YSH20_mpl_je.pdf - 第48页

KJX-1 107 Rev . :It had a change without the compatibility . Please be careful at the time of the parts ordering. Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。 No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. P…

100%1 / 79
KJX-1107
7
27
6
5
8
2
13
4
13
10
9
12
11
3
1
8
29
5
6
7
13
14
31
28
25
26
21
22
24
23
39
15
17
18
19
20
16
30
38
33
32
40
35
34
33
40
36
37
9
1
Control Box
Controller
KJX-1107
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
KJX-M4116-00 BRACKET 1,FILTER
1 /
38
KHL-M4255-00 FLASH DISK
1 B
Í
2
KJX-M4117-00 BRACKET 2,FILTER
1
/
39
KJX-M4186-00
FAN MOTOR ASSY
1
B
Í
3
KJX-M53E9-20 TAPE
1 /
40
90166-12JA06 SCREW,PAN HEAD W/W
4
4
KJX-M53A9-20 FILTER
1 A
41
5
KJJ-M53E9-20 TAPE
2 /
Í
42
6
KJJ-M53A9-20 FILTER
2 A
Í
43
7
KJJ-M411A-00 PLATE
2 /
Í
44
8
KJJ-M411B-00 BRACKET 2
2 /
Í
45
9
KJX-M4216-00 BRACKET 1,FILTER
1
/
46
10
KJX-M4217-00
BRACKET 2,FILTER
1 /
47
11
KJX-M53E9-00 TAPE
1 /
48
12
KJX-M53A9-00 FILTER
1 A
49
13
97602-04308 SCREW,PAN HEAD W/W
30 50
14
KJX-M4110-00 BOX ASSY,SERVO C/R
1 /
Í
51
15
KJJ-M4510-02 MOTHER BOARD ASSY
1 B
r
52
16
KJJ-M5880-00 DRIVER POWER ASSY
1 B
r
53
17
KHN-M5840-42 SERVO BOARD ASSY
1 B
r
54
18
KHN-M5803-41 SERVO UNIT ASSY
1 B
r
55
19
KHN-M5840-92 SERVO BOARD ASSY
1 B
r
56
20
KKE-M5840-00 SERVO BOARD ASSY
1
B
r
57
21
KGS-M5303-00 SW POWER DC5
1 /
r
58
22
KGS-M5303-10 SW POWER DC12
1 /
r
59
23
KJJ-M4186-10 FAN MOTOR ASSY
1 B
Í
60
24
KJJ-M4186-20 FAN MOTOR ASSY
1 B
Í
61
25
KJX-M4186-10 FAN MOTOR ASSY
1 B
Í
62
26
KGA-M4187-00 FAN GUARD 119MM
1 /
Í
63
27
KR8-M459L-00 SEAL NAME,5
1 /
64
28
90K41-000710 SEAL,WARNING
1 /
65
29
KJX-M11B0-00 LABEL,CONTROLLER
1 /
66
30
97602-04308 SCREW,PAN HEAD W/W
10 67
31
KJX-M4210-00 BOX ASSY,SYSTEM C/R
1 68
32
KHL-M4209-21 SYSTEM UNIT ASSY
1
S.T.D
B
r
69
33
KJY-M441H-A0 VISION BOARD SET
1
with MULTI CAMERA A2
B
r
70
KJY-M441H-B0 VISION BOARD SET
1
non MULTI CAMERA A2
B
r
71
34
KHN-M4530-56 REMOTE IF BOARD ASSY
1 B
r
72
35
KHN-M4530-36 REMOTE IF BOARD ASSY
1 B
r
73
36
KJJ-M4454-01 RAS BOARD ASSY
1 B
Í
74
37
KJJ-M4250-00 BACKPLANE BOARD ASSY
1 B
Í
75
9
1
Control Box
Controller
KJX-1107
1,2
1,2
4
11
8
5,6
12
15
5,6,7
10
3
9
13
14
10
1
Exterior, etc
Exterior, etc
