SYS-CP842-1.1E 4.Commands CP-842E / CP-842ME System Reference 141 Maintenance Configuration (Continued) C73SC008E-5 Machine Configuration Data (Continued) Automatic Conveyor Width Mail Settings Trace Output Settings Auto…
4.Commands SYS-CP842-1.1E
140 CP-842E / CP-842ME System Reference
Maintenance
Configuration
(Continued)
C73SC008E-4
Loader
Machine Configuration
Data
(Continued)
Loader Settings
Off
On
Set
→ Numeric Keypad
Panel Unloading Time-out Monitoring
Set → Numeric Keypad
Unloading Time-out Limit
Right to Left
Left to Right
Panel Flow Direction
Ignore
Machine Specific Settings
Reset
Accept
Close
Panel Request Signal From Next Machine
Loading Time-out Limit
Question
OK
Cancel
Loader Function
Disabled
Enabled
Enable
Disable
Close
Panel Uploading Timer
No
Yes
Enable 2-panel production?
Run In-Conveyor After Panel Arrival
Signal Tower
Question
OK
Cancel
Signal Tower Display
Waiting to unload to next stage
In production
Parts out warning
Slots with parts out exist
Statistical warning issued
Machine error stopped
Machine stopped due to no parts
Displaying mesage from host
Spare table change
Non-stop loader runing
Non-production processing
Machine stopped due to vision error
Awaiting previous stage panel
Awaiting operation (Servo ON)
Awaiting operator confirmation
Changeover by operator
Automatic Operation ready
Production stopped temporarily
Machine changeover
Conveying panel
Awaiting operation (Servo OFF)
ON
OFF
Close
Signal Tower Display
Red: Flash
Yellow: Flash
Green: Flash
Red: Light
Yellow: Light
Green: Light
Reset All
Buzzer
Settings
Stop error buzzer at control panel.
Production
Operation Mode
: Command name
: Screen name
Production
: Command group
: Continued on the next page
: Press to scroll upwards
Legend
: Press to scroll downwards
( )
: General description
[ ]
: Push button
→
: Displays separate dialog box
SYS-CP842-1.1E 4.Commands
CP-842E / CP-842ME System Reference 141
Maintenance
Configuration
(Continued)
C73SC008E-5
Machine Configuration
Data (Continued)
Automatic Conveyor
Width
Mail Settings
Trace Output
Settings
Auto Conveyor Change
Not Use
Use
Maximum Value → Numeric Keypad
Minimum Value → Numeric Keypad
Width
Error no.
Parameter
Time to Mail Delivery → Numeric Keypad
Comments
Counter Origin
Close
Automatic Width Change
Question
OK
Cancel
Trace Output Settings
Floppy Disk
Hard Disk
Yes
No
Close
Send Trace Data by Mail
Trace Acquisition
Destination
Trace Acquisition
Hard Disk
Floppy Disk
Output Media
Send Mail
Trace Data
Mail Settings
Mail Trace
Mail Error
Close
Mail Server Name (SMTP) → Virtual Keyboard
Return-Address
→ Virtual Keyboard
Mail Error
Comment → Virtual Keyboard
Subject → Virtual Keyboard
Ignore Error Codes
Close
Mail to → Virtual Keyboard
Clear Address
Mail Trace
Machine Ser. No. → Numeric Keypad
Close
Close
Mail to → Virtual Keyboard
Subject
→ Virtual Keyboard
Production
Operation Mode
: Command name
: Screen name
Production
: Command group
: Continued on the next page
: Press to scroll upwards
Legend
: Press to scroll downwards
( )
: General description
[ ]
: Push button
→
: Displays separate dialog box
4.Commands SYS-CP842-1.1E
142 CP-842E / CP-842ME System Reference
Maintenance
Configuration
(Continued)
C73SC008E-6
Machine
Communication
Statistical Processing
Machine Configuration
Data (Continued)
Machine Communication
Bad Mark Information
Edit → Virtual Keyboard
Line Name
Acquire from database.
(under development)
(under development)
Data acquisition time-out setting → Numeric Keypad
Pick-up Count → Numeric Keypad
For Mark Information
Share with Fujitrax Profiler
Action performed when no data is pre-read.
Sequience Skip Settings
Basic Settings
Edit (Host Name) → Virtual Keyboard
Edit (IP Address)→ Virtual Keyboard
Select Host for machine communication
Mark Information Settings
Close
Machine communication
Statistical Processing
Perform Statistical Processing
Pick-up Count → Numeric Keypad
Close
Pick-up count stoppage monitor
Error Count → Numeric Keypad
Machine stoppage error count
Machine Stoppage Settings
Warning Monitor Settings
Pick-up count warning monitor
Error Count → Numeric Keypad
Warning notification error count
Machine Function
Settings
Brightness Adjustment
Auto
Fixed
Change → Numeric Keypad
Reference Value
Fixed
Change → Numeric Keypad
Reference Value
Shutter Speed
Auto
Narrow Camera
Shutter Speed
Close
Wide Camera
Machine Function Settings
Brightness Adj.
Func. Settings
Production
Operation Mode
: Command name
: Screen name
Production
: Command group
: Continued on the next page
: Press to scroll upwards
Legend
: Press to scroll downwards
( )
: General description
[ ]
: Push button
→
: Displays separate dialog box
