C-S104-16 0604-001 3 CONT -1 目 次 CONTENTS C-S104-16 基板位置決め基準：手前右基準 C-S104-16 P .C.B. Positioning Reference: Front Right Reference Fig. 6 XY テーブル部 XY T ABLE SECTION Fig. 6-1 X 軸 X Axis Fig. 6-2 Y 軸 Y Axis Fig. 6-3 バックアップテ…
C-S104-16
0604-001
2
USING YOUR EXPLODED ILLUSTRATION
1. Subject
This is the Exploded Illustration for Special Specifications component equipments of Chip
Mounting System. Only the differences from the standard specifications are described.
2. Inquiring
(1) For identification of each part, numbers are placed on illustration pages. These numbers
(Key No.) again appear in the far left column of the part table joined up with the
illustration.
(2) The number shown in the Q’ty column of the part table represents the quantity of certain
part used in the equipment. In case of unit assembly, however, the number represents the
quantity of certain part contained in single unit.
3. Parts Ordering
(1) When ordering parts, be sure to inform us of the following details:
Model Type
Serial No.
Fig. No.
Key No.
PART No.
PART NAME
Quantity
[Example]
4. Miscellaneous
(1) The Exploded Illustration is subject to change without prior notice.
(2) All rights reserved. No part of this work covered by the copyrights hereon may be
reproduced or copied without written permission of the publisher.
Some of the parts shown in the Exploded Illustration could fall into the scope of your
government’s regulations on strategic products. In that case, anybody who intend to
export the product should acquire due authorization.
Key No.91123456S 7890 Fig. 6-4 630 002 3459 SPRING,COMP 4TCM-3100J-2
Model Type Serial No. Fig. No. Key No. PART No. PART NAME Q’ty
C-S104-16
0604-001
3
CONT-1
目 次
CONTENTS
C-S104-16
基板位置決め基準：手前右基準
C-S104-16 P.C.B. Positioning Reference:
Front Right Reference
Fig. 6 XY
テーブル部
XY TABLE SECTION
Fig. 6-1 X
軸
X Axis
Fig. 6-2 Y
軸
Y Axis
Fig. 6-3
バックアップテーブル
Back-up Table
Fig. 6-4
シュート
Chute
Fig. 6-5
基板検出レバー
P.C.B. Detector Lever
Fig. 6-6
シュート駆動部
Chute Driver
Fig. 6-7
シュートカバー
Chute Cover
Fig. 6-8
配線支持部
Wiring Support
Fig. 7 L
コンベア部
L CONVEYOR SECTION
Fig. 7-1
コンベア
Conveyor
Fig. 7-2
コンベア駆動部
Conveyor Driving Section
Fig. 7-3
ドライブシャフト
Driving Shaft
Fig. 7-4
基板検出部、基板ストッパ
P.C.B. Detector, P.C.B. Stopper
Fig. 8 R
コンベア部
R CONVEYOR SECTION
Fig. 8-1
コンベア
Conveyor
Fig. 8-2
コンベア駆動部
Conveyor Driving Section
Fig. 8-3
ドライブシャフト
Driving Shaft
Fig. 8-4
基板検出部、基板ストッパ
P.C.B. Detector, P.C.B. Stopper
Fig. 9
トランスファ部
TRANSFER SECTION
Fig. 9-1
スプライン軸
Spline Shaft
Fig. 9-2
送り位置検出部
Transfar Position Detector
Fig. 9-3
トランスファ駆動部
Transfar Driver
Fig. 9-4
送り竿
Transfer Rod
