设备规 格及名 称 17 SECTION ITEM SPECIFICATION REMARK MODEL PITCH(mm ) WIDTH 2) No. of possessory slot per each feede r 8 mm feed er TF - N ST1005( Tape fe eder ) 2 1 Slot 专用 1005 TF- NST08 (Tap e feeder ) 4 1 Slot TF - N ST08L…
Advanced High Speed Flexible Mounter
16
SME-32
1S 1S 1S 1S 1S 1S 1S 1S 1S
SME-44
1S 1S 1S 1S 1S 1S 1S 1S 1S
SME-56
1S 1S 1S 1S 1S 1S 1S 1S 1S
SECTION ITEM SPECIFICATION REMARK
元件供应装置
Tape feeder
8mm, 12mm, 16mm, 24mm, 32mm, 44mm, 56mm
72mm
Vibration stick feeder Stick part storage width max.108mm
Stack stick feeder Stick part storage width max.60mm
Belt stick feeder Stick part storage width max.149mm
Tray feeder
1 pitch(flat
installation)
Occupied width installed in the feeder base
Multi tray feeder
24 Step auto tray
Tray part storage width max.360 mm
non-stop operation
20 Step auto tray
Tray part storage width max.360 mm
12 Step auto tray
1 台或 2 台联动使用
Shuttle tray feeder 24 Step auto tray
2 magazine, 12 step / 1 magazine
non-stop operation
设备规格及名称
17
SECTION ITEM
SPECIFICATION
REMARK
MODEL PITCH(mm)
WIDTH
2)
No. of
possessory
slot
per each
feeder
8 mm feeder
TF-NST1005(Tape feeder)
2
1 Slot
专用 1005
TF-NST08(Tape feeder) 4 1 Slot
TF-NST08L(Tape feeder)
4
1 Slot
TF-P1005(气压式塑料(vinyl)排放装置 feeder)
2
1 Slot
专用 1005
TF-P08(气压式塑料(vinyl)排放装置 feeder)
4 1 Slot
TF-S1005(
气压式
feeder)
2
1 Slot
专用
1005
TF-S08(气压式 feeder)
4
1 Slot
12 mm feeder
TF-S12(气压式 feeder)
4, 8 3 Slot 2ea x 12mm feeder = 5 slot
16 mm feeder
TF-S16(
气压式
feeder)
4, 8, 12
3 Slot
24 mm feeder
TF-S24(气压式 feeder)
8, 12, 16, 20
4 Slot
2ea x 24mm feeder = 7 slot
32 mm feeder
TF-S32(气压式 feeder)
8, 12, 16, 20, 24, 32 5 Slot
TF-S32-A(
粘附式
Tape feeder)
12
5 Slot
44 mm feeder
TF-S44-L(气压式 feeder)
8, 12, 16, 20, 24
5 Slot
TF-S44-S(
气压式
feeder)
16, 20, 24, 32, 40
5 Slot
56 mm feeder
TF-S56(
气压式
feeder)
8, 12, 16, 20, 24, 32, 40
6 Slot
72 mm feeder
72mm 气压式 feeder
-
-
Stick feeder
Vibration stick feeder
-
8 Slot
Belt stack stick feeder
-
4 Slot
Belt stick feeder - 10 Slot
Tray feeder
1 Stage tray feeder
-
24 Slot
12 Step tray feeder
-
21 Slot
20 Step tray feeder - 35 Slot
24 Step tray feeder
-
29 Slot
Advanced High Speed Flexible Mounter
18
40C tray feeder - 36 Slot
Shuttle tray feeder
-
16 Slot
Reject conveyor
-
-
6 Slot
SECTION
ITEM
SPECIFICATION
REMARK
ANC
Type 37 Hole fix type
Small size hole(24) : N14 ~ N37
Middle size hole(6) : N2, N4, N6, N8, N10, N12
Large size hole(3) : N9, N11, N13
Large size odd type hole(3) : N3, N5, N7
Calibration nozzle hole(1) : N1
驱动方式
Double acting air cylinder
Nozzle
Normal nozzle
CN020
外径
/
内经
:
Φ
0.50/
Φ
0.16 mm, Small size hole
0402
CN030
外径/内经: Φ0.75/Φ0.28 mm, Small size hole
0603~1005
CN040
外径/内经: Φ0.75/Φ0.38 mm, Small size hole
1005~1608
CN065
外径/内经: Φ1.2/Φ0.65 mm, Small size hole
2012~3216, MELF, SOT23
CN140
外径/内经: Φ2.2/Φ1.4 mm, Small size hole
Aluminum electrolytic capacitor (Small)
CN220
外径/内经: Φ3.6/Φ2.2 mm, Small size hole
Aluminum electrolytic capacitor (Medium),SOP, SOJ
CN400N
外径/内经: Φ6.0/Φ4.0 mm, Middle size hole
SOP, TSOP, QFP, PLCC, SOJ, Connector
CN750
外径/内经: Φ9.0/Φ7.5 mm, Middle size hole
QFP (Medium), PLCC (Medium)
CN110
外径/内经: Φ12.7/Φ11.0 mm, Large size hole
QFP (Large), PLCC (Large)
Odd nozzle
CTP200
吸附面积 : 2.0 X 10.0 mm, Large size odd type hole
Connector
CTP400
吸附面积 : 4.0 X 12.0 mm, Large size odd type hole
Connector
Rubber nozzle
CN350R
橡胶外径/外径/内经: Φ3.5/Φ2.2/Φ1.3 mm, Small size hole
CN220, CN440N
CN550R
橡胶外径/外径/内经: Φ5.5/Φ3.0/Φ1.4 mm, Middle size hole
CN750
CN900R
橡胶外径/外径/内经: Φ9.0/Φ5.6/Φ4.0 mm, Large size hole
CN110
Calibration nozzle CNT20
外
径
: Φ13.0 mm, Calibration nozzle hole
System calibration
