C-S104-16 0604-001 56 トランスファ部 TRANSFER SECTION Fig. 9-2 送り位置検出部 T ransfar Position Detector 4 3 2 1 See Fig.9-1 Key No.12 6 7 8 5 9 19 18 17 15 16 10 12 13 14 10 12 13 14 16 15 17 18 19 9 6 7 8 1 2 3 4
MEMO
C-S104-16
0604-001
56
トランスファ部
TRANSFER SECTION
Fig. 9-2
送り位置検出部
Transfar Position Detector
4
3
2
1
See Fig.9-1
Key No.12
6
7
8
5
9
19
18
17
15
16
10
12
13
14
10
12
13
14
16
15
17
18
19
9
6
7
8
1
2
3
4
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
C-S104-16
0604-001
57
9-2
1 630 048 8944 BRACKET(STOPPER) 2 659F--03B-027
2 411 141 4305 WASHER V 6X12.5X1.6 2 FW6
3 411 141 3001 WASHER SPR 6 2 SW6
4 630 000 7923 BOLT,HEX-SCT 2 M6X35
5 630 053 5204 SUPPORT 1 659F--03B-030
6 411 141 4305 WASHER V 6X12.5X1.6 2 FW6
7 411 141 3001 WASHER SPR 6 2 SW6
8 630 000 7886 BOLT,HEX-SCT 2 M6X16
9 411 141 0703 NUT HEX 6 6 M6
10 630 053 5181 PLATE(PHOTO L) 2 659F--03B-028
12 411 141 4305 WASHER V 6X12.5X1.6 4 FW6
13 411 141 3001 WASHER SPR 6 4 SW6
14 630 000 7879 BOLT,HEX-SCT 4 M6X12
15 630 000 0245 SENSOR,PHOTO 6 PHS45, PHS43, PHS47,
PHS104, PHS44, PHS124
659F--03H-004
16 630 000 0269 SENSOR,PHOTO(CONNECTOR) 6 659F--03H-025
17 411 088 9005 WASHER F 3X6X0.5 12 FWS3 F
18 411 086 4408 WASHER SPR 3 12 SW3 F
19 411 162 1604 SCR PAN 3X20 12 M3X20 PAN
