28 Component Feeding Waffle Pack Changer (WPC) The waffle-pa ck changer makes the flatpack IC av ail- able in the waffle-pack trays to avoid unnecessary loss of time during stora ge and automatic changing of the waffle-p…
27
Component Feeding
Matrix Tray Changer (MTC)
Technical Data
Electrical ratings
Tray supply 1 (XL) Tray supply 2
Dimensions
Length x width
Height
1305 x 600 mm²
1490 mm for 830 mm PCB transport height
1560 mm for 900 mm PCB transport height
1590 mm for 930 mm PCB transport height
1640 mm for 950 mm PCB transport height
Weight (basic equipment) approx. 500 kg (with PCB magazines and waffle-pack tray
carriers)
Weight (fully equipped) approx. 534 kg (with components)
Weight (moving mass) approx. 80 kg approx. 43.5 kg
PCB magazine size (L x W x H) 391.2 x 305.6 x 93.3 mm³ 352.7 x 154.8 x 133.8 mm³
PCB magazine weight
(fully equipped)
(without waffle-pack tray carrier)
approx. 11 kg
approx. 1.7 kg
approx. 7.5 kg
approx. 1.35 kg
Weight of the
waffle-pack tray carrier
850 g 150 g
Dimensions of the
waffle-pack tray carrier
(L x W x H)
386.5 x 295.8 x 11.1 mm³ 371 x 146 x 10.1 mm³
Distance from PCB magazine to
magazine
96 mm 135 mm
Distance from level to level 12 mm 11.8 mm
Storage capacity 30 XL waffle-pack tray
carriers with 60 JEDEC or
30 special magazines of
maximum size
40 waffle-pack tray carriers
with 40 JEDEC
waffle-pack trays
Changeover time (over 5 levels) approx. 2 s approx. 1.5 s
Max. height of component and
waffle tray, including tolerances
all levels filled
one level free
two levels free
8.5 mm
19.5 mm
31.5 mm
8.5 mm
19.5 mm
-
Supply voltage 3 x 400 VAC, 50 Hz (Europe)
3 x 208 VAC, 60 Hz (USA)
Total power 1.5 kW
Apparent power 3.85 kVA
Rated current 2.7 A at 3 x 400 VAC
4.2 A at 3 x 208 VAC
Fuses 3 x 16 A
Rated power consumption
of the largest consumer
2 A
28
Component Feeding
Waffle Pack Changer (WPC)
The waffle-pack changer
makes the flatpack IC avail-
able in the waffle-pack trays
to avoid unnecessary loss of
time during storage and
automatic changing of the
waffle-pack trays. Program-
mable, random access to up
to 28 waffle-pack trays also
considerably increases the
range of components that
can be made available. The
waffle pack changer has an
integral chassis, and is easy
to move to other locations. It
is supplied with the PCB con-
veyor height implemented for
the machines, but can also
be adapted for the 830, 900,
930 and 950 mm PCB con-
veyor heights with just a few
simple operations. There are
4.5 locations for 30 mm width
S feeder modules available
on the component table.
Location options
for the WPC:
location 2
29
Component Feeding
Waffle Pack Changer (WPC)
Technical Data
Electrical ratings
Dimensions (LxW) 1560 x 360 mm²
Height
830 mm ± 15 mm PCB transport height
900 mm ± 15 mm PCB transport height
930 mm ± 15 mm PCB transport height
950 mm ± 15 mm PCB transport height
1360 mm ± 15 mm
1430 mm ± 15 mm
1460 mm ± 15 mm
1480 mm ± 15 mm
Weight approx. 240 kg
Load per unit area 4.19 kN/m²
Dimensions of the waffle-pack tray carrier (L x W x H) 360 x 260 x 6 mm³
Weight of the waffle-pack tray carrier 0.8 kg
Dimensions of the waffle-pack tray including components 341 x 235 x 15 mm³
max. 341 x 235 x 23 mm³
Weight of the waffle-pack tray carrier including the waffle-pack tray and
components max. 1.2 kg
Storage capacity max. 28 waffle-pack tray
carriers
Total weight of the 28 waffle-pack tray carriers 27.6 kg
Weight of the magazine storage unit, waffle-pack tray carriers, waffle-
pack trays and components max. 50 kg
Changeover time for waffle-pack tray carrier
over 1 level
over 10 levels
over 27 levels
1.9 s
2.3 s
2.9 s
Supply voltage 3 x 208 VAC ± 5%; 50/60 Hz (U.S.A.)
3 x 230 VAC ± 5%; 50/60 Hz
3 x 380 VAC ± 5%; 50/60 Hz
3 x 400 VAC ± 5%; 50/60 Hz (European version)
3 x 415 VAC ± 5%; 50/60 Hz
Nominal apparent power 800 VA
Rated current 0.7 A at 3 x 400 VAC
Fuses 3 x 10 or 3 x 16 A
