
32
91312-04010 BOLT HEX.SOCKET HEAD
8 70
33
KHT-M9326-00 BRKT.,SENSOR
3
RF,LR
/
71
34
KHT-M9371-01 PLATE,STOPPER
1
RF,LR
/
72
35
KHT-M9371-10 PLATE,STOPPER
1
LF,RR
/
73
36
KHW-M9272-00 STOPPER,EXIT
1 /
74
37
KHY-M9273-00 CYLINDER
1 /
75
38
KHY-M9284-00 PLATE,STOPPER
1 /
76
7
6
EXP Transport
Conveyor Unit
KHT-1004
2
8
10
3
1
5
4
14
6
9
11
7
13
12
5
12
7
7
PCB Vacuum (Op.)
Conveyor Unit
KHT-1004
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
KHT-M9400-00 PCB VACUUM ASSY
1 /
Í
39
2
KGY-M94A2-00 BLOCK,SUPPORT
2
/
Í
40
3
KGY-M94A3-00 VACUUM PAD
1 /
41
4
KGY-M94A5-00 VACUUM PAD
2 /
42
5
KGY-M94A7-00 MAGNET
2 /
43
6
KGY-M94A8-00 DOG
1 /
44
7
90990-43J009 PIN
2
45
8
90990-29J014 SHIM
10
46
9
91312-03006 BOLT HEX.SOCKET HEAD
2
M3X6
47
10
91312-04030
BOLT HEX.SOCKET HEAD
4
M4X30
48
11
91312-08012 BOLT HEX.SOCKET HEAD
2
M8X12
49
12
98702-04012 SCREW FLAT HEAD
2 50
13
99480-05016 PIN PARALLEL
1 51
14
99480-06014 PIN,PARALLEL
1 52
15 53
16 54
17 55
18
56
19
57
20
58
21 59
22 60
23 61
24 62
25 63
26 64
27 65
28 66
29 67
30 68
31 69
32 70
33 71
34 72
35 73
36 74
37 75
38 76
7
7
PCB Vacuum (Op.)
Conveyor Unit
