SIPLACE Pro 17.0 (R19-2) / Version Description 11/2019 Edition
3
Contents
1 Introduction 5
1.1 System Overview ................................................................................................. 6
2 Scope of Delivery 7
2.1 Packages ............................................................................................................. 7
2.2 Languages ........................................................................................................... 7
2.3 Licenses ............................................................................................................... 8
3 Prerequisites 10
3.1 Supported Station Software Versions and Machine Types ................................ 10
3.2 Supported DEK Printer Software Versions and Printer Types ........................... 12
3.3 Supported Feeder Types ................................................................................... 12
4 Features of SIPLACE Pro 17.0 14
4.1 Board Editor / Grid Board Editor – Enhancements ............................................ 14
4.2 New License “Single Component Traceability from Wafer – Machine
Connection” ....................................................................................................... 15
4.3 Smart Pin Support for TX V2 – Enhancements ................................................. 15
4.4 New Fiducial Type “Edge”.................................................................................. 15
4.5 ASM Production Planner in SIPLACE Pro Optimizer Toolkit ............................. 16
4.6 New Nozzle Types for C&P20 P, C&P20 P2, and CPP Heads ......................... 16
4.7 Changes of Nozzle Length for Nozzle 2204 ...................................................... 16
4.8 OSC Package - Enhancements ......................................................................... 16
4.9 Placement Improvements – Automatic Pin 1 Recognition ................................. 17
4.10 Automatic Pitch Detection .................................................................................. 17
4.11 Changing Users for a Running SIPLACE Pro Desk Session ............................. 17
5 Restrictions 18
6 Troubleshooting 20
6.1 Problems and Solutions ..................................................................................... 20
7 Appendix 21
7.1 ASM Error Reporter Service .............................................................................. 21
SIPLACE Pro 17.0 (R19-2) / Version Description 11/2019 Edition
5
1 Introduction
SIPLACE® Pro 17.0 (R19-2) is the programming system for SIPLACE placement. The placement
programs for the placement lines are prepared, generated and optimized with SIPLACE Pro. The
Release-Tag displays in which ASM Release the current product has been released.
Example: (R19-2) → 2
nd
Release, 2019.
Additionally, the SIPLACE Pro programming system supports DEK printing solutions. ASM Printer
Programming extends the existing SIPLACE Pro programming system by adding functionality for
editing print process data for DEK printing systems. All features of the previous SIPLACE Pro
versions are specified in the SIPLACE Pro Feature Description, item no: [00197739-xx].
NOTICE
Please note the following:
As a user of the statistic functionalities of ASM's software in this ASM's product, you may
process personal data. Processing - including analyzing - personal data is subject to
data protection and other laws, which might impose restrictions and that might differ by
country. You are responsible to ensure that such processing is performed in compliance
with data protection and other laws applicable to you and your company. We therefore
would like to urge you to consult your supervisor or your legal department as regards the
data protection and other legal requirements to be followed.
