SA FETY FEA TU RES HI GH VOLTAGE PRO TECTIO N Ch apte r Is sue 6, Jun 18 Tech ni cal R efer enc e Manual 2. 13 T yp ical Module Ear th St ud and L abel 1 Earth St uds a nd Labels Mains I solat or ( cover r emoved) Showin…
SAFETY FEATURES
HIGH VOLTAGE PROTECTION
2.12 Technical Reference Manual Chapter Issue 6, Jun 18
Earth Studs and Labels on the Print Carriage
1 Earth Studs and Labels
Earth Studs and Labels on the Vacuum Pump
1 Earth Studs and Labels
SAFETY FEATURES
HIGH VOLTAGE PROTECTION
Chapter Issue 6, Jun 18 Technical Reference Manual 2.13
Typical Module Earth Stud and Label
1 Earth Studs and Labels
Mains Isolator (cover removed) Showing Earth Loom Arrangement
1 Earth lead (Green/Yellow) to printer’s earth bonding point (M5 Stud)
2 Earth Label
4 Earth lead (Green/Yellow) to printer’s earth bonding point (M6 Stud)
SAFETY FEATURES
HIGH VOLTAGE PROTECTION
2.14 Technical Reference Manual Chapter Issue 6, Jun 18
ASM Chase Showing Earth Loom Bonding Point
1 ASM Chase Earth Bonding Point
