SIPLACE Pro 17.0 (R19-2) / Version Description 11/2019 Edition 9 License Type Factory Single Object Floating Lines Long Board Option – Machine C onnection (with station software versi on < 709) Long Board Option up to…
SIPLACE Pro 17.0 (R19-2) / Version Description 11/2019 Edition
8
2.3 Licenses
The available licenses are listed in the following table.
License
Type
Factory
Single
Object
Floating
Lines
SIPLACE Pro Server / Desk (includes OIS /
SIS)
✓
SIPLACE Pro Machine Connection
✓
✓
ASM Printer Programming
✓
✓
SiCluster
✓
SiCluster Professional
✓
SiCluster Professional – Machine
Connection
✓
✓
SiCluster Multiline – Machine Connection
✓
✓
Split Table Mode – Machine Connection
✓
✓
SIPLACE ASM Traceability – Machine
Connection
✓
✓
Single Component Traceability from Wafer
– Machine Connection
✓
✓
DEK ASM Traceability – Machine
Connection
✓
✓
SIPLACE Vision Teach Station
✓
Whispering Down The Line
Notice: This license is not needed if IPC-
HERMES-9852 is activated on all devices
between first and last placement station.
✓
✓
Automatic Program Download (PCB-
Barcode)
✓
✓
Station Wise Download – Machine
Connection
✓
✓
Borrow Performance – Machine
Connection
✓
✓
Reading Barcode recognition with PCB
Camera
Notice: This license is required for each
station in the line.
✓
✓
Alternative Components
✓
✓
Random Setup
✓
✓
SIPLACE Pro 17.0 (R19-2) / Version Description 11/2019 Edition
9
License
Type
Factory
Single
Object
Floating
Lines
Long Board Option – Machine Connection
(with station software version < 709)
Long Board Option up to 850 mm –
Machine Connection
(with station software version 7xx)
Long Board Option up to 1500 mm –
Machine Connection
(with station software version 709 and
higher)
Notice: The license is required for each
station in the line.
✓
✓
✓
✓
✓
✓
SIPLACE LED Pairing – Machine
Connection
✓
✓
Flexible Dual Lane – Machine Connection
Bound
✓
✓
Micron 15u3Sigma – Machine Connection
✓
✓
Vision OSC Package – Machine
Connection
✓
✓
SIPLACE LED Centering – Machine
Connection
✓
✓
MES - Process Interlocking - SIPLACE -
Machine Connection
✓
SIPLACE PCB Inspection – Machine
Connection
✓
Table 2-1: Available Licenses
Definition of the License Types
Factory
This license type is valid for the entire production run and is not assigned to a license server.
Single
This license type is valid in connection with a (single) station.
Object
This license type is bound to an object, in this case to the machine id. The license is unbound
until the first download to a station which requires this license type. Thereafter the license is
permanently bound to the machine id of this station.
Floating
This license type is fetched from a license server by the application and then released again
when the application is terminated. However, the number of licenses on the license server is
limited.
Lines
This license type is assigned to the placement line.
SIPLACE Pro 17.0 (R19-2) / Version Description 11/2019 Edition
10
3 Prerequisites
NOTICE
System requirements
The Support Media checks the necessary system requirements of your system and
installs these. Amongst others e.g. Microsoft .NET Framework, the ASM License
Manager, the ASM Error Reporter Service and the ASM Operation Manager.
The use of the ASM Support Media 2.10 (R19-2) is mandatory.
The system requirements (supported operating systems and database variants) and an
overview of the interoperable products can be found in the ASM Support Media 2.10
(R19-2) Software Version Description, item no. [00900052-xx].
SIPLACE Pro requires an NTFS partition for the installation. FAT or FAT32 file systems are not
supported.
3.1 Supported Station Software Versions and Machine Types
Station Software
Version
Machine Types
713
DX-series: DX1, DX2
SX-series: SX1/SX2, SX1/SX2 V2, SX1/SX2 V3
X-series S: X2 S, X3 S, X4 S, X4 S micron,
X4i S, X4i S micron
CA-series: CA4, CA4 V2
TX-series: TX1, TX2, TX2i, TX2i W, TX2 micron,
TX2i micronTX1 V2, TX2 V2, TX2i V2
E-series: E1 R, R1 L
712
DX-series: DX1, DX2
SX-series: SX1/SX2, SX1/SX2 V2
X-series S: X2 S, X3 S, X4 S, X4 S micron,
X4i S, X4i S micron
CA-series: CA4, CA4 V2
TX-series: TX1, TX2, TX2i, TX2i W, TX2 micron,
TX2i micronTX1 V2, TX2 V2, TX2i V2
E-series: E1 R, R1 L
711
DX-series: DX1, DX2
SX-series: SX1/SX2, SX1/SX2 V2
X-series S: X2 S, X3 S, X4 S, X4 S micron,
X4i S, X4i S micron
CA-series: CA4, CA4 V2
TX-series: TX1, TX2, TX2i, TX2 micron, TX2i micron
TX1 V2, TX2 V2, TX2i V2
E-series: E1 R, R1 L
