Advanced High Speed Flexible Mounter 14 SECTION IT EM SPECIFICATION REMARK Feeder t yp e Vib rati on feed er FS -V- SM 4 L ane Fe eding Belt stic k feed er 1 L ane Fe eding (W 10 ㎜ /3.5 ㎜ ) Slim stic k feed er 中 / 大型连接器供…
设备规格及名称
13
SECTION ITEM SPECIFICATION REMARK
Feeder type Tape feeder
SM-08 (8 mm)
[按照功能] IT / Non-IT, [Slot] 1 slot
SMN-08L (8 mm)
[按照功能] IT / Non-IT, [Slot] 2 slots 气压式供料器 (8mm Large Reel 用供料器)
SM-12 (12 mm)
[按照功能] IT / Non-IT, [Slot] 2 slots
SM-16 (16 mm)
[按照功能] IT / Non-IT, [Slot] 2 slots
SM-24 (24 mm)
[按照功能] IT / Non-IT, [Slot] 3 slots
SM-32 (32 mm)
[按照功能] IT / Non-IT, [Slot] 4 slots
SM-44 (44 mm)
[按照功能] IT / Non-IT, [Slot] 5 slots
SM-56 (56 mm)
[按照功能] IT / Non-IT, [Slot] 6 slots
SM-72 (72 mm)
[按照功能] IT / Non-IT, [Slot] 6 slots
SME-08 (8 mm)
[按照功能] IT [Slot] 1 slot 电动式供料器
SME-08L (8 mm)
[按照功能] IT [Slot] 2 slot 电动式供料器 (8mm Large Reel 用供料器)
SME-12 (12 mm)
[按照功能] IT [Slot] 2 slots 电动式供料器
SME-16 (16 mm)
[按照功能] IT [Slot] 2 slots 电动式供料器
SME-24 (24 mm)
[按照功能] IT [Slot] 3 slots 电动式供料器
Advanced High Speed Flexible Mounter
14
SECTION ITEM SPECIFICATION REMARK
Feeder type
Vibration feeder FS-V-SM 4 Lane Feeding
Belt stick feeder
1 Lane Feeding (W10 ㎜/3.5 ㎜)
Slim stick feeder
中/大型连接器供应用 (W8~32mm)
1 step tray feeder FW-1-SM
安装在正面时使用 1 个 tray(横向供应)
安装在背面时使用 2 个 tray(横向、纵向供应)
Multi tray feeder
FW20NS
20 step non-stop
安装在背面时使用 2 个 tray(横向、纵向供应)
请参阅 FW20NS 规格
但，基板宽度为 460mm 以上时每 palle 横向支援 1 个 tray
STF100N
STF100D
安装在背面时使用 2 个 tray(仅横向供应)
请参阅 STF100N, STF100D 规格
但，基板宽度为 460mm 以上时每 palle 横向支援 1 个 tray
传送带宽度为 510mm 时，只使用 1 个 Upward Camera
设备规格及名称
15
SECTION 2 mm 4 mm 8 mm 12 mm 16 mm 20 mm 24 mm 32 mm 40 mm
SM-08-0402
1S
SM-08-2P
SM-08-4P
1S
SM-12
1S 1S 1S
SM-16
1S 1S 1S 1S
SM-24
1S 1S 1S 1S 1S 2S
SM-32
1S 1S 1S 1S 2S 2S
SM-44
1S 1S 1S 1S 2S 2S 2S
SM-56
1S 1S 1S 1S 2S 2S 2S
SM-72
1S 1S 1S 1S 2S 2S 2S
SM-88
1S 1S 1S 1S 2S 2S 2S
SECTION 2 mm 4 mm 8 mm 12 mm 16 mm 20 mm 24 mm 28 mm 32 mm 36 mm 40 mm
SME-08
1S 1S
SME-12
1S 1S 1S
SME-16
1S 1S 1S 1S
SME-24
1S 1S 1S 1S 1S 1S
