SIPLACE Pro 17.0 (R19-2) / Version Description 11/2019 Edition
15
Restricting Clearance of Pickup Threshold Errors
In the Reject Thresholds group of the Component Editor, a checkbox has been added that allows
only users with activity level “Advanced Production” to clear occurring pickup threshold errors.
4.2 New License “Single Component Traceability from Wafer –
Machine Connection”
If the single component traceability from wafer functionality (SCT) has been activated via the
Traceability system checkbox in the SIPLACE Pro Station Editor, the new license “Single
Component Traceability from Wafer – Machine Connection” is required.
Restrictions
– If SMT traceability is used at the same time, two licenses are required: the “SIPLACE ASM
Traceability – Machine Connection” license and the new “Single Component Traceability from
Wafer – Machine Connection” license.
4.3 Smart Pin Support for TX V2 – Enhancements
The Smart Pin Support for the TX V2 has been enhanced by the functions described below.
Using Partly Accessible Nozzle Magazines
If the TX V2 is configured with Smart Pin Support, the outermost nozzle magazines cannot be
reached by the PCB camera to read the fiducials. Instead of blocking the whole nozzle magazine
by default, it is now possible to use all those nozzles that are within reach of the PCB camera.
NOTICE
Even though SIPLACE Pro version 16.1 (station software version 712) does support
Smart Pin Support for the TX V2, with this older version nozzle magazines out of reach
are fully blocked.
Restrictions
– This functionality is only available for the magazines 4xxx(20) / 6xxx(20), item no.
[03218226-xx] for the C&P20 P2 head and 20xx(20), item no. [03226630-xx] for the CPP
head. It is not available for the magazines 28xx(9) and 20xx(12).
– This functionality is not available for TwinHead magazines.
Combination of Smart Pin Support with TwinHead on TX V2
The combination of Smart Pin Support with a TwinHead on the TX V2 is supported.
4.4 New Fiducial Type “Edge”
In the Fiducial Type Editor of SIPLACE Pro Desk, the fiducial type “Edge” has been introduced.
With this new fiducial type, it is possible to define the length of an X-coordinate, which is useful for
LED alignments.
SIPLACE Pro 17.0 (R19-2) / Version Description 11/2019 Edition
16
4.5 ASM Production Planner in SIPLACE Pro Optimizer Toolkit
SIPLACE Pro supports Production Planner. Detailed information can be found in the ASM
Production Planner User Guide, item no. [00900196-xx].
4.6 New Nozzle Types for C&P20 P, C&P20 P2, and CPP Heads
The following new nozzle types have been introduced:
– Ceramic nozzles for LED centering for C&P20 P / C&P20 P2:
– 4064 / 6064, item no. [03218030-xx]
– 4065 / 6065, item no. [03218163-xx]
– 4113 / 6113, item no. [03215882-xx]
– Nozzle 2204 for CPP with new length (please refer to section 4.7.)
4.7 Changes of Nozzle Length for Nozzle 2204
The length of nozzle 2204 has changed from 15.0 mm to 14.8 mm.
NOTICE
The old nozzles with 15.0 mm length are no longer sold.
4.8 OSC Package - Enhancements
Detailed information on the OSC Package features can be found in the OSC Package User Guide,
item no. [00198374-xx].
The main enhancements made for the OSC Package Option in SIPLACE Pro are listed in the
overview below.
Supported Component Weight on Twin VHF Increased
The maximum weight of a component that can be placed with a Twin VHF has increased from
100 g (component + nozzle or gripper) to 240 g.
For components heavier than 100 g, new reduction options have been introduced. The acceleration
can now be reduced by 5%, 4%, 3%, 2%, and 1%, additionally to the reduction options already
implemented (100%, 75%, 50%, 25%, 10%).
Supported Component Height on Twin VHF Increased
The Twin VHF can place taller components using the “sequential placement” placement mode.
With this, the maximum body height of a component that can be placed with a Twin VHF has
increased from 38 mm to 46 mm (additional to 4 mm centering pins).
SIPLACE Pro 17.0 (R19-2) / Version Description 11/2019 Edition
17
4.9 Placement Improvements – Automatic Pin 1 Recognition
To save time during placement, it is possible to limit the check period and check frequency per
component for the orientation check during position check.
For this, the Check pickup orientation on component change option in the Object Properties of
the Component Editor has been extended. If this option is activated, the check mode can be set to
either Manually by user or to Automatic. If the Automatic mode is selected, three further options
can be specified: the number of measurements, the checking period, and the check sequence.
4.10 Automatic Pitch Detection
The automatic pitch detection can be activated in the Feeder tab of the Component Editor via the
Auto pitch checkbox. In the new Cycle entry field, the number of cycles can be entered. The
range for the automatic pitch detection cycle is 50 – 5000, with a default value of 500. The
automatic pitch option is independent of the selected feeder.
4.11 Changing Users for a Running SIPLACE Pro Desk Session
The user privilege Log Off Other User has been introduced, with which it is possible to change the
user for a running SIPLACE Pro Desk instance without terminating the session.
The user can either be changed in a running SIPLACE Pro Desk session via the
Tools - Log On as An Other User option or the Log-on/Log-off option, or in a locked session via
the logon screen.
