Installation InstructionsQS18 Series Sensor Product Manual
01-Jun-26page20of29 © Banner Engineering Corp. All rights reserved.
www.bannerengineering.com
Mount the Device
If a bracket is needed, mount the device onto the bracket.
1.
Mount the device (or the device and the bracket) to the machine or equipment at the desired location. Do not tighten
the mounting screws at this time.
2.
Check the device alignment.
3.
Tighten the mounting screws to secure the device (or the device and the bracket) in the aligned position.
4.
01-Jun-26 page21of29
QS18 Series Sensor Product Manual
© Banner Engineering Corp. All rights reserved.
www.bannerengineering.com
Chapter Contents
Sensor Sensitivity Adjustment ............................................................................................................................................................................ 21
Sensor Sensitivity Adjustment
After the sensor and retroreflector have been properly installed, the sensor is ready to be adjusted to ensure detection of the
desired object. Sensor sensitivity is adjusted with the single turn adjuster.
Operating Instructions
Chapter 3
01-Jun-26 page22of29
QS18 Series Sensor Product Manual
© Banner Engineering Corp. All rights reserved.
www.bannerengineering.com
Chapter Contents
Cordsets ............................................................................................................................................................................................................. 22
Sensor Status Indicators .................................................................................................................................................................................... 23
QS18 Brackets ................................................................................................................................................................................................... 23
Retroreflective Targets ....................................................................................................................................................................................... 23
Plastic and Glass Fiber Optics ........................................................................................................................................................................... 23
Cordsets
4-pin Single-Ended M12 Female Cordsets (datasheet p/n 235937)
Model Length Dimensions (mm) Pinout (Female)
BC-M12F4-22-1 1 m (3.28 ft)
44 Typ.
ø 14.5
M12 x 1
7 mm
58 mm
Ø5.2 mm
1 2
34
5
1 = Brown
2 = White
3 = Blue
4 = Black
5 = Unused
BC-M12F4-22-2 2 m (6.56 ft)
BC-M12F4-22-5 5 m (16.4 ft)
BC-M12F4-22-8 8 m (26.25 ft)
BC-M12F4-22-10 10 m (30.81 ft)
BC-M12F4-22-15 15 m (49.2 ft)
BC-M12F4-22-20 20 m (65.61 ft)
BC-M12F4-22-25 25 m (82.02 ft)
BC-M12F4-22-30 30 m (98.42 ft)
4-pin Single-Ended M12 Female Right-Angle Cordsets (datasheet p/n 235937)
Model Length Dimensions (mm) Pinout (Female)
BC-M12F4A-22-1 1 m (3.28 ft)
32 Typ.
[1.26"]
30 Typ.
[1.18"]
ø 14.5 [0.57"]
M12 x 1
7 mm
58 mm
Ø5.2 mm
1 2
34
5
1 = Brown
2 = White
3 = Blue
4 = Black
5 = Unused
BC-M12F4A-22-2 2 m (6.56 ft)
BC-M12F4A-22-5 5 m (16.4 ft)
BC-M12F4A-22-8 8 m (26.25 ft)
BC-M12F4A-22-10 10 m (30.81 ft)
BC-M12F4A-22-15 15 m (49.2 ft)
4-Pin Single-Ended Snap-on M8 Female Cordsets
Model Length Style Dimensions Pinout (Female)
PKG4-2 2.03 m (6.66 ft) Straight
ø 9.0
32 Typ.
4
3
1
2
1 = Brown
2 = White
3 = Blue
4 = Black
Continued on page 23
QS18 Accessories
Chapter 4
