SS-1189
(2) Packaged Posture Standards
Taped Components
JIS or its equivalent
• Paper Tapes (Width : 8 mm)
• Embossed Tapes (Width : 8 to 72 mm)
• Reel Outer Diameter : φ 382 mm or less.
Note : Some taping sizes are limited.
Some taped components cannot be used due to the mechanical
characteristics.
Stick Components
• Carrier Stick : Width 8 to 60 mm × Thickness 3 to 16 mm
× Length 400 to 600 mm (CS-G100 used)
Tray Components
• Tray : 100 × 100 to 323 × 136 mm (FP-G100 and FP-G300 used)
100 × 100 to 330 × 230 mm (FP-G200 used)
9. Placement Heads Equipped with 4 heads/4 beams
Vacuum Nozzle: Max. 12 nozzles on each head
Ref. : Maximum Number of Component Picks:
Component Size 5 × 4 mm or less 12
to 10 × 10 mm or less 6
to 12 × 12 mm or less 4
to 20 × 20 mm or less 2
to 44 × 44 mm or less 1
Note : There are two types of nozzles-one for high-speed component placement
and the other for middle-size odd-shaped component placement.
Although the nozzles for high-speed and middle-size odd-shaped
components can be used together, the nozzles for middle-size
odd-shaped components must be attached, leaving one out of every two
pitches empty due to the location of the diffusion plates.
Nozzle for High-Speed Component Placement :
The diameter is φ6 mm or less. This nozzle is used for 0603
components (Size : 0603 to 20
× 20 mm).
Nozzle for Middle-Size odd-shaped Component Placement :
The diameter is φ12 mm or less. The nozzle end is processed
according to the applicable components.
The nozzle can be used for the component size of up to 44 × 44
mm.
10. Number of
Stocked Nozzles
Max. 12 nozzles can be stored for each head.
Notes : (a) When some nozzle stockers are mounted additionally (optional
specifications), up to 48 nozzles can be stored for each head.
(b) When the vacuum nozzles for the middle-size odd-shaped
components are used, the nozzle stockers (a housing in which eight
nozzles can be stored) is required for the nozzles.
0305-002 Tg0846-WO-SP
0608-003 Tg1333-WO-SP 0707-002
9
SS-1189
11. Number of
Installable Feeders
(1) Tape Feeders
Max. 100 feeders (25 feeders × 4 feeder bases)
(When only 8 mm dual tape feeders are used)
Ref. : Up to 200 types of components can be used.
Max. 100 feeders (when only 12/16 mm tape feeders are used)
Max. 48 feeders (when only 24/32 mm tape feeders are used)
Max. 32 feeders (When only 44/56 mm tape feeders are used)
Max. 24 feeders (When only 72 mm tape feeders are used)
(2) Vibratory Stick Feeders
Max. 4 per feeder base
Ref. : Up to 6 carrier sticks can be installed on one vibratory stick feeder.
Notes : (a) The number of installable feeders varies according to the
combination of the reel width for the taping and the feeders.
(b) Use the tape feeders used prepared specially for GXH series.
The tape, dual tape and bulk feeders for the other machines cannot
be used.
Supply Pressure 0.45 to 0.69 MPa (4.6 to 7 kgf/cm ²)
Set Pressure 0.45 MPa (4.6 kgf/ cm²)
Note : Min. 0.4 MPa (4.1 kgf/ cm²) of air pressure is
necessary for operation.
12. Air Supply
Note : Use the dry and clean air as follows
Moisture : Dew Point −17°C or lower (Atmospheric Pressure)
Oil : 0.1 mg/m
3
or less (ANR)
Dust : Solid Material 0.01 μm or less
13. Air Consumption Approx. 160 L/min (normal condition)
Note : Approximately 40 L/min (normal condition) is consumed while one
feeder base is moving up.
14. Vacuum Pressure
−93 kPa (70 cmHg)
15. Environmental
Condition
Temperature : 20
±
10
°
C
Humidity : 30 to 80 % (Avoid dew condensation)
Note : When the ambient temperature rises more than the surface of the
machine, dew may condense under the condition described below.
Note that dew condensation may cause the machine to break down.
Condition of Dew Condensation
Dew may condense when the differences (based on "Humidity (%)")
between the ambient and surface temperatures of the machine reach the
values or more in the table below.
16. Dimensions
Approx. 2,664 (width) × 2,350 (depth) × 1,400 (height) mm
Notes : (a) The width includes the Carrier / Rejected conveyor.
(b) The depth becomes 2,580 mm when the Bank Feeder Change Cart
is included.
(c) The height becomes 2,100 mm when the light tower is included.
17. Mass Approx.
3,000 kg (excl. the Bank Feeder Change Carts and the tape feeders)
0707-002
Humidity
(%)
Differences between Ambient and Surface
Temperatures of Machine (Ambient
Temperature > Surface Temperature)
80 3 °C or more
70 6 °C or more
60 8 °C or more
50 10 °C or more
40 14 °C or more
30 18 °C or more
10
SS-1189
18. Environmental
Requirements for
Bank Feeder
Cange Cart
Floor Gradient : 10/1000 or less
Note : The casters of the cart shall be rigid enough to move smoothly.
0707-002
