3.4. Schedule Task manual operation from the Schedule Task
monitor
In a reset state, you can execute "Shaft Cleaning Blow", "Nozzle Condition Check" and
"Vacuum Check" manually on the [Monitor] – [Schedule Task] tab screen.
Even with a manual execution of Schedule Task, execution results (OK and NG) are
displayed to the Schedule Task monitor.
(Attention 1) You can execute "Nozzle Condition Check" by clicking the "Check Nozzles"
button on the [Setup] screen.
(Attention 2) You can execute "Shaft Cleaning Blow" by the "Cleaning Blow" button on the
[Unit] – [Head] tab.
(Attention 3) About the dialog screen and the operation method to execute Schedule Task by
manual operation, refer to the manual text of each model.
Fig.3.5 The Schedule Task monitor screen
SMT Software Engineering Group
IM Operations YAMAHA MOTOR CO., LTD.
MDOC-SOFT50138
9/13
3.5. Update of “Schedule Task Last Date” by the Schedule Task
manual execution
When "Update with manual operation" of [Machine (VmSpec)] - [Specification Information] -
[Schedule Specification] is "ON", “Schedule Task Last Date” is updated even with a manual
operation. When the “Schedule Task Last Date” is updated, cycle calculation is restarted for
the next Schedule Task execution.
When "Update with manual operation" of [Machine (VmSpec)] - [Specification Information] -
[Schedule Specification] is "OFF", the “Schedule Task Last Date” is not updated with Schedule
Task by manual operation. “Schedule Task Last Date” is updated only when the Schedule
Task of automatic cycle is executed.
(Attention 1) Refer to "4 Setting" for the set of "Schedule Task Last Date".
Fig.3.6 Schedule Task monitor screen
SMT Software Engineering Group
IM Operations YAMAHA MOTOR CO., LTD.
MDOC-SOFT50138
10/13
“Schedule Task Last Date” is updated according to the following conditions.
Condition of the Schedule Task start Check Item Schedule Task Last Date
Vacuum Check
Nozzle Condition Check
When
“Check Item” of the Schedule
Task is executed by
the automatic
cycle.
Shaft Cleaning Blow
Updated.
IfnotScheduleTaskisnot
executedbecauseofsome
hardwaretroubles,it’snot
updated.
Vacuum Check
Nozzle Condition Check
When
“Check Item” of the Schedule
Task is executed by
the manual
operation.
(It is not related to setting of "Update
with manual operation".)
Shaft Cleaning Blow
Not updated
