TOOLS CLEANING - Condensation filters, machinery parts, bulk goods

All systems are serially pre-equipped by default with a

ClosedLoop re-treatment processing, provided for both the

cleaning as well as the rinsing fluid.

The model AF30P is specifically designed for industrial part-

cleaning.

The main features of AF20, AF30, AF75

• 200 l (AF20), 300 l (AF30), 750 l (AF75) process chambers

• Short cycle times

• Additional ultrasonic unit (AF30 P)

• Available with washing drum for bulk goods (AF30 P)

• AF75 with external 2 x 1000 l tank system

• One-push button handling - fully automatic

• PLC process control via touch screen

• Short cycle times, high cleaning efficiency

• Load and unload into empty process chamber

• Fully automatic process: cleaning - rinsing - drying

• ClosedLoop recycling of cleaning and rinsing fluid

• Cleaning and rinsing circulation with skimmer fine filtering

• Rinsing circulation with automatic water exchange

• Filter pressure PLC controlled

• Maintenance and operation events PLC controlled

• Available with automatic re-dosage unit

• Stainless steel tubeframe base rack with rugged casing

made of stainless steel

• Simple and quick maintenance

In the fully automatic kolb AF20, AF30 and AF75 systems

the goods are cleaned, rinsed and dried in one single process

chamber, which is empty during the loading and is pressure

flooded with fine filtered cleaning fluid from a separate tank

through a PLC controlled process. After the goods are cleaned

with the pressure flooding AirFlow

technology, the likewise

filtered rinsing water, is pumped into the process chamber from

a separate tank. Drying is operated by a powerful HotSpeed

warm air dryer unit. All systems have a permanent skimmer

filtration for the cleaning and the rinsing circuit. The model AF30

/AF30P is pre-equipped for WPSDIU (see page 12) waste water

treatment

The process chamber of the systems can be used variably for

different requirements:

• Direct turbulence air-in-immersion cleaning in the entire pro-

cess chamber is an ideal process for the cleaning of conden-

sate filters or machine parts.

• Dip cleaning in up to five in the process chamber rotating

wire mesh baskets or in a washing drum (AF30 P) is the

perfect method to wash lathe parts, milled parts or die cast

components.

• AF75 systems which are perfectly suitable for bulk cleaning of

condensation filters also allow the cleaning of external

cyclones, containers

and oven tubings.

AF series: Compressed air in immersion systems

ClosedLoopPowerSpray

Condensate filters

Seho filter

Washing drum

Rotation basket

kolb systems: solid - flexible - safe - smart Further information: www.kolb-ct.com

AF75AF30

NOTES

Whether through government regulations or taxes, or whether

through privatization and thereby commercialization the (dwind-

ling) global freshwater resources will become a more and more

valuable asset. For economical and ecological reasons it is

foreseeable that the cost of fresh water will significantly influence

the value added chain in any production where the dwindling

resource is a needed in higher amounts.

An internal rinsing water (ClosedLoop) processing cycle is inte-

grated as a standard in all kolb PowerSpray

cleaning systems

with two or more separate circuits already. Here, the rinse water

is reprocessed several times before it needs to be replaced.

Then it may be recycled for reuse in special (CrossLoop) water

management modules or processed for the discharge into the

local sewage network, which is only allowed if the contamination

is safely below legal limits.

For both technologies kolb offers innovative, cost efficient and

compact SYMBIO-modules (integrated as a framework module

at the system back) which deliver perfect results.

SYMBIO-modules increase the depth of a cleaning system by

only about 400 - 700 millimeters.

WATER MANAGEMENT - Recycling and disposal

WPCL & WPSD modules: Reducing cost, conserving resources

kolb systems: solid - flexible - safe - smart Further information: www.kolb-ct.com

AQUBE

LH7 with SYMBIO module

SYMBIOmodules

increase

the

cleanin

only about 4

- 7

millimeters.

UBE

LH7 with SYMBIO m

WPSD IU WPSD IUAF30

WPCL IUT3

The WPSD IU SYMBIO modu-
