MODEL TCM-X200 0203-002 Key No. P AR T No. P AR T NAME Q’ ty REMARKS NOTE 233 MC-5 40 1 630 105 0737 CO VE R 2 40 2 630 105 0744 CO VE R 4 40 3 630 105 0751 CO VE R 1 40 4 630 105 0768 CO VE R 1 40 5 630 105 0225 CO VE R…

MODEL TCM-X200

0203-002

232

ࡈࠖ࡯࠳ࠠࡖ࡝࠶ࠫࠞࡃ࡯ Feeder Carriage Cover

Fig. MC-5 ૞ᬺࠛ࡝ࠕ቟ోᚺࡄࡀ࡞ Work Area Seafty Door Panel

Fig.MC-5

401

402

403

404

402

401

405

406

407

406

405

4797L

TCM-X300

TCM-X200-002

4797A-002

MODEL TCM-X200

0203-002

Key No. PART No. PART NAME Q’ty REMARKS

NOTE

233

MC-5

401 630 105 0737 COVER 2

402 630 105 0744 COVER 4

403 630 105 0751 COVER 1

404 630 105 0768 COVER 1

405 630 105 0225 COVER 2

406 630 105 0232 COVER 4

407 630 105 0249 COVER 1

MODEL TCM-X200

0103-001

234

ࡈࠖ࡯࠳ࠠࡖ࡝࠶ࠫࠞࡃ࡯ Feeder Carriage Cover

Fig. MC-6 ೨஥ࠞࡃ࡯ࡄࡀ࡞ Front Side Cover Panel

502

504

503

501

Fig.MC-6

TCM-X200

TCM-X300

4797A

4797L
