SYS-CP842-1.1E 4.Commands
CP-842E / CP-842ME System Reference 179
Right to Left Loader
Command Path: [Maintenance] - [Configuration] - [Loader] - [Right to Left]
Press to select panel conveyance from right to left.
Revision history:
Save Operator Data Manager
Command Path: [Maintenance] - [Operator] - [Data Manager] - [Save]
Press to display the screen at which operator settings can be output.
Revision history:
Servo I/O Check
Command Path: [Maintenance] - [I/O check] - [Servo]
Press to access the screen at which servo related I/O checks can be performed.
Revision history:
Servo Coordinates Position
Command Path: [Position] - [Servo Coordinates]
Press to display the numeric keypad for specification of the coordinates to which the
selected axis (selected at the commands [X-axis] and [Y-axis]) will be moved.
Revision history:
Servo Count Command bar (All Screens)
Command Path: [Servo Count]
Press to display a dialog box where the servo counts for all axis can be viewed in
pulses or mm/degree.
Revision history:
Servo Setup Maintenance
Command Path: [Maintenance] - [Servo Setup]
Press to display the screen at which the servos can be checked.
Revision history:
4.Commands SYS-CP842-1.1E
180 CP-842E / CP-842ME System Reference
Set Ignore After Handy Terminal
Command Path: [Maintenance] - [Configuration] - [Handy Terminal] - [Set Ignore
After]
Press to display the keyboard at which the Ignore after comment can be set. Any
characters that appear after the selected comment are ignored by the Handy Termi-
nal.
Revision history:
Set Ignore Between Handy Terminal
Command Path: [Maintenance] - [Configuration] - [Handy Terminal] - [Set Ignore
Between]
Press to display the keyboard at which the Ignore between comment can be set. Any
characters that are enclosed by the selected comment are ignored by the Handy Termi-
nal.
Revision history:
Signal Tower Machine Configuration Data
Command Path: [Maintenance] - [Configuration] - [Signal Tower]
Press to access the screen at which the signal tower settings can be specified.
Revision history:
Standard I/O check
Command Path: [Maintenance] - [I/O check] - [Standard]
Press to access the screen at which a standard I/O check can be performed.
Revision history:
Start Sequence Production
Command Path: [Production] - [Start Sequence]
Press to display the Numeric Keypad and input the starting sequence.
Revision history:
SYS-CP842-1.1E 4.Commands
CP-842E / CP-842ME System Reference 181
Statistical Nozzle Skip Machine Configuration Data
Command Path: [Maintenance] - [Configuration] - [Statistical Nozzle Skip]
Press to access the Statistical Nozzle Skip Settings screen.
Revision history:
Status Reset Options
Command Path: [Maintenance] - [Options] - [Status Reset]
Press to reset all machine data except calibration and program related data.
Revision history:
Step Production
Command Path: [Production] - [Step]
Press to set the operation mode to Step.
Revision history:
Stop Recovery
Command Path: [Recovery] - [Stop]
Press to set the recovery action to Stop.
Revision history:
System Maintenance
Command Path: [Maintenance] - [System]
Press to access the screen at which system related commands (Date & Time, Network)
can be selected.
Revision history:
System Backup Data Manager
Command Path: [Maintenance] - [Data Manager] - [System Backup]
Press to access the screen at which the system settings can be backed up.
Revision history:
