SIPLACE SWS Software 3. 0 / Versionsbeschreibung / Ve rsion Description Ausgabe 12/2014 Edition 32 13.2 Simplified Navigation in Manual Se tting Menu The menu navigation at Manual se tting => Parameter test c amera an…
SIPLACE SWS Software 3.0 /
Versionsbeschreibung / Version Description Ausgabe 12/2014 Edition
31
13 SWS Software 2.1 Features
The SWS software 2.1 includes all functions from the SWS software 2.0. The following section
describes the main new features in version 2.1 of the SWS software.
NOTE
For details about the individual functions, please refer to the software manual for
the "SIPLACE SWS Software 2.1 [item no.: 00195986-02].
13.1 Revised Interface to Wafer Map Server
The menu navigation at Manual setting => Wafer-Map has been simplified. The settings and
monitoring options have been revised.
The option Connection settings => SIPLACE Wafer System has been extended. The software
now also supports passive connections to the wafer map server.
SIPLACE SWS Software 3.0 /
Versionsbeschreibung / Version Description Ausgabe 12/2014 Edition
32
13.2 Simplified Navigation in Manual Setting Menu
The menu navigation at Manual setting => Parameter test camera and in the corresponding
Wafer camera and Inspection camera views has been simplified.
A few unnecessary functions, such as Pattern Teaching, have been removed.
13.3 LAN Connection to Station Software 708
In addition to the connection via CAN with the station software 605 SP5, the SWS software
supports a connection to machines via LAN with station software 708.
SIPLACE SWS Software 3.0 /
Versionsbeschreibung / Version Description Ausgabe 12/2014 Edition
33
14 SWS Software 3.0 Features
The SWS software 3.0 includes all functions from the SWS software 2.0 and 2.1. The following
section describes the main new features in version 3.0 of the SWS software.
NOTE
For details about the individual functions, please refer to the software manual for
the "SIPLACE SWS Software 3.0 [item no.: 00195986-03].
14.1 New Main Functions – Messages
In the views toolbar, click on the Messages button.
The Messages => History view shows all information, warnings and error messages which
have been issued.
The Messages => Saved SIPLACE Vision dump files enables you to open and view the
saved SIPLACE Vision dump files. In earlier versions, this function could be found at Manual
Setting => Image viewer.
