12-2-4 12-2 台車 ( 上部 ) CART (UPPER) ｲﾗｽﾄ番号 Ref.No. 部品コード Parts Code 部品名 Parts Name Serial No. 個数 Q'ty 備考 Remarks 同期 Repl. 57 4-149-729-01 ﾛｹｰﾄ ﾋﾟﾝ (2) P PIN (2) (P), LOCATE 2 58 1-789-930-11 ﾀﾞｲｼｬ ｾｲｷﾞｮ ｷﾊﾞﾝ ASSY CAR…

100%1 / 190
12-2-3
12-2
台車 (上部)
CART (UPPER)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
31 4-144-714-01
ﾚｰﾙ
ｽﾛｯﾄ
ﾍﾞｰｽ
(M)
BASE (M), RAIL SLOT
30
32 4-144-715-01
ﾃｰﾌﾞﾙ
TABLE
1
33 4-144-716-01
ﾃｰﾌﾞﾙ
ｻｲﾄﾞ
ﾌﾞﾗｹｯﾄ
(A)
BRACKET (A), TABLE (SIDE)
1
34 4-144-716-11
ﾃｰﾌﾞﾙ
ｻｲﾄﾞ
ﾌﾞﾗｹｯﾄ
(B)
BRACKET (B), TABLE (SIDE)
1
35 4-144-718-01
ﾃｰﾌﾞﾙ
ｻｲﾄﾞ
ｶﾊﾞｰ
COVER, TABLE (SIDE)
2
36 4-144-719-01
ﾀﾞｲｼｬ
ｶﾊﾞｰ
COVER, FLATCAR
1
37 4-144-720-01
ﾛｰﾗ
ﾌｫﾛｱ
ﾎﾙﾀﾞ
HOLDER, ROLLER FOLLOWER
2
38 4-144-721-01
ﾌﾛｰﾃｨﾝｸﾞ
ｺﾈｸﾀ
ﾌﾞﾗｹｯﾄ
BRACKET, FLOATING CONNECTOR
2
39 4-144-722-01
ﾌﾛｰﾃｨﾝｸﾞ
ｺﾈｸﾀ
ﾌﾞﾗｹｯﾄ
(B)
BRACKET (B), FLOATING CONNECTOR
1
40 4-145-354-01
ﾛｯｶｸ
ｼﾁｭｳ
(M4-15)
SUPPORT (M4-15), HEXAGON
6
M4-15
41 4-148-123-01
ﾌｫﾛｱ
ｶﾊﾞｰ
COVER, FOLLOWER
2
42 4-148-124-11
ｶｾｯﾄ
ｶﾊﾞｰ
COVER, CASSETTE
1
43 4-706-726-03
ﾛｯｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M5X8 SUS)
BOLT (M5X8SUS), HEXAGON SOCKET
4
M5X8 SUS
44 7-623-423-07
LW4, TYPE B
LW4, TYPE B
35
LW4
45 7-624-109-04
E
ｶﾞﾀ
ﾄﾒﾜ
5.0
STOP RING 5.0, TYPE-E
4
46 7-682-148-01
+P 3X8
SCREW +P 3X8
62
+P 3X8
47 7-682-160-01
+P 4X6
SCREW +P 4X6
37
+P 4X6
48 7-682-262-04
+K 4X10
SCREW +P 4X10
4
+K 4X10
49 7-682-265-04
+K 4X16
SCREW +P 4X16
6
+K 4X16
50 7-682-561-04
+B 4X8
SCREW +B 4X8
13
+B 4X8
51 7-682-948-01
+PSW 3X8
SCREW +PSW 3X8
6
+PSW 3X8
52 7-683-421-04
ﾛｯｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
4X12
BOLT, HEXAGOB SOCKET 4X12
19
M4X12
53 7-683-423-04
ﾛｯｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
4X16
BOLT, HEXAGOB SOCKET 4X16
2
M4X16
54 7-683-437-04
ﾛｯｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
5X14
BOLT, HEXAGOB SOCKET 5X14
4
M5X14
55 7-683-454-04
ﾛｯｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
6X14
BOLT, HEXAGOB SOCKET 6X14
22
M6X14
56 7-683-419-03
ﾛｯｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
4X8
BOLT, HEXAGOB SOCKET 4X8
150
M4X8
12-2-4
12-2
台車 (上部)
CART (UPPER)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
57 4-149-729-01
ﾛｹｰﾄ
ﾋﾟﾝ
(2) P
PIN (2) (P), LOCATE
2
58 1-789-930-11
ﾀﾞｲｼｬ
ｾｲｷﾞｮ
ｷﾊﾞﾝ
ASSY
CART CONTROL BOARD ASSY
1
- 4-000-028-11
ﾍｲｺｳ
ﾋﾟﾝ
(
ﾌｧｲ
3M6X6)
PIN (DIA. 3M6X6), PARALLEL
78
DIA. 3M6X6
- 4-000-032-01
ﾍｲｺｳ
ﾋﾟﾝ
(
ﾌｧｲ
5X15 H7 SUS)
PIN (DIA. 5X15 H7 SUS)
29
DIA. 5X15 H7 SUS
- 4-000-229-01
ｹｰﾌﾞﾙ
ｸﾞﾗﾝﾄﾞ
(VG M20-1 / K68)
GROUND(VG M20-1 / K68), CABLE
1
VG M20-1 / K68
- 4-701-543-01
ｱｰｽ
ﾒｲﾊﾞﾝ
AMS-550
LABEL (AMS-550), GROUND
8
AMS-550
- 4-706-151-11
ﾊｲｾﾝﾄﾞﾒ
(KR5G5)
CLAMP (KR5G5)
2
- 4-716-434-11
ｲﾝｼｭﾛｯｸ
ﾀｲ
(AB100
ｸﾛ
)
TIE, INSULOCK (AB100 BLACK)
40
- 4-716-435-21
ｲﾝｼｭﾛｯｸ
ﾀｲ
(AB150
ｸﾛ
)
TIE, INSULOCK (AB150 BLACK)
15
- 4-720-479-01
PL
ﾗﾍﾞﾙ
(
ﾕﾋﾞﾊｻﾐｹｲｺｸﾗﾍﾞﾙ
) (
ｴｲｺﾞ
)
LABEL, PL (INSERT CAUTION)
2
- 4-720-755-01
ｲﾄﾞｳ
ﾔｼﾞﾙｼ
ｼｰﾙ
(
ｼﾖｳ
)
SEAL, MOVE ARROW MARK (SMALL)
2
12-3-1
12-3
インテリジェンスカセット用台車内配線（台車制御基板）
INTERNAL WIRING, CART (CART CONTROL BOARD)
CART CONTROL
BOARD
CN 1
1
CN 2
To No.101 Connector
To No.103 Connector
To No.105 Connector
To No.107 Connector
CN 3
CN 4
To No.109 Connector
To No.111 Connector
To No.113 Connector
To No.115 Connector
2
CN 5
CN 6
To No.117 Connector
To No.119 Connector
To No.121 Connector
To No.123 Connector
3
CN 7
CN 8
To No.125 Connector
To No.127 Connector
To No.129 Connector
To No.131 Connector
4
CN 9
CN 10
To No.133 Connector
To No.135 Connector
To No.137 Connector
To No.139 Connector
5
CN 11
CN 12
To No.141 Connector
To No.143 Connector
To No.145 Connector
To No.147 Connector
6
CN 13
CN 14
To No.149 Connector
To No.151 Connector
To No.153 Connector
To No.155 Connector
7
CN 15
CN 16
To No.157 Connector
To (TEST1) & (TEST2)
Connector
8
CN 23
CN 17
To Machine
Connector
9
CCB-17-2
CCB-17
TIMER,
SOLID STATE
(H3Y-4 DC24V)
10
CN 22
11
TB
(LEFT)
TB
(RIGHT)
12
13
