2 3 Feeder Holder YG 60 Feeder Holder KHY/KJV -1 11 1 28 1 1 16 17 23>35 28 15 14 5 12 23 29 24 10 10 21 28 27 31 23 29 24 27 31 9 30 25 7 6 2 22 29 20 8 19 28 22 29 32 32 32 32 26 13 13 26 22 29 4 3 1 22 29 32 18 32 …
1
3
Feeder Holder YS 60
Feeder Holder
KHY/KJV-1111
28
40
47
5
50
37
4
34,35
43
1
45
45
47
36
12
17
60
60
56
56
55
37
2
41
53
55
6
6
7
51
15
15
10
9
63
22
9
10
8
7
11
17
38
38
46
55
56
51
18
42
48
8
33
39
54
56
55
37
3>2
41
53
33
19
20
23
39
54
24
64
50
58
43
45
59
46
34,35
34,35
27
61
62
45
57
25
29
31
32
30
27
44
49
43
21
49
52
59
46
26
21
61
57
25
58
52
26
17
13(15)
14(16)
17
OLD
OLD
Fig 1
21
OLD
Fig 2
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KHY-M3401-01 PLATE,FEEDER 60 1
2 KHY-M3405-00 STAND 1 1
2-1 KHY-M3405-S0 STAND 1/2 SET 1 (2010/4/5) MG30148 OK
3 KHY-M3406-00 STAND 2 1
3-1 delete (2010/4/5) MG30148
4 KHY-M340C-01 PLATE,FRONT 2
5 KHY-M371R-00 RAIL GUIDE 12P 5
6 KHY-M340F-00 BRACKET,BOARD 2
7 KHY-M4476-15 FDR.CTRL.BOARD ASSY 2
7-1 KHY-M4476-16 FDR.CTRL.BOARD ASSY 2 without pnp Changer (2008/12/27) MEY0101 NG
8 KHY-M37E1-00 LIGHT GUIDE 4
9 KHY-M37E1-10 LIGHT GUIDE,L 2
10 KHY-M37E1-20 LIGHT GUIDE,R 2
11 KHY-M340G-00 SHAFT GUIDE 2
12 KHY-M340H-01 PLATE,INDICATOR 1
13 KHY-M349J-00 LABEL,FEEDER POSI. 1 1-30
13-1 Delete (2008/12/27) MEY0111
14 KHY-M349J-10 LABEL,FEEDER POSI. 1 31-60
14-1 Delete (2008/12/27) MEY0111
15 KHY-M349J-20 LABEL,FEEDER POSI. 1 101-130
15-1 KHY-M349J-40 LABEL,INDICATOR 1 (2008/12/27) MEY0111 OK
16 KHY-M349J-30 LABEL,FEEDER POSI. 1 131-160
16-1 Delete (2008/12/27) MEY0111
17 KHY-M379K-00 LABEL,LED POSI. 2
17-1 KHY-M379K-01 LABEL,LED POSI. 2 (2008/12/27) MEY0111 OK
18 KHY-M340J-00 PLATE,CONNECTOR 1
19 KHY-M66TE-00 HNS,F.CTRL - FDR. 60
20 KHY-M372M-00 SCREW,STAD 120
21 KHY-M340K-01 BRACKET,MANIFOLD 1 Fig 1
21-1 KHY-M340K-02 BRACKET,MANIFOLD 1 Fig 2 (2010/4/7) MG30164 NG
21-2 KHY-M340K-03 BRACKET,MANIFOLD 1 (2011/8/22) MH60104 NG
22 KHY-M372R-00 GUIDE,FEEDER UNDER 5
23 KHY-M372P-00 SUPPORT,LEVER 60
24 KHY-M372S-01 SPRING,SUPPORT 60
25 KHY-M372T-00 BRKT.,SUPPORT 2 7
25-1 Delete (2008/12/26) MEY0099
26 KHY-M342T-00 BRKT.,SUPPORT 3 1
26-1 Delete (2008/12/26) MEY0099
27 KHY-M340L-01 COVER,PLATE 1
27-1 Delete (2008/12/26) MEY0099
28 KHY-M340N-01 COVER,BOARD 2
29 KHY-M3411-00 MANIFOLD 1
29-1 Delete (2010/4/7) MG30164
30 K40-M8598-00 PLUG 1 1
30-1 Delete (2010/4/7) MG30164
31 $TSH8-01 JOINT 1
31-1 Delete (2010/4/7) MG30164
32 $TSS4-01 JOINT 6
32-1 Delete (2010/4/7) MG30164
33 KHY-M34J1-00 BLOCK,FEEDER POSI. 2
34 KHY-M3430-10 LABEL,FEEDER 60-12P 1 1-60
35 KHY-M3430-20 LABEL,FEEDER 60-12P 1 101-160
36 99480-06020 PIN,PARALLEL 4
37 99480-06012 PIN,PARALLEL 6
37-1 99480-06012 PIN,PARALLEL 4 (2008/10/9) ME00028
38 99480-04012 PIN,PARALLEL 4
38-1 99480-04012 PIN,PARALLEL 2 (2008/10/9) ME00028
39 91312-08020 BOLT HEX.SOCKET HEAD 6 M8X20
40 91312-06020 BOLT HEX.SOCKET HEAD 4 M6X20
41 91312-06018 BOLT HEX.SOCKET HEAD 4 M6X18
42 91312-06016 BOLT HEX.SOCKET HEAD 4 M6X16
43 91312-06012 BOLT HEX.SOCKET HEAD 18 M6X12
44 91312-04010 BOLT HEX.SOCKET HEAD 4 M4X10
44-1 Delete (2008/10/9) ME00028
45 91312-04008 BOLT HEX.SOCKET HEAD 8 M4X8
45-1 91312-04008 BOLT HEX.SOCKET HEAD 12 M4X8 (2008/10/9) ME00028
46 91312-03018 BOLT HEX.SOCKET HEAD 16 M3X18
46-1 91312-03018 BOLT HEX.SOCKET HEAD 32 M3X18 (2008/10/9) ME00028
47 91312-03016 BOLT HEX.SOCKET HEAD 12 M3X16
48 91312-03010 BOLT HEX.SOCKET HEAD 4 M3X10
49 91312-03006 BOLT HEX.SOCKET HEAD 12 M3X6
49-1 91312-03006 BOLT HEX.SOCKET HEAD 20 M3X6 (2008/10/9) ME00028
50 98702-03006 SCREW FLAT HEAD 90
51 98902-03006 SCREW BINDING HEAD 16
52 98902-03004 SCREW BINDING HEAD 32
53 92902-06200 WASHER PLAIN 4
54 92902-08600 WASHER PLAIN 6
55 $NK-3N NYLON CLIP 4
55-1 $NK-3N NYLON CLIP 10 (2008/10/9) ME00028
56 90990-11J003 SCREW,PAN HEAD W/W 4
56-1 90990-11J003 SCREW,PAN HEAD W/W 10 (2008/10/9) ME00028
57 KHY-M340U-00 PLATE,COVER 1 1
57-1 Delete (2008/12/26) MEY0099
58 KHY-M340V-00 PLATE,COVER 2 1
58-1 Delete (2008/12/26) MEY0099
59 KHY-M6187-00 FAN MOTOR ASSY 4
60 KHY-M379L-00 LABEL,LED 2
61 KV8-M3758-00 SEAL(DUMP) 2
62 90990-42J047 JOINT 2 (2010/4/7) MG30164
2
3
Feeder Holder YG 60
Feeder Holder
KHY/KJV-1111
28
11
16
17
23>35
28
15
14
5
12
23
29
24
10
10
21
28
27
31
23
29
24
27
31
9
30
25
7
6
2
22
29
20
8
19
28
22
29
32
32
32
32
26
13
13
26
22
29
4
3
1
22
29
32
18
32
33
OLD
34
OLD
19
20
6
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KJV-M3401-A0 FEEDER PLATE ASSY.60 1
2 KJV-M3401-00 PLATE,FEEDER 60 1
2-1 KJV-M3401-01 PLATE,FEEDER 60 1 (2010/1/8) MG10013 OK
3 $BF4BU JOINT 60
4 KJV-M3407-A0 JOINT ASSY 60
5 KJV-M3402-00 GUIDE 1,TAPE 1
6 KJV-M3403-00 GUIDE 2,TAPE 1
6-1 KJV-M3403-01 GUIDE 2,TAPE 1 (2010/1/8) MG10012 NG
7 KJV-M3404-00 GUIDE 3,TAPE 1
8 KJV-M3405-00 STAND,1 1
9 KJV-M3406-00 STAND,2 1
10
KJV-M3408-01 BRACKET,VALVE 1 Height 37mm (2010/5/25) MG50094 NG
KJV-M3408-00 BRACKET,VALVE 1 Height 33mm
11 KJV-M3409-00 COVER,VALVE 1
11-1 KJV-M3409-01 COVER,VALVE 1 (2010/2/10) MG20030 OK
12 KJV-M3410-00 VALVE ASSY,60-F 1
13 KJV-M3417-00 GUIDE,4 2
14 KHY-M3411-00 MANIFOLD 1
15 K40-M8598-00 PLUG 1 1
16 $TSH8-01 JOINT 1
17 $TSS4-01 JOINT 6
18 KHY-M3430-10 LABEL,FEEDER 60-12P 1
19 KGS-M3E10-00 GUIDE TAPE BRACKET,R 1
19-1 KJV-M3411-00 GUIDE TAPE BRACKET,R 1 (2010/1/8) MG10012 NG
20 KGS-M3E11-00 GUIDE TAPE BRACKET,L 1
20-1 KJV-M3412-00 GUIDE TAPE BRACKET,L 1 (2010/1/8) MG10012 NG
21 91312-03006 BOLT HEX.SOCKET HEAD 6 M3X6
22 91312-04008 BOLT HEX.SOCKET HEAD 6 M4X8
23 91312-04010 BOLT HEX.SOCKET HEAD 8 M4X10
24 91312-04020 BOLT HEX.SOCKET HEAD 2 M4X20
25 91312-06010 BOLT HEX.SOCKET HEAD 4 M6X10
26 91312-06022 BOLT HEX.SOCKET HEAD 4 M6X22
27 91312-08020 BOLT HEX.SOCKET HEAD 6 M8X20
28 90990-12J001 SCREW BIN.HEAD W/W 12
29 92902-04200 WASHER PLAIN 10
30 92902-06200 WASHER PLAIN 4
31 92902-08600 WASHER PLAIN 6
32 90172-00J040 WASHER EXTL.TOOTHED 10
33 KGA-M37P0-00 VALVE KIT 24 (Spare)
34 KHY-M3410-00 MANIFOLD ASSY 1 1
35 92012-04010 BOLT .BUTTON HEAD 4 (2011/6//29) MH30128 OK
3
3
Feeder Holder YS 24
Feeder Holder
KHY/KJV-1111
23
31
21
28
51
52
53
14
16
49
49
15
15
41
36
26
9
34
36
9
41
36
43
46
2
3
43
38
26
22
16
6
20
31
19
19
33
28
33
18
44
45
17
33
5
4
37
47
27
30
28
35
10
37
26
12
39
12
11
40
29
13
7
8
1
27
21
48
24
25
54
54
42
32
50
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KJH-M3401-01 PLATE, FEEDER 12-24 1
2 KKJ-M3405-01 STAND 1 1
3 KKJ-M3406-01 STAND 2 1
4 KJH-M340F-02 BRACKET, BOARD 1
5 KJH-M340H-02 PLATE, INDICATOR 1
6 KJH-M340J-00 PLATE, CONNECTOR 1
7
KJH-M340K-02 BRACKET 1, MANIFOLD 1 L, R
KJH-M340K-11 BRACKET 2, MANIFOLD 1 R-With Tape Cutter
8 KJH-M340N-02 COVER, BOARD 1
9 KHY-M34J1-00 BLOCK, FEEDER POSI. 2
10 KHY-M371A-01 PLATE, FRONT 1
11 KHY-M371B-00 SHAFT GUIDE 1
12 KHY-M371R-00 RAIL GUIDE 12P 2
13 KHY-M372M-00 SCREW, STAD 48
14 KHY-M372P-00 SUPPORT, LEVER 24
15 KHY-M372R-00 GUIDE, FEEDER UNDER 2
16 KHY-M372S-01 SPRING, SUPPORT 24
17 KHY-M349J-40 LABEL, INDICATOR 1
18 KHY-M379K-01 LABEL, LED POSI. 1
19 KHY-M37E1-00 LIGHT GUIDE 3
20 KHY-M4476-06 FDR. CTRL. BOARD ASSY 1
21 KHY-M6187-00 FAN MOTOR ASSY 2
22 KHY-M66TE-00 HNS, F. CTRL - FDR. 24
23 KV8-M3758-00 SEAL DUMP 1
24 KJH-M340M-00 COVER PLATE 1 non Tape Cutter MFY0118-2009/12/24
25 90990-12J001 SCREW, BIN HEAD W/W 3 non Tape Cutter
26 99480-06012 PIN, PARALLEL 8
27 99480-06020 PIN, PARALLEL 4
28 91312-03006 BOLT HEX. SOCKET HEAD 4
29 91312-03010 BOLT HEX. SOCKET HEAD 2
30 91312-03016 BOLT HEX. SOCKET HEAD 6
31 91312-03018 BOLT HEX. SOCKET HEAD 14
32 91312-04006 BOLT HEX. SOCKET HEAD 4
33 91312-04008 BOLT HEX. SOCKET HEAD 10
34 91312-06012 BOLT HEX. SOCKET HEAD 9
35 91312-06016 BOLT HEX. SOCKET HEAD 4
36 91312-06018 BOLT HEX. SOCKET HEAD 8
37 91312-06020 BOLT HEX. SOCKET HEAD 4
38 91312-08030 BOLT HEX. SOCKET HEAD 6
39 98702-03006 SCREW, FLAT HEAD 36
40 98902-03006 SCREW, BINDING HEAD 6
41 92902-06200 WASHER, PLAIN 4
42 92902-04600 WASHER, PLAIN 4
43 92902-08600 WASHER, PLAIN 6
44 KHY-M379L-00 LABEL, LED 1
45 KHY-M3430-00 LABEL, FEEDER 24-12P 1
46 91312-08060 BOLT HEX. SOCKET HEAD 2
47 99480-04012 PIN, PARALLEL 1
48 KKJ-M3405-S0 STAND, 1/2 SET 1
49 98902-03004 SCREW, BINDING HEAD 16
50 KHY-M3T0X-40 STAY, FIX SLOPE 12X24 1 With Tape Cutter
51 90990-42J047 JOINT 1
52 $USD6-4 JOINT 1
53 $USD8-6 JOINT 1
54 98902-04008 SCREW, BINDING HEAD 16
