User manual E by SIPLACE 7 Maintenance From software version SC 712.1 Edition 05/2 019 7.5 Maintenance o n SIPLACE CP12/CP6 321 7.5 Maintenance on SIPLACE CP12/CP6 7 7.6 Cleaning or Replacing Nozzles This action is requi…
7 Maintenance User manual E by SIPLACE
7.4 Maintenance on SIPLACE TH/PP From software version SC 712.1 Edition 05/2019
320
7.4 Maintenance on SIPLACE TH/PP
7
Cleaning and Checking tasks
SIPLACE TH/PP
Every 6
months
Every 12
months
– Maintenance Pressure Control Valve
X
– Cleaning the Sleeve and Nozzle Seat
X
– Cleaning/Replacing the Additional Volume Filter
X
– Cleaning/Greasing the Pneumatic Rotary Axis
X
– Cleaning/Greasing the Z-axis Linear Guidance
X
– Cleaning the Z-axis Linear Scale and mounting the Buffer
X
– Cleaning the VCR and Vacuum Block
X
User manual E by SIPLACE 7 Maintenance
From software version SC 712.1 Edition 05/2019 7.5 Maintenance on SIPLACE CP12/CP6
321
7.5 Maintenance on SIPLACE CP12/CP6
7
7.6 Cleaning or Replacing Nozzles
This action is required when encountering a nozzle soil/dirty error.
SIPLACE CP12/CP6l Every 6
months
Every 12
months
– Cleaning the Valve Casings
X
– Checking, Cleaning and Greasing the Sleeves
X
– Cleaning the Turning Station Read Unit
X
– Check Cleaning/Greasing Z-Axis
X
– Cleaning/Greasing Star Mount
X
– Check Cleaning/Greasing Vacuum Distributor
X
– Check/Cleaning/Greasing Star brake
X
– Check/Cleaning/Greasing Z-axis Valve adjustment drives
X
– Check/Cleaning Turning station
X
– Check/Cleaning Vacuum generator
X
7 Maintenance User manual E by SIPLACE
7.6 Cleaning or Replacing Nozzles From software version SC 712.1 Edition 05/2019
322
