0$&+,1( 3& 5($53$1 (/&211(& 725)81&7 ,216 5.22 Technical Reference Manual Chapter Issue 3 May 03 PCIB 40 I SA 9 (AutoFl ex T ooling Option) 3SK16 (50 W ay D T ype) PIN 38 DIG .IN.5 PIN 38 DIG .IN.…
0$&+,1(3&
5($53$1(/&211(&725)81&7,216
Chapter Issue 3 May 03 Technical Reference Manual 5.21
NextMove ISA 10
3SK12 Yamaichi 100 Way Connector
Connector 3SK12 Left Row Connector 3SK12 Right Row
PIN 1 ANALOG GND PIN 1 ADC2
PIN 2 ADC1 PIN 2 ADC0
PIN 3 ADC3 PIN 3 ADC6
PIN 4 ADC5 PIN 4 ADC4
PIN 5 ADC7 PIN 5 DAC2
PIN 6 DAC1 PIN 6 DAC0
PIN 7 DAC3 PIN 7 DOP1
PIN 8 DOP0 PIN 8 ANALOG GND
PIN 9 DOP2 PIN 9 DOP5
PIN10 DOP4 PIN10DOP3
PIN 11 DOP6 PIN 11 DOP9
PIN 12 DOP8 PIN 12 DOP7
PIN 13 DOP10 PIN 13 USR GND
PIN 14 USER V+ PIN 14 DOP11
PIN 15 CAN WIRE+ PIN 15 ENCO.1
PIN 16 !EXT.INT.U PIN 16 CAN WIRE-
PIN 17 ENCO!! PIN 17 ENCO.A
PIN 18 ENCO!B PIN 18 ENCO.B
PIN19 ENCO!A PIN 19 ENC1.B
PIN 20 ENC1!! PIN 20 ENC1.1
PIN 21 ENC1 !B PIN 21 ENC2.1
PIN 22 ENC1 !A PIN 22 ENC1.A
PIN 23 ENC2!! PIN 23 ENC2.A
PIN 24 ENC2 !B PIN 24 ENC2.B
PIN 25 ENC2 !A PIN 25 ENC3.B
PIN 26 ENC3!! PIN 26 ENC3.1
PIN 27 ENC3 !B PIN 27 USR V+
PIN 28 ENC3 !A PIN 28 ENC3.A
PIN 29 PULSE 0 PIN 29 PULSE 1
PIN 30 BOOST 0 PIN 30 DIR 0
PIN 31 DIR1 PIN 31 DIR 2
PIN 32 PULSE 2 PIN 32 BOOST 0
PIN 33 BOOST 2 PIN BOOST 3
PIN 34 DIR 3 PIN 34 PULSE 3
PIN 35 USER GND PIN 35 DIG.IN.2
PIN 36 DIG.IN.1 PIN 36 DIG.IN.0
PIN 37 DIG.IN.3 PIN 37 DIG.IN.6
0$&+,1(3&
5($53$1(/&211(&725)81&7,216
5.22 Technical Reference Manual Chapter Issue 3 May 03
PCIB 40 ISA 9 (AutoFlex Tooling Option)
3SK16 (50 Way D Type)
PIN 38 DIG.IN.5 PIN 38 DIG.IN.4
PIN 39 DIG.IN.7 PIN 39 DIG.IN.10
PIN 40 DIG.IN.9 PIN 40 DIG.IN.8
PIN 41 DIG.IN.11 PIN 41 DIG.IN.14
PIN 42 DIG.IN.13 PIN 42 DIG.IN.12
PIN 43 DIG.IN.15 PIN 43 DIG.IN.18
PIN 44 DIG.IN.17 PIN 44 DIG.IN.16
PIN 45 DIG.IN.19 PIN 45 DIG.IN.22
PIN 46 DIG.IN.21 PIN 46 DIG.IN.20
PIN 47 DIG.IN.23 PIN 47 GND
PIN 48 +5V O/P PIN 48 GND
PIN 49 +5V O/P PIN 49 RELAY NO
PIN 50 RELAY N/C PIN 50 RELAY COM
Pin No. Signal Pin No. Signal
1 0V 26 Group 2 Bit 4 Tooling Data
2 Group 0 Bit 1 Tooling Data 27 Group 2 Bit 7 Tooling Data
3 Group 0 Bit 4 Tooling Data 28 Group 3 Bit 0 Tooling Data
4 Group 0 Bit 7 Tooling Data 29 Group 3 Bit 3 Tooling Data
5 Group 1 Bit 0 Tooling Data 30 Group 3 Bit 6 Tooling Data
6 Group 1 Bit 3 Tooling Data 31 Group 4 Bit 3 Board Data
7 Group 1 Bit 6 Tooling Data 32 P (Power On Switch)
8 Group 4 Bit 1 Pin Set 33 +12V
9 Group 2 Bit 2 Tooling Data 34 0V
10 Group 2 Bit 5 Tooling Data 35 Group 0 Bit 2 Tooling Data
11 0V 36 Group 0 Bit 5 Tooling Data
12 Group 3 Bit 1 Tooling Data 37 0V
13 Group 3 Bit 4 Tooling Data 38 Group 1 Bit 1 Tooling Data
14 Group 3 Bit 7 Tooling Data 39 Group 1 Bit 4 Tooling Data
15 Group 4 Bit 4 Board Data 40 Group 1 Bit 7 Tooling Data
16 C (Reduced Power Switch) 41 Group 2 Bit 0 Tooling Data
17 +5V 42 Group 2 Bit 3 Board Select
18 Group 0 Bit 0 Tooling Data 43 Group 2 Bit 6 Board Select
19 Group 0 Bit 3 Tooling Data 44 Group 4 Bit 2 Pin Set
20 Group 0 Bit 6 Tooling Data 45 Group 3 Bit 2 Tooling Data
21 Group 4 Bit 0 Pin Set 46 Group 3 Bit 5 Tooling Data
22 Group 1 Bit 2 Tooling Data 47 0V
23 Group 1 Bit 5 Tooling Data 48 Group 4 Bit 5 Board Data
Connector 3SK12 Left Row Connector 3SK12 Right Row
0$&+,1(3&
5($53$1(/&211(&725)81&7,216
Chapter Issue 3 May 03 Technical Reference Manual 5.23
NOTE
The pin-outs on this connector do not match pin for pin on the AutoFlex board
connectors.
4 Channel RS232 Comms Card ISA 7 (Not Fitted In All Machines)
4 Channel Comms 3SK27 (37 Way D Type)
24 0V 49 -12V
25 Group 2 Bit 1 Tooling Data 50 +5V
Pin No. Signal Pin No. Signal
Pin No. Signal Pin No. Signal
1N/C 20RI3
2 DCD3 21 DTR3
3 GND 22 DSR3
4CTS3 23RTS3
5RX3 24TX3
6 RI4 25 DCD4
7DTR4 26GND
8DSR4 27CTS4
9RTS4 28RX4
10 TX4 29 RI2
11 DCD2 30 DTR2
12 GND 31 DSR2
13 CTS2 32 RTS2
14 RX2 33 TX2
15 RI1 34 DCD1
16 DTR1 35 GND
17 DSR1 36 CTS1
18 RTS1 37 RX1
19 TX1
