5.1 "Save / Load" Tab

(5) When [Delete <<] button is pressed, the following "Confirmation"

dialog box opens.

Fig. 14 "Confirmation" Dialog Box for Confirmation to Deletion

(6) When the [OK] button is pressed, the deletion starts.

18 Tg0969-PM-SO0310-001

19 Tg0969-PM-SO0311-002 A(M801YRK-A1001)

6. Materials

6.1 Parts Locations

Service Panel

-marked area is specially specified.

Note

Floppy Disk Drive (A-DRIVE)

Front View
