0$&+,1 (3& 5($53$1( /&211(& 725)81&7,21 6 Chapter Issue 3 May 03 Technical Reference Manual 5.23 NOTE The pin-out s on this connector do not mat ch pin for pin on t he AutoFlex board connectors. 4…
0$&+,1(3&
5($53$1(/&211(&725)81&7,216
5.22 Technical Reference Manual Chapter Issue 3 May 03
PCIB 40 ISA 9 (AutoFlex Tooling Option)
3SK16 (50 Way D Type)
PIN 38 DIG.IN.5 PIN 38 DIG.IN.4
PIN 39 DIG.IN.7 PIN 39 DIG.IN.10
PIN 40 DIG.IN.9 PIN 40 DIG.IN.8
PIN 41 DIG.IN.11 PIN 41 DIG.IN.14
PIN 42 DIG.IN.13 PIN 42 DIG.IN.12
PIN 43 DIG.IN.15 PIN 43 DIG.IN.18
PIN 44 DIG.IN.17 PIN 44 DIG.IN.16
PIN 45 DIG.IN.19 PIN 45 DIG.IN.22
PIN 46 DIG.IN.21 PIN 46 DIG.IN.20
PIN 47 DIG.IN.23 PIN 47 GND
PIN 48 +5V O/P PIN 48 GND
PIN 49 +5V O/P PIN 49 RELAY NO
PIN 50 RELAY N/C PIN 50 RELAY COM
Pin No. Signal Pin No. Signal
1 0V 26 Group 2 Bit 4 Tooling Data
2 Group 0 Bit 1 Tooling Data 27 Group 2 Bit 7 Tooling Data
3 Group 0 Bit 4 Tooling Data 28 Group 3 Bit 0 Tooling Data
4 Group 0 Bit 7 Tooling Data 29 Group 3 Bit 3 Tooling Data
5 Group 1 Bit 0 Tooling Data 30 Group 3 Bit 6 Tooling Data
6 Group 1 Bit 3 Tooling Data 31 Group 4 Bit 3 Board Data
7 Group 1 Bit 6 Tooling Data 32 P (Power On Switch)
8 Group 4 Bit 1 Pin Set 33 +12V
9 Group 2 Bit 2 Tooling Data 34 0V
10 Group 2 Bit 5 Tooling Data 35 Group 0 Bit 2 Tooling Data
11 0V 36 Group 0 Bit 5 Tooling Data
12 Group 3 Bit 1 Tooling Data 37 0V
13 Group 3 Bit 4 Tooling Data 38 Group 1 Bit 1 Tooling Data
14 Group 3 Bit 7 Tooling Data 39 Group 1 Bit 4 Tooling Data
15 Group 4 Bit 4 Board Data 40 Group 1 Bit 7 Tooling Data
16 C (Reduced Power Switch) 41 Group 2 Bit 0 Tooling Data
17 +5V 42 Group 2 Bit 3 Board Select
18 Group 0 Bit 0 Tooling Data 43 Group 2 Bit 6 Board Select
19 Group 0 Bit 3 Tooling Data 44 Group 4 Bit 2 Pin Set
20 Group 0 Bit 6 Tooling Data 45 Group 3 Bit 2 Tooling Data
21 Group 4 Bit 0 Pin Set 46 Group 3 Bit 5 Tooling Data
22 Group 1 Bit 2 Tooling Data 47 0V
23 Group 1 Bit 5 Tooling Data 48 Group 4 Bit 5 Board Data
Connector 3SK12 Left Row Connector 3SK12 Right Row
0$&+,1(3&
5($53$1(/&211(&725)81&7,216
Chapter Issue 3 May 03 Technical Reference Manual 5.23
NOTE
The pin-outs on this connector do not match pin for pin on the AutoFlex board
connectors.
4 Channel RS232 Comms Card ISA 7 (Not Fitted In All Machines)
4 Channel Comms 3SK27 (37 Way D Type)
24 0V 49 -12V
25 Group 2 Bit 1 Tooling Data 50 +5V
Pin No. Signal Pin No. Signal
Pin No. Signal Pin No. Signal
1N/C 20RI3
2 DCD3 21 DTR3
3 GND 22 DSR3
4CTS3 23RTS3
5RX3 24TX3
6 RI4 25 DCD4
7DTR4 26GND
8DSR4 27CTS4
9RTS4 28RX4
10 TX4 29 RI2
11 DCD2 30 DTR2
12 GND 31 DSR2
13 CTS2 32 RTS2
14 RX2 33 TX2
15 RI1 34 DCD1
16 DTR1 35 GND
17 DSR1 36 CTS1
18 RTS1 37 RX1
19 TX1
0$&+,1(3&
5($53$1(/&211(&725)81&7,216
5.24 Technical Reference Manual Chapter Issue 3 May 03
SBC Breakout Panel ISA 1
Parallel Printer 3SK06 (25 Way D Type)
NOTE
* denotes low active.
3SK39 (9 Way D Type)
Not Used
PCA-6180 SBC ISA 2/3
Video Connector 3SK05 (15 Way Condensed D Type)
Pin No. Signal Pin No. Signal
1 /Strobe 14 /Auto Feed
2 Data Bit 0 15 /ERROR
3 Data Bit1 16 /INIT
4 Data Bit 2 17 /SLCT IN
5 Data Bit 3 18 GND
6 Data Bit 4 19 GND
7 Data Bit 5 20 GND
8 Data Bit 6 21 GND
9 Data Bit 7 22 GND
10 ACK* 23 GND
11 BUSY 24 GND
12 PE (Paper End) 25 GND
13 SLCT
Pin No. Signal Pin No. Signal
1Analog Red 9Vcc
2 Analog Green 10 Vertical Sync Ground
3 Analog Blue 11 N/C
4N/C 12SDT
5 Horizontal Sync Ground 13 Horizontal Sync
6 Red Ground 14 Vertical Sync
7 Green Ground 15 SCK
8 Blue Ground
