Issue 03 November 2020 Services Re q uired ASM requires additional machine supply protection with the fitment of an external cir c uit breaker conforming to national/federal regulations. Use the following table to ensure…
Issue 03 November 2020
Installation
Technical Data
ITEM
DESCRIPTION
Ambient Temperature
15 – 35˚C
Ambient Humidity
30 – 70% @ 20 ˚C
Process Temperature Range
+/- 3˚C of ambient within a programmable range of 23 – 28˚C
Process Temperature
Control
+/- 1˚C
Air Delivery System
Recirculating
Cooling Capacity
900W
Temperature sensor
0 – 10vDC (0 - 50 ˚C) Shared output from printer sensor
Refrigerant gas
R134A/0.4Kg
Full Load Current
7A
Start-up current
15A
Voltage
230V +/- 10% (207v to 253v working range)
Recommended circuit breaker
Type C 10A
Frequency
50/60Hz
Short Circuit Current Rating
6kA @ 230V
Power supply cable
Specification
1.65mm² (15AWG) 3-Core, LL113926 CSA SJT 60°C 300v FT2
Power supply cable
connections
L = Brown, N = Blue, E = Green/ Yellow
Internal Power Wiring
0.5mm (22AWG), 600V, 105 ˚C
1.5mm (1.6AWG), 600V, 105 ˚C
Acoustic Noise
<70dB(A) @ 1m
Dimensions
(Height measured from printer top when
installed)
678mm (H) + Beacon, 1000mm (W), 676mm (D)
Weight
73Kg
Condensate
Collected in a container for disposal or diverted directly to a
drainage system where available
Issue 03 November 2020
Services Required
ASM requires additional machine supply protection with the fitment of an external circuit
breaker conforming to national/federal regulations. Use the following table to ensure the
recommended circuit breaker is used.
Voltage
Frequency
Value of Supply Circuit
Breaker
Type of Circuit
Breaker
230V +/- 10%
(207 to 253V)
50/60Hz
10 Amp
C
Transportation
The unit may only be lifted using suitable equipment capable of lifting 100Kg.
Move the unit to the location where it is going to be installed and remove the unit from its
transportation crate along with any accessories. Remove the protective covering.
CAUTION
OVER CURRENT PROTECTION. An over current circuit
breaker protects the machines internal wiring and
components from over heating or catching fire during fault
conditions. Under no circumstances must a circuit breaker
of greater value than 10 Amps be used
WARNING
Connect to a properly earthed/grounded outlet..
CAUTION
FORK LIFTING. The lifting forks must enter under the
machine from either end of the transportation crate only.
Care must be taken to ensure stability at all times.
Issue 03 November 2020
Power Supply Connection
1. Check the integrity of the electrical power supply cable.
2. Test the mains input at the isolated supply is the correct voltage and frequency
before proceeding.
3. Connect to the mains supply.
WARNING
All electrical connections should be carried out by suitably
qualified personnel ensuring relevant rules and regulations
are observed.
WARNING
To reduce the risk of fire, electric shock, or injury:
Connect to a properly earthed/grounded outlet.
Use only as described in the manual.
Isolate from power supply before opening covers.
WARNING
LETHAL VOLTAGE. Dangerous voltages exist within this
equipment. Ensure all electrical covers and main machine
covers are fitted before operating equipment.
WARNING
ELECTRICAL HAZARD. If any damage to the electrical cable
is found the unit must not be connected. Installation is to
cease until inspected by a qualified electrician.
