0$&+,1( 3& 3&(1&/26 85( 5.12 Technical Reference Manual Chapter Issue 3 May 03 PNP / PCI Configuratio n PC Health S tatus Frequency/V oltage Control Menu Sub Menu Parameter Setting Parameter Setting PNP…
0$&+,1(3&
3&(1&/2685(
Chapter Issue 3 May 03 Technical Reference Manual 5.11
Power Management
Parameter Setting
Power-Supply Type AT
Power Management User Define
Video Off Method DPMS
Video Off In Suspend Yes
Suspend Type Stop Grant
MODEM Use IRQ N/A
HDD Power Down Disabled
Soft-Off By PWRBTN Instant-Off
PowerOn by LAN Disabled
PowerOn by Modem Disabled
PowerOn by Alarm Disabled
CPU Thermal-Throttling 50%
Primary IDE 0 Disabled
Primary IDE 1 Disabled
0$&+,1(3&
3&(1&/2685(
5.12 Technical Reference Manual Chapter Issue 3 May 03
PNP / PCI Configuration
PC Health Status
Frequency/Voltage Control
Menu Sub Menu
Parameter Setting Parameter Setting
PNP OS Installed No
Reset Configuration Data Disabled
IRQ Resources IRQ-3 Assigned to PCI/ISA PnP
IRQ-4 Assigned to PCI/ISA PnP
IRQ-5 Assigned to Legacy ISA
IRQ-7 Assigned to PCI/ISA PnP
IRQ-9 Assigned to Legacy ISA
IRQ-10 Assigned to PCI/ISA PnP
IRQ-11 Assigned to PCI/ISA PnP
IRQ-12 Assigned to PCI/ISA PnP
IRQ-14 Assigned to PCI/ISA PnP
IRQ-15 Assigned to Legacy ISA
DMA Resources DMA-0 Assigned to PCI/ISA PnP
DMA-1 Assigned to PCI/ISA PnP
DMA-3 Assigned to PCI/ISA PnP
DMA-5 Assigned to PCI/ISA PnP
DMA-6 Assigned to PCI/ISA PnP
DMA-7 Assigned to PCI/ISA PnP
PCI/VGA Palette Snoop Disabled
Parameter Setting
CPU Warning Temperature Disabled
Parameters Setting
Auto Detect DIMM/PCI Clk Enabled
Spread Spectrum Disabled
CPU Clock Ratio X 3
0$&+,1(3&
1(;7029(
Chapter Issue 3 May 03 Technical Reference Manual 5.13
NEXTMOVE NextMove is installed in the PC enclosure. However, NextMove is a motion
controller and its functions are described fully in the Machine Controller chapter
of this manual.
The NextMove card sits on the ISA Bus and is itself controlled by the central
processor unit (CPU) in the PC enclosure. This arrangement allows the CPU
to control functions such as the operator interface (the MMI) and provide
general housekeeping functions along with general PC control whilst the Next-
Move card, with its own on-board CPU specifically controls all machine motion.
