3
SIPLACE D3
Contents
Overview of the Technical Data 5
Machine Description 6
Machine Performance 7
Modular Machine Concept 8
Sample Configuration 9
Placement Heads 10
Overview 10
Standard Functions / Options 11
Collect&Place Heads 12
TwinHead 13
Nozzle Changers 14
Technical Data 15
PCB Conveyor 16
Overview 16
Technical Data 17
PCB Warpage 18
PCB Barcode for Product-Controlled Production
(Option) 19
Component Feeding 20
Component Changeover Table 20
Technical Data 21
S Tape Feeder Modules 22
Alternative SIPLACE Feeder Modules 23
Dummy Feeder Modules 24
Waffle-Pack Tray Holder 25
Matrix Tray Changer (MTC) 26
Technical Data 27
Waffle Pack Changer (WPC) 28
Technical Data 29
Digital Vision System 30
Checking the Component Quality 31
Vision Sensor Technology 32
PCB Position Recognition 32
4
SIPLACE D3
Contents
Bad Board Recognition 33
2D Coplanarity Laser Module 34
SIPLACE Software 35
SIPLACE Service 37
Maximum Quality in Production 39
Technical Data 40
Electrical Ratings and Compressed Air Supply 40
Electrical Connection, Interfaces and Compressed Air Connection 41
Dimensions and Set-Up Conditions 42
Dimensions of the Placement System 43
Placement System’s Center of Gravity 43
Maneuvering Radii for CO Tables and MTC 44
Maneuvering Radius for WPC 45
Spacing Distances for Single Conveyor 46
Spacing Distances for Flexible Dual Conveyor 47
Spacing Distances for Machine and MTC 48
Spacing Distances for Machine and WPC 49
Transport and Delivery Configuration 50
Standard List 51
List of Options 52
List of Languages 53
Awards 54
5
Overview of the Technical Data
Placement rate
a
IPC value
Benchmark value
Theoretical value
a) See page 7 for a definition of the output values
37,600 comp./h
40,400 comp./h
61,000 comp./h
Component range 0201 - 200 x 125 mm²
Placement accuracy
b
/
angular accuracy
b) The accuracy value was measured using the vendor-neutral IPC standard
± 22 µm, ± 0.05° / (3),
± 30 µm, ± 0.07° / (4)
Feeder module types Tape feeder modules, waffle-pack trays, stick maga-
zine feeders, bulk cases, dip modules, application-
specific OEM feeder modules
Feeding capacity 180 tracks with 3 x 8 mm S
PCB format max. 610 x 508 mm²
PCB thickness 0.3 - 4.5 mm (others available on request)
PCB weight max. 3 kg
Camera 6 illumination levels
SIPLACE D3 machine colors
Machine protection: Anthracite
(SIPLACE color code SN 614)
Hoods: Light Basic
(SIPLACE color code SN 700)
Machine protection: Light Basic
(SIPLACE color code SN 700)
Hoods: Anthracite
(SIPLACE color code SN 614)
