VITRONICS REFLOW SOLDERING SYSTEMS

EM 02502-G 15-Nov-00 (c) PAGE Operator’s Manual

27

RAIL CHAIN LUBRICATION

The Rail Chain Lubrication Option provides smooth operation and will extend the

life of the rail chain conveyor by periodically applying lubrication to the chain during

oven operation. The Oven MUST be running for ANY Lubrication to take place.

This Option can be used automatic or manual.

RAIL CHAIN LUBRICATION STATUS

The present status of the Rail Chain Lubrication System

can be displayed by selecting the "Lubrication" symbol

at the top of the Oven Operating Screen.

(This symbol will be displayed at the bottom of the screen during

the Lubrication Process)

The Lubrication Status dialogue box will be displayed:

Rail Lubrication System Information is displayed, including:

1) Automatic chain lubrication is enabled (or disabled).

2) Lubrication process is on (or off).

3) Number of chain cycles before the automatic lube process starts.

4) Number of lubrications before a low oil warning is displayed.

VITRONICS REFLOW SOLDERING SYSTEMS

EM 02502-G 15-Nov-00 (c) PAGE Operator’s Manual

28

RAIL CHAIN LUBRICATION

The automatic lubrication starts when the chain has completed the number of

cycles between lubrications.

The Lubrication Icon (symbol) is displayed with the time remaining in the

Lubrication Process, as a predetermined quantity of lube oil is applied to the rail

chain.

The conveyor will start at minimum speed. 5 seconds later, lube oil will be applied

for two complete cycles of the chain.

REFILLING THE OIL RESERVOIR

The oil reservoir needs to be refilled (with the proper lubricant) when a warning

message "check chain lubricant level in tank, refill if necessary." is displayed and

the "low oil symbol" is displayed on the Graphics View Screen.

NOTE

IT IS POSSIBLE TO SELECT REFILL ONLY IF NO LUBRICATION IS

PRESENTLY IN PROCESS.

VITRONICS REFLOW SOLDERING SYSTEMS

EM 02502-G 15-Nov-00 (c) PAGE Operator’s Manual

29

INDEX

ALARMS................................................................................................................................. 17, 19, 21, 22

AUTOMATIC RAIL WIDTH...................................................................................................................... 24

BOARD DROP ......................................................................................................................................... 22

BOARD TRACKING................................................................................................................................. 26

COMMUNICATIONS ALARM.................................................................................................................. 22

CONVECTION.......................................................................................................................................... 22

CONVEYOR ....................................................................................................................................... 22, 24

COOLANT................................................................................................................................................ 22

CRITICAL WARNING....................................................................................................................... 17, 21

CRITICAL ALARM................................................................................................................................... 21

DATALOG ................................................................................................................................................ 25

DATE ........................................................................................................................................................ 31

DEFINITIONS............................................................................................................................................. 7

EMERGENCY STOP................................................................................................................................ 22

GAS ON/OFF............................................................................................................................................ 22

GAS PRESSURE LOW............................................................................................................................ 22

HOOD OPEN............................................................................................................................................ 22

IAS ............................................................................................................................................................ 21

ICONS................................................................................................................................................. 12, 13

LUBRICATION STATUS .........................................................................................................................27

MANUAL RAIL WIDTH ADJUST...................................................................................................... 18, 24

OIL LEVEL LOW...................................................................................................................................... 22

OPERATING SCREEN .............................................................................................................................. 8

OVEN STATUS BAR ...............................................................................................................................9

PASSWORD......................................................................................................................................... 3, 10

PRINTING........................................................................................................................................... 14, 31

PROCESS READY................................................................................................................................... 19

PRODUCT.................................................................................................................................... 15, 16, 24

PUSHBUTTON SYMBOLS........................................................................................................................ 6

QUICK COOL................................................................................................................................. 5, 18, 26

RAIL CHAIN LUBRICATION............................................................................................................. 27, 28

RAIL WIDTH................................................................................................................................. 18, 23, 24

READY................................................................................................................................................ 19, 21

RECIPE............................................................................................................................................... 15, 16

REFILLING THE OIL RESERVOIR......................................................................................................... 28

SERVICE FACILITIES ...............................................................................................................................4

SETUP...................................................................................................................................................... 18

SHUTDOWN................................................................................................................................. 19, 20, 21

SHUTDOWN PROCEDURE.................................................................................................................... 20

STABILIZING ..................................................................................................................................... 18, 21

STATUS MESSAGES.............................................................................................................................. 22

SYMBOLS.............................................................................................................................................. 6, 8

SYSTEM SETUP...................................................................................................................................... 18

TIME.......................................................................................................................................................... 31

WARNING .............................................................................................................................. 17, 18, 20, 21

ZONE........................................................................................................................................................ 26
