00197793-03_VD_Support_Media_2.3_EN.pdf - 第11页
Support Media 2. 3 / Software Version Description 05/2016 Edition 11 NOTICE Limitations and requirements for Microsoft SQL server ● Microsoft SQL S erver Express Edit ion is a scaled dow n, free edition of Microsoft SQL …
Support Media 2.3 / Software Version Description 05/2016 Edition
10
3 System Requirements
The following system requirements apply for Support Media 2.3.
3.1 Supported Operating Systems and Database Variants
3.1.1 Server / Database Computer System
Server/Database Computer System
Software (required)
● Preferred
Microsoft Windows Server 2012 R2
Microsoft SQL Server 2008 R2 SP2
1)
/ Express Edition R2 SP2
● Compatible Operating Systems
Microsoft Windows Server 2008 R2 SP1
● Compatible Databases
Microsoft SQL Server 2014 SP1
Microsoft SQL Server 2014 SP1 Express Edition
Microsoft SQL Server 2012 SP3 / Express Edition SP3
Microsoft SQL Server 2008 R2 SP2 / Express Edition R2 SP2
● Required
Microsoft .NET Framework 4.5.2
(64-bit)
(64-bit)
(64-bit)
(64-bit)
(32- and 64-bit)
(32- and 64-bit)
(32-bit)
Hardware (recommended)
● e.g. 2x Intel E5520 2.26 GHz 8MB, 4096 MB RAM
● HDD SATA II 500GB, Optional backup drive (e.g. DVD, DAT)
● 21" monitor (19" monitor at least)
● Optional: Uninterruptible power supply
Table 3-1: Server/Database Computer System
1)
Microsoft SQL Server 2008 R2 SP3 (KB2979597) is compatible.
CAUTION
Discontinued server operating systems and database installations
As of Support Media 2.0 we discontinued the support of the following server operating
systems and database installations:
Operating systems Database installations
● Windows Server 2003 ● SQL Server/Express 2005
● Windows Server 2008 ● SQL Server/Express 2008
● Windows Server 2012
Support Media 2.3 / Software Version Description 05/2016 Edition
11
NOTICE
Limitations and requirements for Microsoft SQL server
●
Microsoft SQL Server Express Edition is a scaled down, free edition of Microsoft SQL
server, which includes the core database engine. While there are no limitations on
the number of databases or users supported, it is limited to using one processor, 1
GB memory and 4 GB database files (10 GB database files from Microsoft SQL
Server Express 2008 R2). These limitations may impact the system performance).
● A 64-bit Microsoft SQL Server edition requires a 64-bit operating system.
A mixed operation of different Microsoft SQL server versions (e.g. SQL 2008 R2 / SQL
2012 / 2014) is not supported.
3.1.2 Client Computer System
Client Computer System
Software (required)
● Preferred
Microsoft Windows 8.0
● Compatible
Microsoft Windows 10
Microsoft Windows 7 SP1
● Required
Microsoft .NET Framework 4.5.2
(64-bit)
(64 bit)
(32- and 64-bit)
Hardware (recommended)
● e. g. 1x Core 2 Duo E8500, 4096 MB RAM
● HDD SATA II 250GB
● 21" monitor (19" at least) with a screen resolution of at least
1024 x 1280 pixel (small fonts)
● Powerful graphics board with 256 MB RAM
Table 3-2: Client Computer System
CAUTION
Discontinued Client Operating Systems
As of Support Media 2.0 we discontinued the support of the following client operating
systems:
● Windows XP
● Windows Vista
● Windows 8.0
Support Media 2.3 / Software Version Description 05/2016 Edition
12
3.2 Products of Release 85 (R85)
Product Release 85
SIPLACE Board Gate Keeper 1.2 SP1
SIPLACE EDM 3.3
SIPLACE Explorer 3.3
SIPLACE Feeder Manager 3.0 SP1
SIPLACE LED Pairing Controller 1.0 SP2
SIPLACE License Manager 4.1
SIPLACE Line Monitor 4.1
SIPLACE Material Manager 2.3
SIPLACE OIB 4.3
SIPLACE OIS/SIS 13.1
SIPLACE Order Manager 1.2
SIPLACE Performance Monitor 1.5 SP1
SIPLACE Pro 13.1
SIPLACE Setup Center 8.1
SIPLACE Station Software 709.1
SIPLACE Support Media 2.3
SIPLACE Traceability 5.1
Table 3-3: Products of Release 85 (R85)
