Features QS18 Series Sensor Product Manual
01-Jun-26 page7of29© Banner Engineering Corp. All rights reserved.
www.bannerengineering.com
Continued from page 6
Model Diffuse Mode Range Output Connection
QS18VP6DBQ PNP
150 mm (6 in) cable with a 4-pin M8
QD
QS18VP6DBQ5 PNP
150 mm (6 in) cable with a 4-pin
M12 QD
QS18VP6DBQ7 PNP 4-pin M8 male QD
QS18VP6DBQ8 PNP 4-pin M12 male QD
Divergent mode models (940 nm infrared)
Model Range Output Connection
QS18VN6W
100 mm (4 in)
NPN 2 m (6.5 ft) cable
QS18VN6WQ NPN
150 mm (6 in) cable with a 4-pin M8
QD
QS18VN6WQ5 NPN
150 mm (6 in) cable with a 4-pin
M12 QD
QS18VN6WQ7 NPN 4-pin M8 male QD
QS18VN6WQ8 NPN 4-pin M12 male QD
QS18VP6W PNP 2 m (6.5 ft) cable
QS18VP6WQ PNP
150 mm (6 in) cable with a 4-pin M8
QD
QS18VP6WQ5 PNP
150 mm (6 in) cable with a 4-pin
M12 QD
QS18VP6WQ7 PNP 4-pin M8 male QD
QS18VP6WQ8 PNP 4-pin M12 male QD
Fixed-field mode models (630 nm visible red)
Model Range Output Connection
QS18VN6FF50
50 mm (2 in)
NPN 2 m (6.5 ft) cable
QS18VN6FF50 W/30 NPN 9 m cable
QS18VN6FF50Q NPN
150 mm (6 in) cable with a 4-pin M8
QD
QS18VN6FF50Q5 NPN
150 mm (6 in) cable with a 4-pin
M12 QD
QS18VN6FF50Q7 NPN 4-pin M8 male QD
QS18VN6FF50Q8 NPN 4-pin M12 male QD
QS18VP6FF50 PNP 2 m (6.5 ft) cable
QS18VP6FF50 W/30 PNP 9 m cable
QS18VP6FF50Q PNP
150 mm (6 in) cable with a 4-pin M8
QD
QS18VP6FF50Q5 PNP
150 mm (6 in) cable with a 4-pin
M12 QD
QS18VP6FF50Q8 PNP 4-pin M12 male QD
QS18VN6FF100
100 mm (4 in)
NPN 2 m (6.5 ft) cable
QS18VN6FF100 W/30 NPN 9 m cable
QS18VN6FF100Q5 NPN
150 mm (6 in) cable with a 4-pin
M12 QD
QS18VN6FF100Q8 NPN 4-pin M12 male QD
QS18VP6FF100 PNP 2 m (6.5 ft) cable
Continued on page 8
FeaturesQS18 Series Sensor Product Manual
01-Jun-26page8of29 © Banner Engineering Corp. All rights reserved.
www.bannerengineering.com
Continued from page 7
Model Range Output Connection
QS18VP6FF125 125 mm (5 in) PNP 2 m (6.5 ft) cable
QS18VN6FF150
150 mm (6 in)
NPN 2 m (6.5 ft) cable
QS18VN6FF150Q5 NPN
150 mm (6 in) cable with a 4-pin
M12 QD
QS18VN6FF150Q8 NPN 4-pin M12 male QD
QS18VP6FF150 PNP 2 m (6.5 ft) cable
QS18VP6FF150 W/30 PNP 9 m cable
QS18VP6FF150Q PNP
150 mm (6 in) cable with a 4-pin M8
QD
QS18VP6FF150Q5 PNP
150 mm (6 in) cable with a 4-pin
M12 QD
QS18VP6FF150Q7 PNP 4-pin M8 male QD
QS18VP6FF150Q8 PNP 4-pin M12 male QD
Plastic fiber optic mode models (660 nm visible red)
Model Range Output Connection
QS18VN6FP
Range varies by sensing mode and
fiber optics used
NPN 2 m (6.5 ft) cable
QS18VN6FPQ NPN
150 mm (6 in) cable with a 4-pin M8
QD
QS18VN6FPQ5 NPN
150 mm (6 in) cable with a 4-pin
M12 QD
QS18VN6FPQ7 NPN 4-pin M8 male QD
QS18VN6FPQ8 NPN 4-pin M12 male QD
QS18VP6FP PNP 2 m (6.5 ft) cable
QS18VP6FPQ PNP
150 mm (6 in) cable with a 4-pin M8
QD
QS18VP6FPQ5 PNP
150 mm (6 in) cable with a 4-pin
M12 QD
QS18VP6FPQ7 PNP 4-pin M8 male QD
QS18VP6FPQ8 PNP 4-pin M12 male QD
Glass fiber optic mode models (940 nm infrared)
Model Range Output Connection
QS18VN6FQ5
Range varies by sensing mode and
fiber optics used
NPN
150 mm (6 in) cable with a 4-pin
M12 QD
QS18VN6FQ7 NPN 4-pin M8 male QD
QS18VP6F PNP 2 m (6.5 ft) cable
QS18VP6FQ PNP
150 mm (6 in) cable with a 4-pin M8
QD
QS18VP6FQ5 PNP
150 mm (6 in) cable with a 4-pin
M12 QD
QS18VP6FQ8 PNP 4-pin M12 male QD
Models with a quick disconnect require a mating cordset.
For a list of discontinued models, see Discontinued Models.
Features QS18 Series Sensor Product Manual
01-Jun-26 page9of29© Banner Engineering Corp. All rights reserved.
www.bannerengineering.com
Specifications
Supply Voltage
10 V DC to 30 V DC (10% maximum ripple) at less than 25
mA, exclusive of load
Protected against reverse polarity and transient voltages
Light Source
Glass Fiber Optic, Opposed and Diffuse mode models:
Infrared, 940 nm
Plastic Fiber Optic, Retroreflective, Convergent models:
Visible red, 660 nm
Fixed-Field and DVS models: Visible red, 630 nm
Adjustments
Glass Fiber Optic, Plastic Fiber Optic, Convergent, Diffuse,
and Retroreflective mode models (only): Single-turn sensitivity
(Gain) adjustment potentiometer
Indicators
Two LED indicators on the sensor top
Green: Power on
Amber: Light sensed
Amber flashing: Marginal excess gain (1 to 1.5 times excess
gain)
Construction
ABS housing
3 mm mounting hardware included
Connections
2 m (6.5 ft) 4-wire PVC cable; 9 m (30 ft) 4-wire PVC cable; 4-
pin M8 or M12 QD; or 150 mm (6 in) cable with a 4-pin M8 or
M12 QD, depending on the model
Repeatability
Opposed Mode: 100 microseconds
DVS, DL and FF Modes: 90 microseconds
All Other Modes: 150 microseconds
Output Configuration
Solid-state complementary (SPDT): NPN or PNP (current
sinking or sourcing), depending on model
Rating: 100 mA maximum each output at 25 °C
DVS, DL and FF Modes ON-state Saturation Voltage: less
than 1.5 V at 10 mA; less than 3 V at 100 mA
All Other Modes: ON-state Saturation Voltage: less than 1 V
at 10 mA; less than 1.5 V at 100 mA
Protected against false pulse on power-up and continuous
overload or short circuit of outputs
Output Response
Opposed Mode: 750 microseconds ON; 375 microseconds
OFF
DVS, FF, and DL Modes: 850 microseconds ON/OFF
All Other Modes: 600 microseconds ON/OFF
100-millisecond delay on power-up; outputs do not conduct
during this time
Environmental
IP67
UL Type 1
Operating Conditions
–20°Cto+70°C(–4°Fto+158°F)
95% at +50 °C maximum relative humidity (non-condensing)
Vibration and Mechanical Shock
All models meet MIL-STD-202F, Method 201A (Vibration: 10
Hz to 60 Hz maximum, 0.06 inch (1.52 mm) double amplitude,
10G maximum acceleration) requirements. Also meets IEC
60947-5-2 (Shock: 30G 11 ms duration, half sine wave)
requirements.
Required Overcurrent Protection
WARNING: Electrical connections must
be made by qualified personnel in
accordance with local and national
electrical codes and regulations.
Overcurrent protection is required to be provided by end
product application per the supplied table.
Overcurrent protection may be provided with external fusing
or via Current Limiting, Class 2 Power Supply.
Supply wiring leads < 24 AWG shall not be spliced.
For additional product support, go to
www.bannerengineering.com.
Supply
Wiring
(AWG)
Required Overcurrent
Protection (A)
Supply
Wiring
(AWG)
Required Overcurrent
Protection (A)
20 5.0 26 1.0
22 3.0 28 0.8
24 2.0 30 0.5
Certifications
Banner Engineering BV
Park Lane, Culliganlaan 2F bus 3
1831 Diegem, BELGIUM
Turck Banner LTD Blenheim House
Blenheim Court
Wickford, Essex SS11 8YT
GREAT BRITAIN
NOTE: For performance specifications of the FF50 and FF100 models built prior to date code 17090, refer
to document p/n 63908.
FCC Part 15 Class A for Unintentional Radiators
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
(Part15.21)Anychangesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoidtheuser’sauthoritytooperatethis
equipment.
