NOTES 13 Highly efficient, aqueous, ecologically safe Cleaning detergents with TS ® t echnology Sequence 1: Elimination of particle adhesion Sequence 2: De-activation of particles Sequence 3: Filtration / regeneration Sp…

NOTES

Whether through government regulations or taxes, or whether

through privatization and thereby commercialization the (dwind-

ling) global freshwater resources will become a more and more

valuable asset. For economical and ecological reasons it is

foreseeable that the cost of fresh water will significantly influence

the value added chain in any production where the dwindling

resource is a needed in higher amounts.

An internal rinsing water (ClosedLoop) processing cycle is inte-

grated as a standard in all kolb PowerSpray

cleaning systems

with two or more separate circuits already. Here, the rinse water

is reprocessed several times before it needs to be replaced.

Then it may be recycled for reuse in special (CrossLoop) water

management modules or processed for the discharge into the

local sewage network, which is only allowed if the contamination

is safely below legal limits.

For both technologies kolb offers innovative, cost efficient and

compact SYMBIO-modules (integrated as a framework module

at the system back) which deliver perfect results.

SYMBIO-modules increase the depth of a cleaning system by

only about 400 - 700 millimeters.

WATER MANAGEMENT - Recycling and disposal

WPCL & WPSD modules: Reducing cost, conserving resources

kolb systems: solid - flexible - safe - smart Further information: www.kolb-ct.com

AQUBE

LH7 with SYMBIO module

SYMBIOmodules

increase

the

cleanin

only about 4

- 7

millimeters.

UBE

LH7 with SYMBIO m

WPSD IU WPSD IUAF30

WPCL IUT3

The WPSD IU SYMBIO modu-

les use the patented kolb

HME

process for metal pre-

cipitation from alkaline rinsing

waters with high dissolved and /

or undissolved heavy metal

contents such as lead, tin, silver

and copper. The rinse water is

thus treated in such a way that

it can be indirectly disposed into

a public sewage network.

WPCL IUT3

SYMBIO-module for the recycling of heavy metal contami-

nated DI / DM rinse water with CrossLoop technology for all

AQUBE

X systems.

WPCL IU

SYMBIO-module for all AQUBE

systems (except MV8

sTWIN) for the treatment of heavy metal contaminated rin-

sing water to be indirectly discharged (subject to regulatory

approval) into a public sewage network.

WPSD IUAF30

SYMBIO-module for AF30 AirFlow

systems for the

treatment of heavy metal contaminated rinsing water to be

indirectly discharged (subject to regulatory approval) into a

public sewage network.

NOTES

Highly efficient, aqueous, ecologically safe

Cleaning detergents with TS

technology

Sequence 1: Elimination of particle adhesion

Sequence 2: De-activation of particles

Sequence 3: Filtration / regeneration

Special chemicals from the same source

2 3

MultiEx

VR-SP RM

Aqueous alkaline TS

Ready-Mix for e.g. PCBs, ceramic substrates,

misprints, stencils, aluminum, stainless steel etc.

PRODUCT CLEANING

For SMD adhesive, SMD paste, colophonium and flux

MultiEx

N7 CN / RM Aqueous pH-neutral

broadband cleaning and rinsing detergent for

stencils, misprints, aluminum, stainless steel, etc.

MultiEx

B11 CN Aqueous alkaline TS

broad-

band cleaning detergent concentrate for stencils,

misprints, PCBs, aluminum, stainless steel etc.

MultiEx

3D RM Aqueous 3-dimensional TS

detergent ReadyMix cleans DCB-substrates /

PCBs, ceramic substrates, copper, nickel, alumi-

num, stainless steel etc.

MultiEx

Rapid CN Aqueous alkaline cleaning

concentrate especially for cleaning colophonium

and flux from PCBs

TOOLS CLEANING

For flux residues, colophonium, condensate, grease, etc.

Further information about these detergents as well as more spe-

cial cleaners, manual cleaners, particular additives and service

products: www.kolb-ct.com/detergents

All kolb detergents are eco-audit compatible, with VOC reduced

formulations and low odor. They can be used without explosion

protection and offer broadband application, optimum efficiency

as well as a disposal circuit.

ContraFlux

Basic CN Aqueous alkaline

broadband cleaning concentrate for solder frames,

solder carriers, machinery parts and PCB carriers

(for AirFlow

Systems)

CF1 Aqueous alkaline cleaning ReadyMix for

manual cleaning of SMD ovens, wave-soldering

machines, carriers and machinery parts

G50 Aqueous alkaline cleaning ReadyMix for

manual basic cleaning of hard and old residues

from SMD ovens, wave-soldering machines, machi-

nery parts etc.

WipeEx SA120

Aqueous pH-neutral cleaning

ReadyMix for the machine cleaning with fleece for

underscreen cleaning in screen printers

ContraFlux

FM RM Aqueous alcaline

ReadyMix detergent for colophonium and conden-

sates of flux management systems, stainless steel,

etc. (for AirFlow

systems)

WetWipes

Aqueous pH-neutral ready-to-use,

detergent-soaked cleaning tissues for the manual

cleaning of SMD tools

Disposal

All detergents / chemicals supplied by kolb can also

be disposed by kolb. The products for disposal have

to be classified as per their waste classification.

ContraFlux

BC CN Aqueous alkaline

cleaning concentrate especially for cleaning colo-

phonium and flux from carriers, masks, boxes etc.

Disposal

NOTES

The options and accessories range for kolb cleaning systems

offers - from cleaning carrier to reservoir, from storage cart to

pH-value test - almost everything, which makes the cleaning

process easier, faster and more efficient.

Any part of this program can either be installed prior to delivery

or be retrofitted at a later stage at customer site.

ServiceCases SC300 / 400

for a quick and safe process

monitoring of cleaning deter-

gents.

Measured values (scale units):

• Refraction (brix)

• pH value

• Conductance (µS)

Stencil storage cart

The stencil storage cart has a

capacity of five stencils and is

the optimum solution for trans-

port and storing close to the

cleaning system.

The service and storage cart

can be used e.g. for placing of

PCBs into LF-carriers fixed on

the cart.

Flexible carriers

Adapter washing frames for

• Frameless stencils

• PumpPrint stencils

• DEK Vector-Guards

• Misprinted boards

• PCBs

• Squeegees and scrapers

Accessories and special systems

The kolb machinery portfolio includes even more products -

from a basic entry model to „all in one“ systems to specialized

systems e.g. for the external cleaning of cyclones, containers

and tubings to industrial parts cleaning systems. Here you find

some examples:

More systems and information: www.kolb-ct.com

Clever solutions - the answer to customer demands

Compact multi-washer for

industrial parts cleaning

XXL multi-washer for industri-

al parts cleaning

Basket and drum system for

industrial parts cleaning

Semi-automatic system for

filter and carrier cleaning

Dispenser stands, wall hol-

ders, disinfectant

Desktop starter system for

filter and carrier cleaning

AQUBE

PH7

AF30P AF04

AF03 Disinfection technology

AQUBE

PH9
