Introduction
Scope of Delivery
24 SIPLACE Traceability 4.1
1.3
1.3 Scope of Delivery
Scope of Delivery
▪ SIPLACE Traceability Basic License V4.x (license only) [00117302]
or
▪ SIPLACE Traceability Upgrade-License V4.x (license only) [00117303]
▪ SIPLACE Traceability Machine Connection (full version [169578] or Upgrade [00169579])
▪ SIPLACE Traceability V4.x Media Package [00117301]:
– 1 Traceability 4.1 CD
▪ SIPLACE NET Support Version 2.0 [00117951]
▪ Basic documents:
– Installation Manual SIPLACE Traceability 4.1 (item no.: 00197718-02 [English])
– This Software Version Description SIPLACE Traceability 4.1
(item no.: 00197717-02 [English, German])
– User Guide SIPLACE Traceability 4.1
(item no.: 00197715-02 [German] / 00197716-02 [English])
Please use the Navigation Guide button of the Support Media Launcher for navigating through the doc-
umentation. The Navigation Guide and all the other documents referred to can be found on the Support
Media DVD.
NOTICE
SIPLACE License Management
It is possible to download the SIPLACE Traceability Media Package from the SIPLACE License
Management website without any further costs.
NOTICE
Accessing the Support Media DVD
Please use the Navigation Guide button of the Support Media Launcher for navigating through
the documentation. The Navigation Guide and all the other documents referred to can be found
on the Support Media DVD.
Traceability Interfaces
SIPLACE Traceability 4.1 25
2
2 Traceability Interfaces
Traceability Interfaces
The traceability data generated in the machine are made available for further processing.
The following options for further processing exist:
Traceability data via OIB
The "OIB Eventing Interface" takes care for the export of traceability data into an advanced processing
subsystem (e.g. MES).
Traceability data in an SQL database
Data in the traceability database can be accessed for viewing via the DBView interface (see Traceability
4.1 User Guide). The traceability SQL database is designed to find the placement data for boards to be
produced. To directly and rapidly locate new traceability data with external subsystems, we recommend
using the event-based OIB interface.To directly and rapidly locate new traceability data with external
subsystems, we recommend using the event-based OIB interface.
Traceability data as XML files in the file system
The data interface (XML) is primarily available for test purposes and should not be used in productive
operations without deleting or moving the data generated, due to the existing limitations of the file sys-
tem.
Data in the traceability database can be accessed for viewing via the DBView interface (see Traceability
4.1 User Guide). The traceability SQL database is designed to find the placement data for boards to be
produced. To directly and rapidly locate new traceability data with external subsystems, we recommend
using the event-based OIB interface.To directly and rapidly locate new traceability data with external
subsystems, we recommend using the event-based OIB interface.
NOTICE
OIB interlocking interface no longer available
The "OIB Interlocking Interface" is replaced by the "OIB Eventing Interface" and will no longer
be available in future versions. A special software adapter will be available to customers who
wish to continue using the discontinued "OIB Interlocking Interface" or who intend to use it for
the long term; however, this does not provide the benefits of the new interface concept. We
therefore recommend that you integrate the new "OIB Eventing Interface". For detailed infor-
mation, refer to the User Guide SIPLACE Traceability 4.1 and the OIB SDK documentation.
NOTICE
Further Information
► For further information about traceability data interfaces, register at http://www.siplace.com
and request the document package.
► If you plan to connect SIPLACE Traceability to your own software interfaces we recom-
mend to contact SIPLACE product management in advance.
Traceability Interfaces
26 SIPLACE Traceability 4.1
