18 PCB magazine series 700 further sizes on r equest V ariable width setting by pulling the gear belt by hand 4 Gear belt By pulling the g ear belt, the side walls are se t to the PCB width. 2 Four pr ecision spindles to…

100%1 / 24
17
PCB magazine series 600
further sizes on request
DL31001
assembled with
stacking knobs
DL 31002
assembled for
perfecting operation
The PCB magazines 60X.1 and 60X.2
are delivered partially assembled.
Assembled magazines to be ordered
with an additional part no.:
1
Transport lock
A bar is mounted as a standard on the front
and back sides. At liing, the bar is moved
to the outside and locks in upper position.
The PCBs can be inserted or removed.
When liing again, the slots are locked.
Screw-clamped width setting
2
Screw clamps
Series 600 magazines are cost-eective.
With the help of four screw clamps,
the side wall can be set to the PCB width.
Type Part no. Side wall
material
Temperatur e °C
Outside dimensions
PCB
Insertions
Surrounding
Weight kg
Width
W
Length
L
Height
H
Width
D
Length
C
mm mm mm mm
up to
mm
601.1
601.2
601.3
8917601
8916601
8915601
Polystyrene
Polycarbonate
Metal
60
130
200
50
80
200
5.6
5.9
6.9
320 355 563 40 - 250 342
602.1
602.2
602.3
8917602
8916602
8915602
Polystyrene
Polycarbonate
Metal
60
130
200
50
80
200
5.8
6.1
7.2
320 400 563 40 - 250 387
603.1
603.2
603.3
8917603
8916603
8915603
Polystyrene
Polycarbonate
Metal
60
130
200
50
80
200
6.2
6.5
7.6
380 400 563 40 - 310 387
The PCB magazines 60X.3
are delivered assembled with stacking knobs.
18
PCB magazine series 700
further sizes on request
Variable width setting by pulling the gear belt by hand
4
Gear belt
By pulling the gear belt,
the side walls are set to the PCB width.
2
Four precision spindles
to set the moveable side wall
Type Part no. Side wall
material
Temperature °C
Outside dimensions
PCB
Insertions
Surrounding
Weight kg
Width
W
Length
L
Height
H
Width
D
Length
C
mm mm mm mm
up to
mm
701.1
701.2
701.3
8917701
8916701
8915701
Polystyrene
Polycarbonate
Metal
60
130
200
50
80
100
5.6
5.9
6.9
320 355 563 40 - 250 342
702.1
702.2
702.3
8917702
8916702
8915702
Polystyrene
Polycarbonate
Metal
60
130
200
50
80
100
5.8
6.1
7.2
320 400 563 40 - 250 387
703.1
703.2
703.3
8917703
8916703
8915703
Polystyrene
Polycarbonate
Metal
60
130
200
50
80
100
6.2
6.5
7.6
380 400 563 40 - 310 387
704.1
704.2
704.3
8917704
8916704
8915704
Polystyrene
Polycarbonate
Metal
60
130
200
50
80
100
7.8
8.0
9.5
400 460 563 10 - 330 447
716.2
716.3
8916716
8915716
Polycarbonate
Metal
130
200
80
100
9.5
10.9
460 535 563 10 - 390 522
717.2
717.3
8916717
8915717
Polycarbonate
Metal
130
200
80
100
9.7
11.1
530 535 563 10 - 460 522
1
Safety screw
Clamping the gear belt with a thumb screw
prevents from accidental adjustment
of the moveable side wall.
DL31001
assembled with
stacking knobs
DL 31002
assembled for
perfecting operation
The PCB magazines 70X.1 and 70X.2
are delivered partially assembled.
Assembled magazines to be ordered
with an additional part no.:
The PCB magazines 70X.3
are delivered assembled with stacking knobs.
3
Transport lock
A bar is mounted as a standard on the front
and back sides. At liing, the bar is moved
to the outside and locks in upper position.
The PCBs can be inserted or removed.
When liing again, the slots are locked.
19
PCB magazine series 800
further sizes on request
Type Part no. Side wall
material
Temperatur e °C
Outside dimensions
PCB
Insertions
Surrounding
Weight kg
Width
W
Length
L
Height
H
Width
D
Length
C
mm mm mm mm
up to
mm
801.1
801.2
801.3
8919801
8918801
8915801
Polystyrene
Polycarbonate
Metal
60
130
200
50
80
100
5.6
5.9
6.9
320 355 563 40 - 250 342
802.1
802.2
802.3
8919802
8918802
8916740
Polystyrene
Polycarbonate
Metal
60
130
200
50
80
100
5.8
6.1
7.2
320 400 563 40 - 250 387
803.1
803.2
803.3
8919803
8916745
8915803
Polystyrene
Polycarbonate
Metal
60
130
200
50
80
100
6.2
6.5
7.6
380 400 563 40 - 310 387
804.1
804.2
804.3
8919804
8918804
8915804
Polystyrene
Polycarbonate
Metal
60
130
200
50
80
100
7.8
8.0
9.5
400 460 563 10 -330 447
816.2
816.3
8916816
8915816
Polycarbonate
Metal
130
200
80
100
9.5
10.9
460 535 563 10 - 390 522
817.2
817.3
8916817
8915817
Polycarbonate
Metal
130
200
80
100
9.7
11.1
530 535 563 10 - 460 522
3
Transport lock
A bar is mounted as a standard
on the front and back sides.
Automatic operation
When put on a loader, the bar
is moved to the outside by a wedge.
At removal, the slot locks again.
Manual operation
At liing by hand, the bar is moved
to the outside and locks in upper position.
When liing again, the slots are locked.
Variable width setting by pulling the gear belt motor-driven or by hand
5
Clutch disc
for motor-driven width setting
1
Gear belt
for manual or automatic width setting
4
Safety screw
Clamping the gear belt with a thumb screw
prevents from accidental adjustment
of the moveable side wall.
DL31001
assembled with
stacking knobs
The PCB magazines 80X.1 and 80X.2
are delivered partially assembled.
Assembled magazines to be ordered
with an additional part no.:
The PCB magazines 80X.3
are delivered assembled with stacking knobs.
2
Four precision spindles
to set the moveable side wall
