EUKYX 1-8 199-5100 1.7 Head Unit 1 .7 Head Unit A V P R A P A V P A V P V alve Filter Rotary Joint φ 8 Fitting φ 8 φ 4 φ 8 Fitting φ 6 Fitting φ 4 Fitting φ 4 Fitting V alve 3 2 1 4 5 6 From Main Body Robot Cable Nozzle1…
EUKYX
1-7199-5100
1.6 Nozzle Stocker
1.6 Nozzle Stocker
8
4
5
6
2
3
9
1
Stocker 1 U/D
From Main Body
Shutter 1 Open / Close
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
1 Tube
∅
8 1
2 Tube
∅
6 1
3 Tube
∅
4 1
4 Solenoid Valve 1
5 Cylinder 1
6 Cylinder 1
8 Needle 1
9 Union Y 1
EUKYX
1-8199-5100
1.7 Head Unit
1.7 Head Unit
A
V
P
R
A
P
A
V
P
A
V
P
Valve
Filter
Rotary Joint
φ8 Fitting
φ8
φ4
φ8 Fitting
φ6 Fitting
φ4 Fitting
φ4 Fitting
Valve
3
2
1
4
5
6
From Main Body
Robot Cable
Nozzle1 Nozzle2 Nozzle15
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
1 Tube
∅
4 1
2 Tube
∅
8 1
3 Solenoid Valve 1
4 Rotary Joint 1
5 Solenoid Valve 15
6 Filter 15
EUKYX
1-9199-5100
1.8 Feeder Base
1.8 Feeder Base
5
1
2
3
4
6
From Main Body
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
1 Tube
∅
6 1
2 Solenoid Valve 2
3 Speed Controller 4
4 Cylinder 2
5 Modular Unit 2
6 Air Connector Pin 2
