KHT-1004
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
KHT-M7231-00 PLATE,VALVE
1 /
39
2
KHT-M7232-A0 DISP. VALVE ASSY
1
B
40
3
KHT-M7233-01 SEAL,DISP. PRESSURE
1 /
41
4
KHT-M7234-00 PRESSURE GAGE
1 /
42
5
KHT-M7235-00 BRKT.,VACUUM VALVE
1 /
43
6
KHT-M7236-00 VALVE,125A
1 A
44
7
KHT-M7237-00 VACUUM UNIT
1
A
45
8
KGJ-M3245-01 REGULATOR
1
/
46
9
KGR-M9933-00 INLINE FILTER
1
E
47
10
KHW-M8597-00 BRACKET,GAUGE
1 /
48
11
$KM-11 MUFFLER
1
49
12
$SL4-M5 JOINT
1
50
13
$SL4-01 JOINT
2
51
14
$SL6-01 JOINT
4
52
15
$TS6-01 JOINT
1
53
16
$TS8-02 JOINT
1
54
17
$UL6M JOINT
2
55
18
$ULA6 JOINT
2
56
19
$ULA6M JOINT
1
57
20
$ULAD6-4 JOINT
1
58
21
$ULAD8-6 JOINT
1
59
22
$ULAD10-8 JOINT
2
60
23
$USD8-6 JOINT
1
61
24
$UT4M JOINT
1
62
25
$UT8 JOINT
1
63
26
91312-03020 BOLT,HEX.SOCKET HEAD
2
M3X20 64
27
91312-03030 BOLT,HEX.SOCKET HEAD
2
M3X30 65
28
91312-04008 BOLT HEX.SOCKET HEAD
4
M4X8 66
29
91312-04010 BOLT HEX.SOCKET HEAD
2
M4X10 67
30
91312-05008 BOLT HEX.SOCKET HEAD
1
M5X8 68
31
98902-03006 SCREW BINDING HEAD
2
M3X6 69
32
92902-04600 WASHER PLAIN
4
70
33
71
34
72
35
73
36
74
37
75
38
76
8
4
Syringe-Dispence Supply
PSC
KHT-1101
8
5
FX-axis Sensor,Cable Duct / Distance Sensor
PSC
13
12
3
8
18
17
21
25
24
12
14
14
23
22
12
16
21
15
20
19
13
5
12
3
6
7
2
8
10
12
14
12
13
14
12
4
9
9
11
1
7
6
11
38
for Pot
for Syringe
38
34
35
35
32
33
36
28
29
30
27
37
26
31
38
39
40
KHT-1101
