TECHNICAL REFERENCE APPENDIX M37 POWER SUPPLY ENCLOSURE 3.24 Appendix to Micron Technical Manuals Chapter Issue 1 Feb 15 M37SK27 M37SK30 M37SK31 - M37SK35 Pin No. Signal Pin No. Signa l 1 System Button 9 Right Jog Button…
TECHNICAL REFERENCE APPENDIX
M37 POWER SUPPLY ENCLOSURE
Chapter Issue 1 Feb 15 Appendix to Micron Technical Manuals 3.23
M37SK24
M37SK25
M37PL26
Pin No. Signal Pin No. Signal
1 External E Stop Link to Pin 5 4 N/C
2 External E Stop Link to Pin 3 5 External E Stop Link from Pin 1
3 External E Stop Link from Pin 2 6 N/C
1
4
6Way Trident
Pin No. Signal Pin No. Signal
1 E Stop Loop to Pin 5 4 N/C
2 E Stop Loop to Pin 3 5 E Stop Loop from Pin 1
3 E Stop Loop from Pin 2 6 N/C
1
4
6Way Trident
Pin No. Signal Pin No. Signal
1 N/C 6 Cover Interlock
2 Jog Left 7 E Stop Loop Supply
3 Jog Right 8 0V
4N/C 9N/C
5 Power On Monitor
1
9
9 Way D Type
Plug
TECHNICAL REFERENCE APPENDIX
M37 POWER SUPPLY ENCLOSURE
3.24 Appendix to Micron Technical Manuals Chapter Issue 1 Feb 15
M37SK27
M37SK30
M37SK31 - M37SK35
Pin No. Signal Pin No. Signal
1 System Button 9 Right Jog Button
2 System Button 10 Right Jog Button
3 System Lamp 11 Right Jog Button
4 System Lamp 12 Right Jog Button
5 Left Jog Button 13 RSVD (Cat 4)
6 Left Jog Button 14 RSVD (Cat 4)
7 Left Jog Button 15 N/C
8 Left Jog Button
1
15
15 Way D Type
Socket
Pin No. Signal Pin No. Signal
1 USB Supply 3 USB Data +ve
2 USB Data -ve 4 USB Ground
Pin No. Signal Pin No. Signal
1Live 3Earth
2Neutral
1
4
USB Type B
Socket
1
2
AC Mains
Socket
3
TECHNICAL REFERENCE APPENDIX
BLUE UNDERSCREEN CLEANER
Chapter Issue 1 Feb 15 Appendix to Micron Technical Manuals 3.25
BLUE UNDERSCREEN CLEANER
Solvent The solvent pump supplies solvent to the paper roll from the external solvent
tank, mounted on the rear or either side of the machine. The external solvent
tank container is capable of accommodating a 5 litre container of solvent. A load
cell in the base of the external solvent tank enables the software to calculate
the percentage level of solvent within the container.
NOTE
1. In the event of the solvent container leaking, the volume of the solvent
container housing (8.329 ltr) is suffucient to hold the contents of the 5 ltr
solvent container.
2. The procedure to be followed in the event of a leaking sovent container is
detailed in the Preventative Maintenance section of this manual.
Solvent Advice The plastic tubing that transports the solvent from the solvent tank to the
underscreen cleaner head is designed to withstand most types of solvent.
However, mixing of two different solvents can cause a chemical reaction and
seriously damage the plastic tubing. When changing to a different type of
solvent, the tubing must be replaced completely to prevent solvent leaks. To
obtain new tubing and replacement instructions, order Machine Performance
Upgrade (MPU) 601187*2.
ASM only recommend the DEK-PRO XF (Environmentally Friendly) USC solu-
tion to be used with the under screen cleaner in this machine. The following are
available from ASM:
NOTE
The following solvents MUST NOT be used in the under screen cleaner unit,
however, this list is not complete and does not mean that any solvent not
mentioned is compatible, with DEK machines.
• Rosstech 106 FE
• Rosstech 162 ND
• Acetone
• Iso-Propyl Alcohol (IPA)
Description 1 Litre 5 Litre 20 Litre
DEK-PRO XF 431513 431514 -
