YSP_mpl_je.pdf - 第73页

KHT -1004 16 14 15 17 18 5 19 2 2 1 25 23 1 25 23 20 26 28 13 21 24 22 26 3 4 6 7 1 1 12 8,9 29 7 27 27 28 28 9 1 Control Box Control Box

100%1 / 81
KHT-1101
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
KHT-M7204-00 BRKT. UP,FX TAPE
1 /
Í
39
KHT-M7339-00 CARRY BRKT. FX
1 /
2
KHT-M7204-50 BRKT. LOW,FX TAPE
1
/
Í
40
KHT-M7395-00 CARRY BRKT. FX
1
/
3
KHT-M7205-01 PLATE,NUT FX
2 /
Í
41
4
KHT-M7221-00 BRKT.,FX DUCT
1 /
Í
42
5
KHT-M7222-00 DUCT CABLE,FX
1 /
Í
43
6
KHT-M7223-01 TAPE 1,FX DUCT
1 /
Í
44
7
KHT-M7224-01 TAPE 2,FX DUCT
1
/
Í
45
8
KHT-M7225-00 TAPE 3,FX DUCT
1
/
Í
46
9
90990-01J032 BOLT,HEX.SOCKET HEAD
4
47
10
91312-04010 BOLT HEX.SOCKET HEAD
4
M4X10
48
11
98902-03005 SCREW BINDING HEAD
4
M3X5
49
12
$NK-3N NYLON CLIP
19 50
13
90990-11J001 SCREW PAN HEAD W/W
8 51
14
90990-11J003 SCREW,PAN HEAD W/W
13 52
15
KHT-M7241-00 BRKT.,SENSOR
1 /
Í
53
16
KHT-M7242-00 COVER,SENSOR
1 /
54
17
KHT-M7243-00 BRKT. 1,HNS.
1 /
Í
55
18
KHT-M7244-00 BRKT. 2,HNS.
1
/
Í
56
19
KHT-M7245-01 STAY,SENSOR R
1
/
57
20
KHT-M653C-A0 SENSOR SOL.DET.ASSY
1
B
Í
58
21
91312-04006 BOLT HEX.SOCKET HEAD
4
M4X6
59
22
91312-04010 BOLT HEX.SOCKET HEAD
2
M4X10
60
23
91312-05010 BOLT HEX.SOCKET HEAD
2
M5X10
61
24
98902-03010 SCREW BINDING HEAD
2
M3X10
62
25
90990-12J001 SCREW BIN.HEAD W/W
2 63
26
KHT-M66JB-00 HNS,SOL.DET.SENSOR 1
1 A
Í
64
27
KHT-M7385-00 BRKT.,FP SENSOR
1 /
Í
65
28
KHT-M7390-00 BRACKET,FP BELT
1 /
Í
66
29
KHT-M7391-00 NUT PLATE
1 /
Í
67
30
KHT-M7392-00 FITTING,BELT
1 /
Í
68
31
KHT-M6531-A0 SENSOR FX ORG ASSY
1 B
Í
69
32
KHT-M6531-B0 SENSOR FX SAFE ASSY
1 B
Í
70
33
KHT-M6531-C0 SENS. FX CENTER ASSY
1 B
Í
71
34
91312-03012 BOLT,HEX.SOCKET HEAD
4
M3X12
72
35
91312-05014 BOLT HEX.SOCKET HEAD
4
M5X14
73
36
92902-03600 WASHER PLAIN
6 74
37
98502-03006 SCREW PAN HEAD
6
M3X6
75
38
91312-05012 BOLT HEX.SOCKET HEAD
4
M5X12
76
8
5
FX-axis Sensor,Cable Duct / Distance Sensor
PSC
KHT-1004
16
14
15
17
18
5
19
2
2
1
25
23
1
25
23
20
26
28
13
21
24
22
26
3
4
6
7
11
12
8,9
29
7
27
27
28
28
9
1
Control Box
Control Box
KHT-1004
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
KJJ-M411B-00 BRACKET 2
2 /
37
2
KJJ-M411A-00 PLATE
2
/
38
3
KJJ-M4119-00 BRACKET 1 FILTER
1 /
39
4
KJJ-M4120-00 BRACKET 2 FILTER
1 /
40
5
KJJ-M4510-02 MOTHER BOARD ASSY
1 /
Í
41
6
KHN-M5840-00 SERVO BOARD ASSY
1 B
r
42
7
KHN-M5840-80 SERVO BOARD ASSY
2 B
r
43
8
KHL-M4209-01 SYSTEM UNIT ASSY
1
S.T.D
B
r
44
9
KHL-M4209-21 SYSTEM UNIT ASSY
1
IT O/P
B
r
45
10
46
11
KHL-M441H-23 VISION BOARD ASSY
1 B
r
47
12
KHN-M4530-65 REMOTE IF BOARD ASSY
1 B
r
48
13
KJJ-M5880-00 DRIVER POWER ASSY
1 B
r
49
14
KJJ-M4454-01 RAS BOARD ASSY
1 B
Í
50
15
KJJ-M4250-00 BACKPLANE BOARD ASSY
1 B
Í
51
16
KHL-M4255-00 FLASH DISK
1 B
Í
52
17
KGS-M5303-00 SW POWER DC5
1 B
Í
53
18
KGS-M5303-10 SW POWER DC12
1 B
Í
54
19
KJJ-M4186-00 FAN MOTOR ASSY
1
B
Í
55
20
KJJ-M4186-10 FAN MOTOR ASSY
1
B
Í
56
21
KJJ-M4186-20
FAN MOTOR ASSY
1 B
Í
57
22
KJJ-M53A9-10 FILTER
1 /
58
23
KJJ-M53A9-20 FILTER
2 /
59
24
KJJ-M53E9-10 TAPE
1 /
60
25
KJJ-M53E9-20 TAPE
2 /
61
26
91312-04006 BOLT HEX.SOCKET HEAD
8
M4X6 62
27
90166-12JA10 SCREW,PAN HEAD
4
63
28
97602-04308 SCREW,PAN HEAD W/W
63
64
29
KHN-M5840-B0 SERVO BOARD ASSY
1
S.T.D
B
r
65
KHN-M5803-80 SERVO BOARD ASSY
1
PSC O/P
B
r
66
KHN-M5840-80 SERVO BOARD ASSY
1
PSC O/P Syringe
B
r
67
30
68
31
69
32
70
33
71
34
72
35
73
36
74
9
1
Control Box
Control Box
