Safety Precautions
EUKYX-Safety
199-X100
Safe-11
Alert Indications described as "
CAUTION
"
Alert Description Related Items
Avoid hand and finger injuries.
• Be careful to avoid hand and finger injuries when closing the covers
(door type).
• Hold the hand grip firmly and open or close the cover (door type)
slowly.
"2.2.3" in "Chapter 1 (Vol. 1)"
When the green lamp of the light tower is ON or flickering (ON and
OFF), it indicates that the static machine is in the "Automatic" mode
(standby mode).
"2.3.2" in "Chapter 1 (Vol. 1)"
Before operating the machine, confirm that there are no people
around the machine (especially, the other side of the machine
operation) and no objects such as tools and parts are left around the
machine.
"3.2" in "Chapter 1 (Vol. 1)"
"1.1.4" and "4.1" in
"Chapter 3 (Vol. 1)"
Depending on the setting for the PCB discharge from the input
machine to this machine or from this machine to the output machine,
the conveyor may move at the moment when the PCB has been
removed. In such cases, your finger might be caught.
"3.2" in "Chapter 1 (Vol. 1)"
Strong Magnetism
• Do not bring any metal of high magnetizability close to this.
Otherwise, such metal will easily be magnetized and attracted,
causing an injury to the operator or breakdown of the machine.
• Do not bring any object such as a magnetic card and a watch
close to the machine. Such an object can easily be affected by
the magnetism.
The data of the magnetic card might be cleared or a watch, etc.,
may be damaged due to the strong magnetism.
"3.4" in "Chapter 1 (Vol. 1)"
4. Alert Indications in Instruction Manual
Safety Precautions
EUKYX-Safety
199-X100
Safe-12
Alert Indications described as "
CAUTION
" (continued)
Alert Description Related Items
When a tape feeder is attached or detached, be sure not to drop
it.
Otherwise, a foot injury will result or the feeder itself may be
damaged. Carefully handle each feeder one by one and do not drop
any.
"3.8" in "Chapter 1 (Vol. 1)"
"2.2.4" in "Chapter 3 (Vol. 1)"
"3.1" in"Chapter 3 (Vol. 1)"
"3.4.2" in"Chapter 3 (Vol. 1)"
Hazardous to your hands and fingers!
• Be sure to hold the handle to move the bank feeder change cart.
• Be careful not to hit your hand against the cover while installing the
bank feeder change cart onto the main machine.
"3.8.1" in "Chapter 1
“2.2.4” in “Chapter 3 (Vol. 1)"
Watch your step!
• Be careful not to hit your foot against the cart while moving the
bank feeder change cart.
Especially, the resistance against cart movement may change rapidly
when the floor is ragged and the cart gets caught on the floor or a
sheet is used and the cart gets caught at the edge or a slackened
portion of the sheet.
• Make sure to insert the feeder into the deep end.
When the tape feeder is mounted onto the feeder carriage, make
sure that it has been inserted into the deep end and fixed securely.
In the case that it has not been fixed securely, the tape feeder might
fall, which might cause a lower leg injury or damage to the feeder.
"3.8.1" in "Chapter 1 (Vol. 1)"
"2.2.4" in "Chapter 3 (Vol. 1)"
Do not put your hand in the moving area while the feeder base is
moving up or down.
While the LED of the Feeder Ready switches are being flickering, it
indicates that the corresponding feeder base is moving up and down.
"2.2.5" in "Chapter 1 (Vol. 1)"
When you need to bend down to perform work, you may hit your
head on the tape feeder worktable and get injured.
"2.2.6.1" in "Chapter 3
(Vol. 1)"
4. Alert Indications in Instruction Manual
Safety Precautions
EUKYX-Safety
199-X100
Safe-13
Alert Indications described as "
CAUTION
" (continued)
Alert Description Related Items
When the tape feeder connecting cable is connected to the tape
feeder, unless the tape feeder is held securely, the tape feeder
holding guide may come off and drop from the tape feeder unit.
Connect the cable with the tape feeder held securely.
"2.2.6.1" in
"Chapter 3 (Vol. 1)"
There are some heavy feeder models. When such feeders are
removed with one hand, the weight of the feeder removed from
the guide cannot be supported by one hand and the feeder might
drop. Remove the feeder using both hands to support it.
"2.2.6.2" in
"Chapter 3 (Vol. 1)"
The padlock key should be kept in such a way that nobody except the
personnel in charge of maintenance can supervise it.
"4.3" in "Chapter 2 (Vol. 1)"
The load power to the motors, etc., is turned OFF but the setup
operation must be performed carefully when you put your hand
inside the machine. Avoid hand and finger injuries.
"2.3.5" in "Chapter 3 (Vol. 1)"
"4.1" and "4.2.1" in
"Chapter 6 (Vol. 2)"
Even when the power breaker is set to "OFF", the primary line is
powered, making it possible to cause an electric shock.
Be sure to completely stop the power supply to the machine before
maintenance work.
"1.1" in "Chapter 1 (Vol. 4)"
Residual voltages may remain behind for a few minutes in the
internal devices of the machine after power interception.
Before performing maintenance work, wait until the charge lamps of
the DC power supply and the servo amplifier go "OFF" in 10 minutes
or more after the power breaker is set to "OFF".
"1.1" in "Chapter 1 (Vol. 4)"
After making sure that the power supply has been stopped and
the cutter blades are closed, start maintenance.
During maintenance, do not touch the cutter blade.
“4.6.1” and "4.6.2" in
"Chapter 1 (Vol. 4)"
4. Alert Indications in Instruction Manual
