INSTRUCTION MANUAL

Product

website

ALE

Automatic-Feed Soldering Control Unit

This manual corresponds to the following references:

With Solder Wire Perforation:

Without Solder Wire Perforation:

Note: For correct operation, the diameter of the solder wire in use must match the diameter

of the ALE reference purchased.

for wire ø 0.8mm

ALE-908UVB (100 V)

ALE-108UVB (120 V)

ALE-208UVB (230 V)

for wire ø 1.5 m m

ALE-915UVB (100 V)

ALE-115U VB (120 V )

ALE-215UVB (230 V)

for wire ø 1.0mm

ALE-910UVB (100 V) *

ALE-110UVB (120 V) *

ALE-210UVB (230 V) *

for wire ø 1.6 mm

ALE-916UVB (100 V)

ALE-116UVB (120 V )

ALE-216UVB (230 V)

for wire ø 1.2mm

ALE-912UVB (100 V)

ALE-112UVB (120 V )

ALE-212UVB (230 V)

for wire ø 0.38 - 0.4mm

ALE-904UB (100 V)

ALE-104UB (120 V)

ALE-204UB (230 V)

for wire ø 0.70 - 0.78mm

ALE-907UB (100 V)

ALE-107UB (120 V )

ALE-207UB (230 V)

for wire ø 1.14 - 1.27mm

ALE-912UB (100 V)

ALE-112UB (120 V )

ALE-212UB (230 V)

for wire ø 1.80mm

ALE-918UB (100 V)

ALE-118UB (120 V)

ALE-218UB (230 V)

for wire ø 0.45 - 0.56mm

ALE-905UB (100 V )

ALE-105UB (120 V)

ALE-205UB (230 V)

for wire ø 0.80 - 0.82mm

ALE-908UB (100 V )

ALE-108UB (120 V )

ALE-208UB (230 V)

for wire ø 1.50 - 1.57mm

ALE-915UB (100 V)

ALE-115UB (120 V )

ALE-215UB (230 V)

for wire ø 0.60 - 0.64mm

ALE-906UB (100 V)

ALE-106UB (120 V )

ALE-206UB (230 V)

for wire ø 0.90 - 1.10mm

ALE-910UB (100 V )

ALE-110UB (120 V )

ALE-210UB (230 V)

for wire ø 1.60 - 1.63mm

ALE-916UB (100 V)

ALE-116UB (120 V )

ALE-216UB (230 V)

* Available to order on the

JBC Web site. All other

references upon request.

40 mm

50 mm

60 mm

80 mm

100 mm

130 mm

para manuales - negro plano

200 mm

300 mm

Allen Key ø 2.5 ............ 1 unitAllen Key ø 1.5 ............ 1 unit

Power Cord .................... 1 unit

Ref. 0024077 (100V)

0023717 (120V)

0024080 (230V)

Manual ............................ 1 unit

Ref. 0033469

Automatic-Feed Soldering

Control Unit ................... 1 unit

Spanner ......................... 1 unit

Key Set*

for SF / AL ...................... 1 unit

Ref. 0019341

includes:

*Already assembled in ALE Control Unit

Packing List

The following items are included in all references:
