SMT Software Engineering Group
IM Operations YAMAHA MOTOR CO., LTD
MDOC-SOFT50389
7/18
3.3 Error Message
The below is the error messages added for this function.
Error No. Title Cause and Solution
2793
PICK HEIGHT
TEACH FILE
READ ERROR
Failed to read following file.
Restore the machine data with System Backup.
Re-install the software.
2794
PICK HEIGHT
TEACH FILE
WRITE ERROR
Unable to write the setting file of Pick Height Teach.
Remove read-only, and try it again.
Restore the machine data with [System Backup] - [Restore], and
try it again.
2980
PICK HEIGHT
TEACH FAILED
Causes
- Nozzle is clogged, so that change of vacuum level will not be
detected correctly.
- There is an unknown object that can bother the measurement.
- Surface of the measure point is uneven.
- The target feeder or tape is not attached.
Solutions:
- Clean the nozzle.
- Check the measure point.
- Check the condition of the target feeder and tape.
2981
FEEDER GUIDE
RECOGNITION
FAILED
Causes:
- The recognition position is unclean.
- The recognition mark data is not correct.
Solutions:
- Clean the position, and ensure no unknown object is there.
- Check the mark data.
SMT Software Engineering Group
IM Operations YAMAHA MOTOR CO., LTD
MDOC-SOFT50389
8/18
Error No. Title Cause and Solution
2982
PICK HEIGHT
TEACH RESULT
LIMIT OVER
Causes:
- Nozzle is clogged, so that change of vacuum will not be
detected correctly.
- There is an unknown object that can bother the measurement.
- Surface of the measurement position is uneven.
- The target feeder or tape is not attached.
Solutions:
- Clean the nozzle.
- Check the measurement position.
- Check the condition of the target feeder and tape.
2983
PICK HEIGHT
TEACH ERROR
SET NUMBER
Unable to measure the pick height on the following feeder setting
position. Release auto-measurement and execute individual
measurement.
24742
ALL
FEEDBACK?
Confirm that you really want to feedback all the teaching result to
board data.
-Yes・・・All Feedback is executed.
-No・・・Not executed.
24743
Pick Height
Measurement
Error
Vacuum level is different between before and after measurement.
Cause
-Parts or something is on the nozzle.
Solution
-Check the nozzle and clean it if necessary.
24744
PICK HEIGHT
TEACH MARK
DATA LOADING
ERROR
Failed to load the Pick Height Teach mark data.
Cause
- Mark data number is not correct.
- Denied access to database.
Solution
- Enter a correct mark data number in [Machine Setting]-[Pick
Height Teach]-[Tape Guide Recog Mark No.].If [SS Tape Guide
Type] is "Metal" or "Plastic", enter "0".
- Confirm that database is accessible.
24767
Pick Height
Teach Feedback
WARNING
This board data includes parts without feedback of pick height.
Close this screen?
YES・・・Close this screen.
NO・・・Back to the previous screen.
SMT Software Engineering Group
IM Operations YAMAHA MOTOR CO., LTD
MDOC-SOFT50389
9/18
Error No. Title Cause and Solution
24792
FEEDER GUIDE
RECOGNITION
ERROR
Unable to recognize the feeder guide, because it is out of the
moving range of the camera.
To teach the pick height, move the feeder to a position within the
camera range.
24793
PICK HEIGHT
MEASUREMENT
ERROR
The measurement position is out of the moving range of head.
No measurable head found.
-To teach the pick height, move the feeder or parts to a position
where the head can reach.
-Use a nozzle that is selected on [Machine] - [Specification
Information] - [Head Specification].
-Confirm the head number used for mounting.
24794
PICK HEIGHT
TEACH
CONDITION
ERROR
- The parts are set to be mounted.
- Do not use a x03/x14 nozzle or larger to measure a plastic
guide.
- Only 8mm or 4mm feeder is allowed.
- The nozzle is set with [Pick Height Teach] - [Nozzle Type]
checked.
- When [Pick Height Teach] - [SS Tape Guide Type] is set to "Mix",
enter a mark database number of guide recognition into [Tape
Guide Recog Mark No].
-Confirm that [Parts] - [Basic] - [Category] is not set to "Stamp".
-Confirm that the feeder is set on the measurement set position.
24809
Feeder set
number is
overlapped
(▲1)
The board data has other parts on the same feeder set position.
Confirm that setting position is entered properly.
Change the feeder set number to avoid overlaps.
If the parts don't need to be measured, set the feeder setting
position with "0".
