2 Maintenance Tasks for Vacuum Pump
2.5 Final work
48 Maintenance Manual / Instandhaltungsanleitung Vacuum Pump / Vakuumpumpe Becker VX25 06/2017
2.5 Final work
► Installation is performed by following the above instructions in the reverse order. Also observe
the following instructions:
Fig.17: Protections on the manual tables
Manual tables only:
WARNING!
There is a risk of injury on manual tables without
the two protections.
.
► Fit the two protections.
Fig.18: Plastic strips on SIPLACE SX1/SX2
CAUTION!
Make sure that the plastic strips (1) (if present)
are located behind the plate (2) when you hook
up the used tape chute.
The black-yellow hatched label must be com-
pletely visible.
.
CAUTION
Waste slide
► Install the waste slide.
