0$&+,1( 3& 5($53$1 (/&211(& 725)81&7 ,216 5.26 Technical Reference Manual Chapter Issue 3 May 03 V ision PC Adaptor Card ISA 5 Camera Lighting 3SK10 (9 Way D T ype) Camera Power and T rigger 3PL1 …
0$&+,1(3&
5($53$1(/&211(&725)81&7,216
Chapter Issue 3 May 03 Technical Reference Manual 5.25
RS232 Touchscreen COM 1 3PL03 (9 Way D Type)
Keyboard Connector 3SK04 (6 Way Mini-DIN)
Mouse Connector 3SK07 (6 Way Mini-DIN)
Ethernet UTP Connector 3SK02 (8 Way RJ45)
USB Connectors 0,1,2, & 3 3SK34, 35, 36 & 37
Not Used
Pin No. Signal Pin No. Signal
1DCD 6DSR
2RXD 7RTS
3TXD 8CTS
4DTR 9Ring Ind
5GND
Pin No. Signal
1 Keyboard Data
2Mouse Data
30V
4+5 Volts
5 Keyboard Clock
6Mouse Clock
Pin No. Signal
1 Keyboard Data
2 Mouse Data
30V
4+5 Volts
5 Keyboard Clock
6 Mouse Clock
Pin No. Signal Pin No. Signal
1 +ve Transmit 5 Not Used
2 -ve Transmit 6 -ve Receive
3 +ve Receive 7 Not Used
4 Not Used 8 Not Used
0$&+,1(3&
5($53$1(/&211(&725)81&7,216
5.26 Technical Reference Manual Chapter Issue 3 May 03
Vision PC Adaptor Card ISA 5
Camera Lighting 3SK10 (9 Way D Type)
Camera Power and Trigger 3PL11 (9 Way D Type))
3SK40 (9 Way D Type)
Not Used
Vision Card PCI 3
Camera 0 3SK08 (15 Way Condensed D Type)
Camera 1 3SK09 (15 Way Condensed D Type)
Not Used
Pin No. Signal Pin No. Signal
1 Ground 6 0V
2Tx 70V
3Rx 8 24 V US
4 Strobe 9 24V US
5 Not Used
Pin No. Signal Pin No. Signal
1 Not Used 6 0V
2 Not Used 7 Not Used
3 Not Used 8 +12 V Trig
4! Trig 9 24V US
5 Not Used
Pin No. Signal Pin No. Signal
1 Not Used 9 Not Used
2 Video Input 10 Not Used
3 Not Used 11 Not Used
4 +12V dc (Camera) 12 Not Used
5 Camera GND 13 Not Used
6 Not Used 14 Not Used
7 Video GND 15 Not Used
8 Not Used
0$&+,1(3&
5($53$1(/&211(&725)81&7,216
Chapter Issue 3 May 03 Technical Reference Manual 5.27
Vision Card PCI 2 (Gold Camera Option)
Camera 0 3SK30 (15 Way Condensed D Type)
Camera 1 3SK31 (15 Way Condensed D Type)
Not Used
Pin No. Signal Pin No. Signal
1 Not Used 9 Not Used
2 Video Input 10 Not Used
3 Not Used 11 Not Used
4 +12V dc (Camera) 12 Not Used
5 Camera GND 13 Not Used
6 Not Used 14 Not Used
7 Video GND 15 Not Used
8Not Used
